ROSE DISPLAYS ANOQUICK WITH PEG AND MULTICLIPS Manuale utente

Parts

Instructions for Hanging

Instruction Sheet

Step 1

When using AnoQuick to hang 1/8” Sintra or an

equally heavy substrate, have your printer punch

two 1/4” holes along the top and bottom edges of

print — or only the top if no bottom holder is

being used. Fig. 1

Note: Each hole must be centered 1/4” in from the

edge of the substrate.

Step 2

Push both parts of the peg together through each

of the punched holes. Fig. 2

Step 3

Install MultiClip in the top AnoQuick Holder.

Holding clip at slight angle, first insert one round

end, then press down on other round end and push

MultiClip into holder. Fig. 3

Note: For OneUp applications place the

MultiClip in the center of the AnoQuick Holder.

AnoQuick™ with Peg

Instructions for Hanging

Incept-8.15.02

Figure 1

The AnoQuick is a registered trademark of Rose Displays, Ltd. Neither

the manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part # 02INSAnoQw/PegMCEndcap

Figure 2

Figure 3

AnoQuick

12A300R

End Caps

06-5525

MultiClip

1UP-0100

Pegs

06-1920

35 Congress Street, Salem MA 01970

Tel# 1-800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Parts

Instructions for Hanging

Instruction Sheet

Step 1

When using AnoQuick to hang 1/8” Sintra or an

equally heavy substrate, have your printer punch

two 1/4” holes along the top and bottom edges of

print — or only the top if no bottom holder is

being used. Fig. 1

Note: Each hole must be centered 1/4” in from the

edge of the substrate.

Step 2

Push both parts of the peg together through each

of the punched holes. Fig. 2

Step 3

Install MultiClip in the top AnoQuick Holder.

Holding clip at slight angle, first insert one round

end, then press down on other round end and push

MultiClip into holder. Fig. 3

Note: For OneUp applications place the

MultiClip in the center of the AnoQuick Holder.

AnoQuick™ with Peg

Instructions for Hanging

Incept-8.15.02

Figure 1

The AnoQuick is a registered trademark of Rose Displays, Ltd. Neither

the manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part # 02INSAnoQw/PegMCEndcap

Figure 2

Figure 3

AnoQuick

12A300R

End Caps

06-5525

MultiClip

1UP-0100

Pegs

06-1920

Parts

Instructions for Hanging

Step 4

Slide AnoQuick onto substrate. The pegs should

slide into the side rails. Fig. 4

Note: This is the easiest way to safely hang

heavier substrates.

Step 5

Push end caps into place. Fig. 5

Note: To remove poster with pegs, simply rotate

end cap up out of the way.

Step 6

Suspend poster.

Important note:

Please save and reuse the AnoQuick Holder, Pegs,

End Caps and MultiClips for future projects.

Instructions for Hanging

Incept-8.15.02

The AnoQuick is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #02INSAnoQw/PegMCEndcap

AnoQuick

12A300R

End Caps

06-5525

MultiClip

1UP-0100

Figure 5

Figure 4

Pegs

06-1920

35 Congress Street, Salem MA 01970

Tel# 1-800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Instruction Sheet

AnoQuick™ with Peg

Parts

Instructions for Hanging

Step 4

Slide AnoQuick onto substrate. The pegs should

slide into the side rails. Fig. 4

Note: This is the easiest way to safely hang

heavier substrates.

Step 5

Push end caps into place. Fig. 5

Note: To remove poster with pegs, simply rotate

end cap up out of the way.

Step 6

Suspend poster.

Important note:

Please save and reuse the AnoQuick Holder, Pegs,

End Caps and MultiClips for future projects.

Instructions for Hanging

Incept-8.15.02

The AnoQuick is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #02INSAnoQw/PegMCEndcap

AnoQuick

12A300R

End Caps

06-5525

MultiClip

1UP-0100

Figure 5

Figure 4

Pegs

06-1920

Instruction Sheet

AnoQuick™ with Peg
