ROSE DISPLAYS ECONOFRAME WITH WINDOW MOUNTS Manuale utente

35 Congress Street, Salem, MA 01970

Tel# 1- 800 631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Parts

Instruction Sheet

Step 1

Locate the two split rails and the

solid rail that is the same length as

the split rails.

Insert corner brackets into side

EconoFrame rails. Insert two corner

brackets into each end of the solid

side rail. Insert one corner bracket

into each end of each split side rail.

Fig. 1 & Fig. 2

Note: Tension tabs on corner

brackets face towards outside of

frame.

Step 2

Slide the Window Mounts

into the top rail of the EconoFrame

rail. Fig. 3

Step 3

Finish assembling frame following the

sequence in Fig. 4.

Step 4

Insert poster. Fig 5

Note: For best performance when

first applied and occasionally

thereafter, press the middle of the

cup (on the cap) to “burp” extra

air out.

EconoFrame™

Instructions for Hanging

Incept-12.04.02

The EconoFrame™ is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #02INSEconoFrameWindowMounts

Figure 1

Figure 5

Figure 3

Figure 4

split rails

Figure 2

Window Mounts

20-0038

Corner

brackets

split rails

solid rail

EconoFrame

Rails 12EF-100

EconoFrame

Split Rails

Parts

Window Mounts

20-0038

Instruction Sheet

EconoFrame™

Instructions for Hanging

Incept-12.04.02

The EconoFrame™ is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #02INSEconoFrameWindowMounts

Corner

brackets

Figure 1

Figure 5

Figure 3

Figure 4

split rails

Step 1

Locate the two split rails and the

solid rail that is the same length as

the split rails.

Insert corner brackets into side

EconnoFrame rails. Insert two corner

brackets into each end of the solid

side rail. Insert one corner bracket

into each end of each split side rail.

Fig. 1 & Fig. 2

Note: Tension tabs on corner

brackets face towards outside of

frame.

Step 2

Slide the Window Mounts

into the top rail of the EconoFrame

rail. Fig. 3

Step 3

Finish assembling frame following the

sequence in Fig. 4.

Step 4

Insert poster. Fig 5

Note: For best performance when

first applied and occasionally

thereafter, press the middle of the

cup (on the cap) to “burp” extra

air out.

Figure 2

split rails

solid rail

EconoFrame

Rails 12EF-100

EconoFrame

Split Rails
