ROSE DISPLAYS ANOGOTCHA PLUS WITH MULTICLIPS AND REGULAR... Manuale utente

Parts

AnoGotcha Plus

Instructions to hang graphic

Incept-2.15.05

AnoGotcha is a traemark and Gotcha is a registered trademark of Rose

Displays, Ltd. Neither the manufacturer nor any sales agent may be held

liable for injury, loss or damage resulting from the use of these products.

Part #04INSAnoGotchaPlus

Note: Follow steps 1 through 4 for both

the top and bottom holder.

Step 1

Rotate one end cap on each AnoGotcha Plusn180˚.

The Gotcha will be easily accessible. Fig. 1

Step 2

Slide the Gotcha out of the aluminum shell. Fig. 2

Step 3

Place poster on a flat surface. Snap the Gotcha

holder open so hinge is turned up as far as possible.

Insert graphic completely into holder until edge of

graphic meets top of holder. Fig. 3 To close, snap

the Gotcha holder shut. Fig. 4

Note: It is easier to open and close the Gotcha

holder by starting at one end and working your way

down the holder. With large or curling graphics, it

may be easier to insert graphic at one end and slide

into holder from one end to another.

Step 4

Slide Gotcha into the AnoGotcha Plus and rotate

the end cap 180˚ back to its original position. Fig.5

Step 5

Suspend graphic with regular hooks. Fig.6

Note: To change graphic, unhook the holder from

the regular hooks and repeat steps 1 through 5.

Instruction Sheet

35 Congress Street, Salem, MA 01970

Tel# 1- 800 631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

MultiClips

(already inserted into

aluminum shell)

AnoGotcha

Plus Shells

12AG500

Regular Hooks

Gotcha holder

(already inserted into

aluminum shells)

Figure 3 Figure 4

Figure 1 Figure 2

Figure 5 Figure 6

Parts

AnoGotcha Plus

Instructions to hang graphic

Incept-2.15.05

AnoGotcha is a traemark and Gotcha is a registered trademark of Rose

Displays, Ltd. Neither the manufacturer nor any sales agent may be held

liable for injury, loss or damage resulting from the use of these products.

Part #04INSAnoGotchaPlus

Note: Follow steps 1 through 4 for both

the top and bottom holder.

Step 1

Rotate one end cap on each AnoGotcha Plusn180˚.

The Gotcha will be easily accessible. Fig. 1

Step 2

Slide the Gotcha out of the aluminum shell. Fig. 2

Step 3

Place poster on a flat surface. Snap the Gotcha

holder open so hinge is turned up as far as possible.

Insert graphic completely into holder until edge of

graphic meets top of holder. Fig. 3 To close, snap

the Gotcha holder shut. Fig. 4

Note: It is easier to open and close the Gotcha

holder by starting at one end and working your way

down the holder. With large or curling graphics, it

may be easier to insert graphic at one end and slide

into holder from one end to another.

Step 4

Slide Gotcha into the AnoGotcha Plus and rotate

the end cap 180˚ back to its original position. Fig.5

Step 5

Suspend graphic with regular hooks. Fig.6

Note: To change graphic, unhook the holder from

the regular hooks and repeat steps 1 through 5.

Instruction Sheet

MultiClips

(already inserted into

aluminum shell)

AnoGotcha

Plus Shells

12AG500

Regular Hooks

Gotcha holder

(already inserted into

aluminum shells)

Figure 3 Figure 4

Figure 1 Figure 2

Figure 5 Figure 6
