ROSE DISPLAYS SPIDER RING Manuale utente

35 Congress Street, Salem, MA 01970

Tel# 1- 800 631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Parts

Spider Ring™

Important note:

Spider Rings can be attached before or after

suspending sign. If the rings need to be posi-

tioned out of reach, or if more than two cable

wraps are required per ring, wrap the cable

around the rings before sign is hung.

Step 1

Place Spider Ring onto the cable. The cable

goes inside the ring’s outer groove. Fig. 1

Step 2

With the cable inside the groove, wrap it once

around the ring. Fig. 2

Step 3

While holding the ring, pull down on

cable until it pops into the groove. Fig. 3

Repeat steps 1-3 for multiple wrappings.

Note: Each wrap shortens the cable by 3”.

Maximum of 6 wraps or 18” per Spider Ring.

Multiple rings can be used on each cable for

more adjustability.

Step 4

Repeat steps 1-3 for each cable used to hang

your sign.

Step 5

Slide the Spider Rings up and out of view. Fig 4

& 5. Note: To lengthen cable, unwind one

or more wraps from each Spider Ring.

Instruction Sheet

Instructions for assembly

Incept-2.5.02

The Spider Ring™ is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #02INSSpiderRing

Spider Ring

16-0018R

Figure 5

Figure 3 Figure 4

Figure 1 Figure 2
