ROSE DISPLAYS ULTRAFRAME WITH SLATWALL Manuale utente

Parts

35 Congress Street, Salem MA 01970

Tel# 1-800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Instructions for Hanging

Instruction Sheet

Step 1

Insert hangers into upper portion

of slatwall. Fig. 1

Note: To ensure that the frame hangs level use

two hangers placed an equal distance in from

each side of the frame.

Step 2

Hangers will rest on lower portion

of slatwall. Fig. 2

Step 3

Place UltraFrame on the hangers using the

bottom channel of the top rail. Fig. 3

Step 4

Place UltraFrame in position on slatwall.

Fig. 4

Step 5

Open rails, put in poster and

close rails. Fig 5

Note: Be sure to open all four side rails

gently. Excessive force may cause inside clips

to unhinge.

UltraFrame™ Slatwall Hanger

Instructions for Hanging

Incept-9.13.02

The UltraFrame™ is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss

or damage resulting from the use of these products.

Part #02INSUltraFrameSlatwall

Slatwall Hanger

06-6068

UltraFrame

12UF100

Figure 1 Figure 2

Figure 3 Figure 4

Figure 5

Parts

Instructions for Hanging

Instruction Sheet

Step 1

Insert hangers into upper portion

of slatwall. Fig. 1

Note: To ensure that the frame hangs level use

two hangers placed an equal distance in from

each side of the frame.

Step 2

Hangers will rest on lower portion

of slatwall. Fig. 2

Step 3

Place UltraFrame on the hangers using the

bottom channel of the top rail. Fig. 3

Step 4

Place UltraFrame in position on slatwall.

Fig. 4

Step 5

Open rails, put in poster and

close rails. Fig 5

Note: Be sure to open all four side rails

gently. Excessive force may cause inside clips

to unhinge.

UltraFrame™ Slatwall Hanger

Instructions for Hanging

Incept-9.13.02

The UltraFrame™ is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss

or damage resulting from the use of these products.

Part #02INSUltraFrameSlatwall

Slatwall Hanger

06-6068

UltraFrame

12UF100

Figure 1 Figure 2

Figure 3 Figure 4

Figure 5
