RSA Lighting ACT955RMMH Manuale utente

DESCRIPTION Catalog # Type

Project

Comments Date

Prepared by

www.cooperlighting.com

SPECIFICATION FEATURES

A...Housing

White housing with structural steel arm

and wireway. Connected to integral j-box.

B ...System Protection:

Thermal protection provided to guard

against overheating and misuse of

insulation over and around ﬁxture.

Vent holes in housing provide cooler

operation.

C ...Electrical

Integral j-box and electronic metal halide

ballast. 120V/277V input. Junction box

is U.L. listed for through branch wiring.

Includes ﬁve 1/2 trade size knockouts.

D...Lamp

MR16 style metal halide lamp. (not included)

GX10 twist-and-lock lamp socket included.

E ...Mounting

Supplied with 3 (three) spring loaded

mounting clips. May accomodate 1/2”,

1”, or 1-1/2” ceiling thickness. Includes

adjustable leveling screw.

Ceiling Cut-Out: 4.18”

ACCURUS

ACT955RMMH

Remodel Housing

for 5” Square Trim

FOR METAL HALIDE MR16

20W or 39W

ORDERING INFORMATION

Housing

ACT955RMMH =

Accurus Remodel Housing

for Square Trim

w/ Integral Metal Halide Ballast

Voltage

120 =120 volts primary

277 =277 volts primary*

*Consult factory for 277V ballast availability.

Remodel housing for Accurus square trims. Includes electronic metal

halide ballast for use with 20W or 39W MR16 Metal Halide lamp.

For remodel applications. Insulation must be kept 3” from all sides and at

least 1” above the housing.

Speciﬁcations and Dimensions subject to change without notice.

RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031

Ballast Wattage

20 =20 watts

39 =39 watts

ACT955RMMH

rev 122007

11.25”

3.28”

5.00”

4.18”

J-box with integral

electronic metal

halide ballast
