RTS XCP-955 Guida rapida
July 2006 Rev B
XCP-955
Breakout Panel Technical Guide
LIT000021
1
CHAPTER 1
XCP-955
8800303674
The XCP-955 is the 25-port RJ-11 breakout panel with SCSI
connector for the ADAM.
Specifications
Dimensions:
18.98” (482mm) L x 1.69” (43mm) H x 0.55” (104mm) D
Weight:
1.6 lb (.725 kg)
J28
DATA
J27
AUDIO DESTINATION
J26
AUDIO SOURCE
XCP-955
XCP-955
RTS SYSTEMS
RJ-12 Connector
Pin 1 Keypanel Data -
Pin 2 Audio Out +
Pin 3 Audio In +
Pin 4 Audio In -
Pin 5 Audio Out -
Pin 6 Keypanel Data +
XCP-955 8800303674
2
Telco Backcard - Telco Connector - J26
Pin
Number Port Function
1 1 Audio From Matrix +
26 1 Audio From Matrix -
2 2 Audio From Matrix +
27 2 Audio From Matrix -
3 3 Audio From Matrix +
28 3 Audio From Matrix -
4 4 Audio From Matrix +
29 4 Audio From Matrix -
5 5 Audio From Matrix +
30 5 Audio From Matrix -
6 6 Audio From Matrix +
31 6 Audio From Matrix -
7 7 Audio From Matrix +
32 7 Audio From Matrix -
8 8 Audio From Matrix +
33 8 Audio From Matrix -
9 9 Audio From Matrix +
34 9 Audio From Matrix -
10 10 Audio From Matrix +
35 10 Audio From Matrix -
11 11 Audio From Matrix +
36 11 Audio From Matrix -
12 12 Audio From Matrix +
37 12 Audio From Matrix -
13 13 Audio From Matrix +
38 13 Audio From Matrix -
14 14 Audio From Matrix +
39 14 Audio From Matrix -
15 15 Audio From Matrix +
40 15 Audio From Matrix -
16 16 Audio From Matrix +
41 16 Audio From Matrix -
17 17 Audio From Matrix +
42 17 Audio From Matrix -
18 18 Audio From Matrix +
43 18 Audio From Matrix -
19 19 Audio From Matrix +
44 19 Audio From Matrix -
20 20 Audio From Matrix +
45 20 Audio From Matrix -
21 21 Audio From Matrix +
46 21 Audio From Matrix -
22 22 Audio From Matrix +
47 22 Audio From Matrix -
23 23 Audio From Matrix +
48 23 Audio From Matrix -
24 24 Audio From Matrix +
49 24 Audio From Matrix -
Telco Backcard - Telco Connector - J27
Pin
Number Port Function
11AudioToMatrix+
26 1 Audio To Matrix -
22AudioToMatrix+
27 2 Audio To Matrix -
33AudioToMatrix+
28 3 Audio To Matrix -
44AudioToMatrix+
Telco Backcard - Telco Connector - J26
Pin
Number Port Function
3
Specifications
29 4 Audio To Matrix -
5 5 Audio To Matrix +
30 5 Audio To Matrix -
6 6 Audio To Matrix +
31 6 Audio To Matrix -
7 7 Audio To Matrix +
32 7 Audio To Matrix -
8 8 Audio To Matrix +
33 8 Audio To Matrix -
9 9 Audio To Matrix +
34 9 Audio To Matrix -
10 10 Audio To Matrix +
35 10 Audio To Matrix -
11 11 Audio To Matrix +
36 11 Audio To Matrix -
12 12 Audio To Matrix +
37 12 Audio To Matrix -
13 13 Audio To Matrix +
38 13 Audio To Matrix -
14 14 Audio To Matrix +
39 14 Audio To Matrix -
15 15 Audio To Matrix +
40 15 Audio To Matrix -
16 16 Audio To Matrix +
41 16 Audio To Matrix -
17 17 Audio To Matrix +
42 17 Audio To Matrix -
18 18 Audio To Matrix +
43 18 Audio To Matrix -
Telco Backcard - Telco Connector - J27
Pin
Number Port Function
19 19 Audio To Matrix +
44 19 Audio To Matrix -
20 20 Audio To Matrix +
45 20 Audio To Matrix -
21 21 Audio To Matrix +
46 21 Audio To Matrix -
22 22 Audio To Matrix +
47 22 Audio To Matrix -
23 23 Audio To Matrix +
48 23 Audio To Matrix -
24 24 Audio To Matrix +
49 24 Audio To Matrix -
Telco Backcard - Telco Connector - J28
Pin
Number Port Function
1-8 1-8 Data +
25-33 1-8 Data -
9-16 9-16 Data +
34-41 9-16 Data -
17-24 17-24 Data +
42-49 17-24 Data -
Telco Backcard - Telco Connector - J27
Pin
Number Port Function
XCP-955 8800303674
