RTS XCP-24 Guida rapida

July 2006 Rev B

XCP-24

Breakout Panel Technical Guide

38110-513

CHAPTER 13

XCP-24

9000-7559-000

The XCP-24 Breakout Panel allows for the expansion of the

ADAM frame using TELCO connectors. When using the

XCP-24 breakout panel, you must use the SCSI backcard

with the AIO-16 card.

TABLE 1.

J2 J1 J3

Telco Connector (J1 - J3)

SCSI Connector (J4 - J6)

XCP-24

J4 J5 J6

SCSI Connector - J1, J2, J3, J4, J5

Number Port Function

2Data+

27 Data -

34 1 Audio To Matrix +

9 1 Audio To Matrix -

35 1 Audio From Matrix +

10 1 Audio From Matrix -

36 2 Audio To Matrix +

11 2 Audio To Matrix -

37 2 Audio From Matrix +

12 2 Audio From Matrix -

38 3 Audio To Matrix +

13 3 Audio To Matrix -

39 3 Audio From Matrix +

14 3 Audio From Matrix -

40 4 Audio To Matrix +

15 4 Audio To Matrix -

41 4 Audio From Matrix +

16 4 Audio From Matrix -

42 5 Audio To Matrix +

17 5 Audio To Matrix -

43 5 Audio From Matrix +

18 5 Audio From Matrix -

SCSI Connector - J1, J2, J3, J4, J5

Number Port Function

XCP-24 9000-7559-000

44 6 Audio To Matrix +

19 6 Audio To Matrix -

45 6 Audio From Matrix +

20 6 Audio From Matrix -

46 7 Audio To Matrix +

21 7 Audio To Matrix -

47 7 Audio From Matrix +

22 7 Audio From Matrix -

48 8 Audio To Matrix +

23 8 Audio To Matrix -

49 8 Audio From Matrix +

24 8 Audio From Matrix -

Telco Backcard - Telco Connector - J1

Number Port Function

1 1 Audio To Matrix +

26 1 Audio To Matrix -

2 2 Audio To Matrix +

27 2 Audio To Matrix -

3 3 Audio To Matrix +

28 3 Audio To Matrix -

4 4 Audio To Matrix +

29 4 Audio To Matrix -

5 5 Audio To Matrix +

30 5 Audio To Matrix -

6 6 Audio To Matrix +

31 6 Audio To Matrix -

7 7 Audio To Matrix +

32 7 Audio To Matrix -

8 8 Audio To Matrix +

33 8 Audio To Matrix -

9 9 Audio To Matrix +

SCSI Connector - J1, J2, J3, J4, J5

Number Port Function

34 9 Audio To Matrix -

10 10 Audio To Matrix +

35 10 Audio To Matrix -

11 11 Audio To Matrix +

36 11 Audio To Matrix -

12 12 Audio To Matrix +

37 12 Audio To Matrix -

13 13 Audio To Matrix +

38 13 Audio To Matrix -

14 14 Audio To Matrix +

39 14 Audio To Matrix -

15 15 Audio To Matrix +

40 15 Audio To Matrix -

16 16 Audio To Matrix +

41 16 Audio To Matrix -

17 17 Audio To Matrix +

42 17 Audio To Matrix -

18 18 Audio To Matrix +

43 18 Audio To Matrix -

19 19 Audio To Matrix +

44 19 Audio To Matrix -

20 20 Audio To Matrix +

45 20 Audio To Matrix -

21 21 Audio To Matrix +

46 21 Audio To Matrix -

22 22 Audio To Matrix +

47 22 Audio To Matrix -

23 23 Audio To Matrix +

48 23 Audio To Matrix -

Telco Backcard - Telco Connector - J1

Number Port Function

XCP-24 9000-7559-000

24 24 Audio To Matrix +

49 24 Audio To Matrix -

Telco Backcard - Telco Connector - J2

Number Port Function

1 1 Audio From Matrix +

26 1 Audio From Matrix -

2 2 Audio From Matrix +

27 2 Audio From Matrix -

3 3 Audio From Matrix +

28 3 Audio From Matrix -

4 4 Audio From Matrix +

29 4 Audio From Matrix -

5 5 Audio From Matrix +

30 5 Audio From Matrix -

6 6 Audio From Matrix +

31 6 Audio From Matrix -

7 7 Audio From Matrix +

32 7 Audio From Matrix -

8 8 Audio From Matrix +

33 8 Audio From Matrix -

9 9 Audio From Matrix +

34 9 Audio From Matrix -

10 10 Audio From Matrix +

35 10 Audio From Matrix -

11 11 Audio From Matrix +

36 11 Audio From Matrix -

12 12 Audio From Matrix +

37 12 Audio From Matrix -

Telco Backcard - Telco Connector - J1

Number Port Function

13 13 Audio From Matrix +

38 13 Audio From Matrix -

14 14 Audio From Matrix +

39 14 Audio From Matrix -

15 15 Audio From Matrix +

40 15 Audio From Matrix -

16 16 Audio From Matrix +

41 16 Audio From Matrix -

17 17 Audio From Matrix +

42 17 Audio From Matrix -

18 18 Audio From Matrix +

43 18 Audio From Matrix -

19 19 Audio From Matrix +

44 19 Audio From Matrix -

20 20 Audio From Matrix +

45 20 Audio From Matrix -

21 21 Audio From Matrix +

46 21 Audio From Matrix -

22 22 Audio From Matrix +

47 22 Audio From Matrix -

23 23 Audio From Matrix +

48 23 Audio From Matrix -

24 24 Audio From Matrix +

49 24 Audio From Matrix -

Telco Backcard - Telco Connector - J2

Number Port Function

XCP-24 9000-7559-000

Telco Backcard - Telco Connector - J3

Number Port Function

1-8 1-8 Data +

25-33 1-8 Data -

9-16 9-16 Data +

34-41 9-16 Data -

17-24 17-24 Data +

42-49 17-24 Data -
