ROSE DISPLAYS ANOQUICK ROUND WITH MULTICLIPS Manuale utente

35 Congress Street, Salem, MA 01970

Tel# 1- 800 631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Parts

Instruction Sheet

Step 1

Prepare edges of graphic. Place the graphic on

tabletop with one edge at the table edge. Using

the AnoQuick holder, run it across the graphic

edge, crushing it slightly. Fig. 1

Step 2

Starting at one corner, push the holder onto the

graphic. Work your way down the holder tapping

it down firmly to seat the graphic fully. Fig. 2

Step 3

Squeeze sides of MultiClip together. Fig.3

Step 4

Align the bottom rail of the MultiClip with

the top channel of the aluminum holder. Slide

MultiClip into rail. Fig. 4 Repeat steps 3 & 4

for second MultiClip.

Step 5

Push end caps into place. Fig. 5

Step 6

Suspend poster. Fig. 6

Important note:

Please save and reuse the AnoQuick holder,

End Caps and MultiClips for future projects.

MultiClips

1UP-0101

End Caps

06-5525

Note: Use only

with graphics

mounted on 3/16”

foamboard or other

similar thickness.

Can also use a

folded edge thinner

substrate.

AnoQuick™

Instructions for Hanging

Incept-7.31.02

Figure 2

AnoQuick

12A300

AnoQuick is a trademark. Neither the manufacturer nor any sales agent

may be held liable for injury, loss or damage resulting from the use of

these products. Part #02INSAnoQuickMC

Figure 3

Figure 5

Figure 4

Figure 1

Figure 6

35 Congress Street, Salem, MA 01970

Tel# 1- 800 631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Parts

Note: Use only

with graphics

mounted on 3/16”

foamboard or other

similar thickness.

Can also use a

folded edge thinner

substrate.

Instructions for Hanging

OneUp

Instruction Sheet

Step 1

Prepare edges of graphic. Place the graphic on

tabletop with one edge at the table edge. Using

the AnoQuick holder, run it across the graphic

edge, crushing it slightly. Fig. 1

Step 2

Starting at one corner, push the holder onto the

graphic. Work your way down the holder tapping

it down firmly to seat the graphic fully. Fig. 2

Step 3

Squeeze sides of MultiClip together. Fig.3

Step 4

Align the bottom rail of the MultiClip with

the top channel of the aluminum holder. Slide

MultiClip into rail. Fig. 4

Step 5

Push end caps into place. Fig. 5

Step 6

Suspend poster. Fig. 6

Important note:

Please save and reuse the AnoQuick holder,

End Caps and MultiClip for future projects.

AnoQuick™

Incept-7.31.02

End Caps

06-5525

AnoQuick

12A300

AnoQuick is a trademark. Neither the manufacturer nor any sales agent

may be held liable for injury, loss or damage resulting from the use of

these products. Part #02INSAnoQuickMC

MultiClip

1UP-0101

Figure 2

Figure 3

Figure 5

Figure 4

Figure 1

Figure 6

Parts

Note: Use only

with graphics

mounted on 3/16”

foamboard or other

similar thickness.

Can also use a

folded edge thinner

substrate.

Instructions for Hanging

Instruction Sheet

AnoQuickTM

Incept-7.31.02

End Caps

06-5525

AnoQuick

12A300

AnoQuick is a trademark. Neither the manufacturer nor any sales agent

may be held liable for injury, loss or damage resulting from the use of

these products. Part #02INSAnoQuickMC

MultiClips

1UP-0101

Step 1

Prepare edges of graphic. Place the graphic on

tabletop with one edge at the table edge. Using

the AnoQuick holder, run it across the graphic

edge, crushing it slightly. Fig. 1

Step 2

Starting at one corner, push the holder onto the

graphic. Work your way down the holder tapping

it down firmly to seat the graphic fully. Fig. 2

Step 3

Squeeze sides of MultiClip together. Fig.3

Step 4

Align the bottom rail of the MultiClip with

the top channel of the aluminum holder. Slide

MultiClip into rail. Fig. 4 Repeat steps 3 & 4

for second MultiClip.

Step 5

Push end caps into place. Fig. 5

Step 6

Suspend poster. Fig. 6

Important note:

Please save and reuse the AnoQuick holder,

End Caps and MultiClips for future projects.

Figure 2

Figure 3

Figure 5

Figure 4

Figure 1

Figure 6

Incept-7.31.02

Parts

Note: Use only

with graphics

mounted on 3/16”

foamboard or other

similar thickness.

Can also use a

folded edge thinner

substrate.

Instructions for Hanging

OneUp

Instruction Sheet

AnoQuick™

Incept-7.31.02

End Caps

06-5525

AnoQuick

12A300

AnoQuick is a trademark. Neither the manufacturer nor any sales agent

may be held liable for injury, loss or damage resulting from the use of

these products. Part #02INSAnoQuickMC

MultiClip

1UP-0101

Step 1

Prepare edges of graphic. Place the graphic on

tabletop with one edge at the table edge. Using

the AnoQuick holder, run it across the graphic

edge, crushing it slightly. Fig. 1

Step 2

Starting at one corner, push the holder onto the

graphic. Work your way down the holder tapping

it down firmly to seat the graphic fully. Fig. 2

Step 3

Squeeze sides of MultiClip together. Fig.3

Step 4

Align the bottom rail of the MultiClip with

the top channel of the aluminum holder. Slide

MultiClip into rail. Fig. 4

Step 5

Push end caps into place. Fig. 5

Step 6

Suspend poster. Fig. 6

Important note:

Please save and reuse the AnoQuick holder,

End Caps and MultiClip for future projects.

Figure 2

Figure 3

Figure 5

Figure 4

Figure 1

Figure 6
