ROSE DISPLAYS ANOQUICK ROUND WITH GOTCHA AND MULTICLIPS Manuale utente

Parts

35 Congress Street, Salem MA 01970

Tel# 1-800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Instructions for Hanging

Step 1

Place poster on a flat surface. Snap the Gotcha

Holder open and insert poster (top and bottom).

To close, snap the Gotcha Holder shut. Fig. 1

Note: It is easier to open and close the Gotcha

Holder by starting at one end and working your way

down the holder.

Step 2

Slide the Gotcha Holder into the AnoQuick Holder.

Fig. 2

Step 3

Install MultiClips in the top AnoQuick Holder.

Holding clip at slight angle, first insert one round

end, then press down on other round end and push

MultiClip into holder. Insert second MultiClip.

Fig. 3 & 4

Step 4

Push end caps into place. Fig. 5

Note: To remove Gotcha (and sign), simply rotate

end cap up out of the way.

Step 5

Suspend poster.

Important note:

Please save and reuse the AnoQuick Holder, Gotcha

Holder, End Caps and MultiClips for future projects.

AnoQuick™ with Gotcha

Insert

Instructions for Hanging

Incept-9.9.02

The AnoQuickTM is a trademark and Gotcha®is a registered trademark of

Rose Displays, Ltd. Neither the manufacturer nor any sales agent may be

held liable for injury, loss or damage resulting from the use of these

products. Part #02INSAnoQuickGotchaMC

Gotcha

Special

(no clip rail)

AnoQuick

12A300R

MultiClips

1UP-0100

End Caps

06-5525

Figure 1

Figure 5

Figure 2

Figure 3

Figure 4

Instruction Sheet

Parts

35 Congress Street, Salem MA 01970

Tel# 1-800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Instructions for Hanging

Step 1

Place poster on a flat surface. Snap the Gotcha

Holder open and insert poster (top and bottom).

To close, snap the Gotcha shut. Fig. 1

Note: It is easier to open and close the Gotcha

Holder by starting at one end and working your way

down the holder.

Step 2

Slide the Gotcha Holder into the AnoQuick

Holder. Fig. 2

Step 3

Install MultiClip in the top AnoQuick Holder.

Holding clip at slight angle, first insert one round

end, then press down on other round end and push

MultiClip into holder. Fig. 3

Note: For OneUp applications place the MultiClip

in the center of the AnoQuick Holder. Fig. 4

Step 4

Push end caps into place. Fig. 5

Note: To remove Gotcha (and sign), simply rotate

end cap up out of the way.

Step 5

Suspend poster.

Important note:

Please save and reuse the AnoQuick Holder, Gotcha

Holder, End Caps and MultiClips for future projects.

Instructions for Hanging

Incept-9.9.02

The AnoQuickTM is a trademark and Gotcha®is a registered trademark of

Rose Displays, Ltd. Neither the manufacturer nor any sales agent may be

held liable for injury, loss or damage resulting from the use of these

products. Part #02INSAnoQuickGotchaMC

Gotcha

Special

(no clip rail)

AnoQuick

12A300R

End Caps

06-5525

MultiClip

1UP-0100

Figure 1

Figure 4

Figure 2

Figure 5

Figure 3

AnoQuick™ with Gotcha

Insert

OneUp

Instruction Sheet

Parts

Instructions for Hanging

Step 1

Place poster on a flat surface. Snap the Gotcha

Holder open and insert poster (top and bottom).

To close, snap the Gotcha Holder shut. Fig. 1

Note: It is easier to open and close the Gotcha

Holder by starting at one end and working your

way down the holder.

Step 2

Slide the Gotcha Holder into the AnoQuick Holder.

Fig. 2

Step 3

Install MultiClips in the top AnoQuick Holder.

Holding clip at slight angle, first insert one round

end, then press down on other round end and push

MultiClip into holder. Insert second MultiClip.

Fig. 3 & 4

Step 4

Push end caps into place. Fig. 5

Note: To remove Gotcha (and sign), simply rotate

end cap up out of the way.

Step 5

Suspend poster.

Important note:

Please save and reuse the AnoQuick Holder, Gotcha

Holder, End Caps and MultiClips for future projects.

Instructions for Hanging

Incept-9.9.02

The AnoQuickTM is a trademark and Gotcha®is a registered trademark of

Rose Displays, Ltd. Neither the manufacturer nor any sales agent may be

held liable for injury, loss or damage resulting from the use of these

products. Part #02INSAnoQuickGotchaMC

Gotcha

Special

(no clip rail)

AnoQuick

12A300R

End Caps

06-5525

MultiClips

1UP-0100

Figure 1

Figure 5

Figure 2

Figure 3

Figure 4

AnoQuick™ with Gotcha

Insert

Instruction Sheet

Parts

Instructions for Hanging

Step 1

Place poster on a flat surface. Snap the Gotcha

Holder open and insert poster (top and bottom).

To close, snap the Gotcha Holder shut. Fig. 1

Note: It is easier to open and close the Gotcha

Holder by starting at one end and working your way

down the holder.

Step 2

Slide the Gotcha Holder into the AnoQuick Holder.

Fig. 2

Step 3

Install MultiClip in the top AnoQuick Holder.

Holding clip at slight angle, first insert one round

end, then press down on other round end and push

MultiClip into holder. Fig. 3

Note: For OneUp applications place the MultiClip

in the center of the AnoQuick Holder. Fig. 4

Step 4

Push end caps into place. Fig. 5

Note: To remove Gotcha (and sign), simply rotate

end cap up out of the way.

Step 5

Suspend poster.

Important note:

Please save and reuse the AnoQuick Holder, Gotcha

Holder, End Caps and MultiClips for future projects.

AnoQuick™ with Gotcha

Insert

Instructions for Hanging

Incept-9.9.02

The AnoQuick is a trademark and Gotcha®is a registered trademark of

Rose Displays, Ltd. Neither the manufacturer nor any sales agent may be

held liable for injury, loss or damage resulting from the use of these

products. Part #02INSAnoQuickGotchaMC

Gotcha

Special

(no clip rail)

AnoQuick

12A300R

End Caps

06-5525

OneUp

Instruction Sheet

MultiClip

1UP-0100

Figure 1

Figure 4

Figure 2

Figure 5

Figure 3
