ROLLSIZER.COM AUTOMATIC DECAPPER
Operating and Maintenance Manual
PLEASE READ THIS MANUAL BEFORE YOU USE THIS MACHINE
(OR ASK US FOR TECHNICAL SUPPORT…...).
We are always happy to help if you have any questions, but it is nice to
know you have read this first. Please use the same terminology used in
this manual when contacting us. It will help us to understand what the
issue is.
All brass processing or reloading activities come with risks including
health, environmental or personal physical risks. The owners and users of
this Decapper acknowledge and accept the Rollsizer.com Pty Ltd terms
and conditions of sale. A copy of the terms and conditions are available
on the Rollsizer.com website.
The Decapper is designed for the small to medium volume personal
reloader. It is not designed or warranted for commercial or unattended
operation. The Decapper will process cases between 380ACP up to
308Win and only requires minor changes to the speed and using the
appropriate drop tube and shuttle to change calibres.
The Decapper has been designed for use with the supplied FW Arms
Universal Decapping Die and the small decapping pins ONLY. The
Decapper will NOT work with large pins. You can damage the Decapper if
you try.
Using decapping dies other than the one provided is not likely to work.

Decapper O & M Manual Rev D
It is expected that at some stage you WILL break pins, and occasionally
guide rods for a variety of reasons (rocks, dirt, nestled cases, Berdan
primed cases etc.) and with extended use (or abuse) you will eventually
wear out other parts on the Decapper. Replacement parts are available
from Rollsizer.com.
The Decapper motor WILL get warm especially when new / running in.
The motor and gearboxes will often get up to 75Deg C (167F), especially
when new. This is normal. The plastic components have been designed
for the motor / gearbox temperatures and will not be affected. At slower
speeds the Decapper will have a high frequency whine, this is normal and
does not affect the operation. Yes, it’s annoying, sorry, that’s the way it
is.
It is expected the gearmotor will take time to bed in, this will mean the
Decapper will run slightly slower initially and stall more readily in some
situations. Likewise the Decapper is expected to require adjustment in
the linkage between the decapper body and the case pusher. Refer to
the manual for details. Please read it a few times before attempting any
adjustment.
Please do NOT modify the decapper outside of the instructions included
in this manual. The Decapper is surprisingly complex and we ask you to
discuss this with us BEFORE you modify it.

Operating and Maintenance Manual
Contents
Introduction....................................................................................................4
Safety First......................................................................................................5
Disclaimer.......................................................................................................5
➢What is supplied with the Decapper? ................................................6
➢Decapper Operation...........................................................................8
➢Decapper Location –Where to place it? ............................................9
➢FW Arms Decapper installation........................................................10
➢Power Supply and Motor..................................................................12
➢Switch operation...............................................................................14
➢Casefeeder and Connecting Hose.....................................................15
➢Processing Rates...............................................................................16
➢Calibre Conversions ..........................................................................17
➢Pistol conversions.........................................................................17
➢Rifle conversion process...............................................................17
➢Calibre conversion process...........................................................18
➢Maintenance Requirements.............................................................19
➢Pre-Start Checks ...........................................................................20
➢Gearbox and Motor Maintenance................................................20
➢What tools do I need? ..................................................................21
➢Decapper FAQ’s ............................................................................21

Operating and Maintenance Manual
Introduction
The Decapper you have purchased will supply years of reliable operation if
the processes and safety procedures in this manual are followed.
The Decapper has been designed to remove spent / fired primers from lightly
soiled fired cases to allow cleaning / processing before reloading.
Please ensure you read this manual from start to finish BEFORE you use the
Decapper. Please pay attention to the following key points.
•The Decapper is not designed for unattended operation and should
be monitored at all times.
•Only fired cases with spent primers should be used in the
Decapper.
•The following are considered consumables and are not covered by
warranty
oDecapping pins and guide rods.
oWear on the stainless-steel base and plastic pegs / spring.
oWear in the spherical bearings, (these require grease).
oAny damage to the pegs, spring, and case pusher from jammed
cases.
oDamage to the Decapper mount from repeated jamming or
incorrectly adjusted decapping dies.
•Loaded ammunition or cases with live primers should never be
processed or used in the Decapper under any circumstances.
SERIOUS INJURY or DEATH could result.
•Check the drop tube height is adjusted before using the Decapper,
refer to the manual below.
•Fill the feed tube BEFORE starting the Decapper.
•The last case in the Decapper will need to be removed manually,
use long nose pliers…. Not your fingers….

Operating and Maintenance Manual
5 | P a g e D e c a p p e r O & M M a n u a l R e v D
Safety First
Please note that with all machinery, safety is critical. Do not allow
inexperienced users to operate this machine and never allow children near
the Decapper (or any other machinery) whilst it is operating. Never attempt
any sort of work or adjustment on the machine whilst the Decapper is
energized or operating. Work should never be done on the Decapper unless
the power supply is turned off and the power lead is unplugged from the
power supply.
Failure to do this could result in significant injury or death.
In addition, you should never process reloaded ammunition or cases with
live primers through the Decapper, if the ammunition or components are
ignited, there is significant risk of injury or death as a result.
Disclaimer
The purchaser and users of this machine expressly acknowledge and hold
harmless, Rollsizer.com Pty Ltd, its affiliates, associates, and resellers
(hereafter noted as Rollsizer.com), from all liabilities including loss of
income, injury, harm or death for the use of the Decapper and any actions
that the use that the Decapper may have. Rollsizer.com make no claims or
guarantees regarding the suitability of the processed cases for reloading or
any other use and it is the responsibility of the user to verify the suitability
and purpose of the finished product.
All Decappers are sold subject to the Terms and Conditions on the
Rollsizer.com website.
❖When you see this symbol, we will provide suggestions that will
assist in installing / setting up / operating your Decapper.

Operating and Maintenance Manual
6 | P a g e D e c a p p e r O & M M a n u a l R e v D
➢What is supplied with the Decapper?
The Decapper will generally be supplied with the following components in
addition to the drop tubes and additional spares purchased with your
Decapper.
1. Your Decapper is supplied with a custom FW Arms Decapper
Assembly. You will need to install and adjust the Decapper as
detailed in the supplied instructions from FW Arms AND the process
described in this manual.
2. The following is supplied with the Decapper as standard
a. This manual. Updated manuals are available online.
b. 1 set of self-aligning “pegs” and spare spring.
c. Length of 15mm (5/8”) ID vinyl feed hose with a Dillon
casefeeder adaptor fitted on one end and a cable tie for the
drop tube on the other end. This is called the feed hose.
d. Length of 15mm (5/8’) ID Vinyl hose to be used to control
the cases feeding into a bucket (or similar) and for primer
removal. The customer can cut the hose to suit.
e. Universal Power supply suitable for 100VAC to 277VAC
supplies. The power supply brick is supplied to the market
with an Australian power plug and depending on your
location a plug adaptor. You may need to purchase a plug
adaptor to suit your location. These are available from most
electronic and travel stores.
3. You will need additional parts to operate the Decapper, and these
include spare decapping pins and drop tubes. The spare pins are a
recommended spare and drop tubes are calibre sensitive and should
be ordered with the machine at the time of purchase. If you did not
order these, you WILL need them before your machine will process
cases.

Operating and Maintenance Manual
7 | P a g e D e c a p p e r O & M M a n u a l R e v D
Refer to photographs below identifying the main components of the
Decappers.
Drop tube showing the
feed hose correctly
positioned / fitted.
Trim the other end if
you need to shorten
the hose.
On / Off / Reverse switch.
The reverse is a momentary
switch to assist in removal of
jammed cases.
Always disconnect the
power supply before
removing cases. Use long
nose pliers to remove cases.
Mounting holes
to screw base
to reloading
bench. (4
places)
Variable Speed
control dial.
2 x Discharge tubes for
cases and spent primers.
You will need to cut the
tube to suit.
Self-
aligning
pegs
FW Arms
Decapping
Die
Case
pusher

Operating and Maintenance Manual
8 | P a g e D e c a p p e r O & M M a n u a l R e v D
➢Decapper Operation
The Decapper operation is generally as follows.
❖Cases do not always need to be sorted perfectly. However, some
case combinations can be a problem as they can nestle within the
other case and jam in the drop tube. This will result in nuisance
jams and potentially damage to the decapper. (9mm fits nicely
inside a 40S&W).
1. Remove rocks, debris, and other contaminants from the fired cases
(light soot and soiling on the cases is acceptable).
2. The cases are fed from your casefeeder though the supplied feed
hose.
3. Cases fall into the drop tube which in turn allows individual cases
to be control fed into the case pusher.
4. The motor rotation lifts the Decapper (moving up and down
vertically) while the case pusher moves horizontally backwards and
forwards.
5. As the case is pushed into position it will “snap” into the decapping
position. This position is self-centering.
❖It does not matter if the case is a small 380ACP or a 44mag
case. The primer position is the same.
6. As the motor continues to rotate, the case pusher arm pulls back,
and the decapper lowers onto the primer to push out the primer.
The primer will come out with an audible “pop”. This noise is
normal and is useful to identify if the primer pin is broken.
❖We recommend you process cases in small batches so if
you miss identifying a broken pin you will not have to redo
large volumes of cases. For this (and other reasons) we
STRONGLY recommend you keep the decapping pin in your
reloading press)
7. As the primer is being removed, another case falls in front of the
case pusher.

Operating and Maintenance Manual
9 | P a g e D e c a p p e r O & M M a n u a l R e v D
8. As the motor continues to rotate, the decapper lifts, and the new
case is pushed into position. As the case moves into position it will
push the previous case out.
9. As the case is pushed out the pegs will “snap” and the case will be
thrown into the drop chute. IF THE CASE PUSHER IS NOT
CORRECTLY ADJUSTED THEN CASES WILL OFTEN FALL OVER AT THIS
POINT.
❖In certain case types the processing speed will need
adjustment (up or down) to prevent the cases bouncing
around too long in the drop hole.
10. When the case supply has run out the last case will not be pushed
out. To remove this case, park the decapper so there is sufficient
clearance above the case to allow the case to be removed.
❖We STRONGLY recommend you use long nose needle pliers to
remove cases. DO NOT PUT YOUR FINGERS IN THE DECAPPER
unit ever. Serious injury could result.
➢Decapper Location –Where to place it?
The location of the Decapper requires some thought and planning BEFORE
you fit / cut the hoses. Please consider the position of the casefeeder and
where the primer tube and decapped cases will be routed.
❖Place the Decapper on your bench as a trial and look at the
underside of the machine. You will see 2 tubes coming out.
These will have tubes connected to them and need to clear the
edge of the bench. Think about where the tubes will go and how
easy it will be to remove the primers from the tube. The spent
primer hose can be sealed with tape or plugged.
❖Consider rotating your case feeder 90 degrees if it is mounted on
a square tube, this may improve the tube route to the decapper.
In most applications, the hoses for the deprimed cases and spent primers
do not need to be clamped to the discharge tubes. Simply push them on.

Operating and Maintenance Manual
10 | P a g e D e c a p p e r O & M M a n u a l R e v D
The tube is supplied coiled in the box and will often want to stay that way.
Running (and holding) hot water in the tube for a few minutes will allow
the tube to relax and straighten out.
❖It helps if you knead the hose whilst it is hot and hang it vertically
whilst it cools.
The decapper machine has 4 places where hold down bolts or screws can
be used. Refer to the photos in this manual.
In most installations, hold down screws will not be required, but if you
place it in a position where it can get knocked off the bench, then screw it
down to be safe.
❖If the decapper falls off your bench onto concrete, you will break
something. We have replacement parts if required.
➢FW Arms Decapper installation
The FW Arms Decapping Die supplied with the decapping machine is a
proprietary product that has been customized for the Rollsizer.com
decapper. It is not a standard FW Arms decapping unit. The installation of
the decapping unit must only be done with the decapper linkage shown in
the position shown in the photo below. This ensures the decapper body
will not touch / crush the pegs in its lowest position.
Failure to follow this procedure will break or damage the pegs or the
decapper body. This is NOT a warranty claim.
The decapper will only work with Small Pins. Using the FW Arms large
pins will result in the cases jamming on the pin and being pulled up and
out of the pegs.
Please read the Instructions supplied with the FW Arms Decapper. The
manual explains the safe pin removal / replacement procedure. The
supplied decapper parts include specialized spanners to remove broken
pins and a spare guide rod. Pins should be finger tight only with the locktite
and left to set for a minimum of 1 hour before use.
Indice
Altri manuali Rollsizer Attrezzature industriali
