MT7000

User’s Manual

v1.3

Contents

CONTENTS..................................................................................................................................................................... 2

SAFETY PRECAUTIONS........................................................................................................................................... 5

REGULATORY AND CERTIFICATION.................................................................................................................. 7

FCC...................................................................................................................................................................................................7

CE MARKING..................................................................................................................................................................................8

R&TTE.............................................................................................................................................................................................8

LITHIUM BATTERY SAFETY STATEMENT...............................................................................................................................8

CHAPTER 1. PRODUCT INTRODUCTION.......................................................................................................... 9

HARDWARE SPECIFICATIONS...................................................................................................................................................9

ENVIRONMENT............................................................................................................................................................................ 10

I/O PORTS.................................................................................................................................................................................... 11

DIMENSION AND WEIGHT........................................................................................................................................................ 12

MT7000 Standard.............................................................................................................................................................. 12

MT7000 with I/O water-proof box.............................................................................................................................. 13

PACKAGE LIST ............................................................................................................................................................................ 14

CHAPTER 2. HARDWARE INSTALLATION......................................................................................................15

MSATAMODULE........................................................................................................................................................................ 15

Installing/Removing a mSATA Module.................................................................................................................... 15

INSTALLING/REMOVING THE WI-FI MODULE................................................................................................................... 17

INSTALLING/REMOVING THE SIM CARD ............................................................................................................................ 18

Internal SIM slot................................................................................................................................................................. 19

External SIM slot................................................................................................................................................................ 20

INSTALLING/REMOVING THE WWAN MODULE ............................................................................................................... 21

Optional WWAN Module Installation........................................................................................................................ 21

INSTALLING WWAN/WLANANTENNAS............................................................................................................................ 23

Internal Antennas............................................................................................................................................................... 23

External Antenna................................................................................................................................................................ 24

CHAPTER 3. HARDWARE MOUNTING.............................................................................................................25

CHAPTER 4. START UP ..........................................................................................................................................26

POWERING THE SYSTEM........................................................................................................................................................ 26

Connector Power............................................................................................................................................................... 26

Powering Down the System......................................................................................................................................... 28

LED STATUS................................................................................................................................................................................ 29

ADJUST THE SPEAKER VOLUME.......................................................................................................................................... 30

AUTO-BRIGHTNESS ADJUSTMENT...................................................................................................................................... 30

INTERNAL MICROPHONE......................................................................................................................................................... 31

PROGRAMMABLE BUTTONS................................................................................................................................................... 31

POWER MANAGEMENT............................................................................................................................................................ 31

CHAPTER 5. JUMPERS AND CONNECTORS................................................................................................32

BOTTOM VIEW ............................................................................................................................................................................ 32

EXTERNAL CONNECTORS PIN ASSIGNMENTS................................................................................................................ 33

Power Connector............................................................................................................................................................... 33

RS-232 Port (COM1)....................................................................................................................................................... 34

USB and RS-232/422/485 Port (COM2)................................................................................................................ 35

Digital I/O and CANbus Port........................................................................................................................................ 37

CHAPTER 6. DASHON SETTING.........................................................................................................................38

DEVICE INFORMATION.............................................................................................................................................................. 39

VEHICLE STATUS ....................................................................................................................................................................... 40

COMMUNICATION SETTING.................................................................................................................................................... 41

Enable/ Disable Module................................................................................................................................................. 41

WWAN Communication Setting................................................................................................................................. 42

SYSTEM STATUS &SETTING................................................................................................................................................. 43

Power Automatic Turn Off Behavior......................................................................................................................... 43

Power Management Setup........................................................................................................................................... 43

Wake up Setting................................................................................................................................................................. 48

I/O Configuration................................................................................................................................................................ 50

Brightness Setting............................................................................................................................................................. 50

Watchdog Timer................................................................................................................................................................. 51

Programmable Button..................................................................................................................................................... 54

LOCATION AND SENSOR.......................................................................................................................................................... 56

Enable/ Disable GPS Receiver................................................................................................................................... 58

Serial Port Setting............................................................................................................................................................. 58

Baud Rate Setting............................................................................................................................................................. 59

CHAPTER 7. MAIN BIOS SETTING.....................................................................................................................60

SET BOOT SEQUENCE............................................................................................................................................................. 60

SET THE SYSTEM CONFIGURATION..................................................................................................................................... 61

Setting the System Date................................................................................................................................................ 61

Setting the System Time................................................................................................................................................ 61

SYSTEM INFORMATION............................................................................................................................................................ 62

BOOT FEATURES ....................................................................................................................................................................... 62

MISCELLANEOUS CONFIGURATION..................................................................................................................................... 63

ACCOUNT’S PASSWORD SETTING....................................................................................................................................... 63

HDD SECURITY SETTING....................................................................................................................................................... 64

CHAPTER 7. WI-FI HOTSPOT SETUP...............................................................................................................65

Safety Precautions

1. Read these safety instructions carefully. 

2. Keep this user’s manual for later reference. 

3. Disconnect this equipment from anyAC outlet before cleaning. Use a damp cloth. Do

not use liquid or spray detergents for cleaning. 

4. For plug-in equipment, the power outlet socket must be located near the equipment and

must be easily accessible. 

5. Keep this equipment away from humidity. 

6. Put this equipment on a stable surface during installation. Dropping it or letting it fall

may cause damage. 

7. Do not leave this equipment in either an unconditioned environment or in an above

40ºC storage temperature as this may damage the equipment. 

8. The openings on the enclosure are for air convection to protect the equipment from

overheating. DO NOT COVER THE OPENINGS. 

9. Make sure the voltage of the power source is correct before connecting the equipment

to the power outlet. 

10. Place the power cord in a way so that people will not step on it. Do not place anything

on top of the power cord. Use a power cord that has been approved for use with the

product and that it matches the voltage and current marked on the product’s electrical

range label. The voltage and current rating of the cord must be greater than the volt-

age and current rating marked on the product. 

11. All cautions and warnings on the equipment should be noted.

12. If the equipment is not used for a long time, disconnect it from the power source to avoid

damage by transient overvoltage.

13. Never pour any liquid into an opening. This may cause fire or electrical shock.

14. Never open the equipment. For safety reasons, the equipment should be opened only

by qualified service personnel.

15. If one of the following situations arise, get the equipment checked by service personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well, or you cannot get it to work according to the

user’s manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

16. Do not place heavy objects on the equipment.

17. The unit uses a three-wire ground cable which is equipped with a third pin to ground the

unit and prevent electric shock. Do not defeat the purpose of this pin. If your outlet does

not support this kind of plug, contact your electrician to replace your obsolete outlet.

18. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY RE- PLACED.

REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE REC- OMMENDED BY

THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE

MANUFACTURER’S INSTRUCTIONS.

Regulatory and Certification

FCC

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may

cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Shielded interconnect cables and shielded AC power cable must be employed with this

equipment to insure compliance with the pertinent RF emission limits governing this device.

Changes or modifications not expressly approved by the system’s manufacturer could void

the user’s authority to operate the equipment.

Any changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

This device is operable in 5.15 –5.25GHz frequency range, then restricted in

indoor use only, Outdoor operations in the 5.15 –5.25GHz is prohibitive.

CE Marking

This product has passed the CE test for environmental specifications when shielded cables

are used for external wiring. We recommend the use of shielded cables. Please contact your

local representative for ordering information.

This product has passed the CE test for environmental specifications. Test conditions for

passing included the equipment being operated within an industrial enclosure. In order to

protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage,

we strongly recommend the use of CE-compliant industrial enclosure products.

R&TTE

This device complies with the essential requirements of the R&TTE Directive 1999/5/EC.

Lithium Battery Safety Statement

Lithium battery inside. Danger of explosion if battery is incorrectly replaced. Replace only

with the same or equivalent type of battery recommended by battery manufacturer.

THIS PRODUCT CONTAINS LITHIUM-ION BATTERY PACKS. IT MUST BE

DISPOSED OF PROPERLY. CONTACT LOCAL ENVIRONMENTAL

AGENCIES FOR INFORMATION ON RECYCLING AND DISPOSAL PLANS IN

YOUR AREA.

Chapter 1. Product Introduction

MT7000 is an in-vehicle terminal with 7” high resolution display and 500nits brightness, and

is flexible to support a wide range of wireless connection capability. The device is well-suited

for fleet management, asset management, EOBR and ELDs application.

It is compliant to ISO 7637-2, SAE J1455 and SAE J1113 and its optimized power system is

designed for cold cranking, load dump, transient voltage and ESD.

The device is engineered with IP65 protection rating, a wide temperature design, wide input

range, and rich expanding interfaces that support in-vehicle connectivity.

Hardware Specifications

Item

Description

Processor

Intel® Atom™ E3815 1.46GHz, optional Intel® Atom™ E3826 1.46GHz

Memory

DDR3L 2GB SDRAM up to 4GB (by request)

Storage

mSATA SSD x 1, Micro SD slot x 1

Display

7-inch WSVGA (1024 x 600)

500 nits

Viewing angel: 145(H)/ 160(V) (CR>10)

Touch Panel

Projected Capacitive Touch Screen

Wireless

Connectivity

802.11 ac/a/b/g/n 2x2

Bluetooth 4.0 + HS

GPS / QZSS or GLONASS (COM3)

1 mini PCIe slot (full size) for cellular module

External SMA female connectors for wireless expansion (Wi-Fi/WWAN

and GPS)

Item

Description

Power Input

9-36VDC,3.5A

Battery

1950mAh, 3.6V

Housing

(Mechanical)

PC+ABS, fanless design

Certification

CE, FCC, CB

Environment

Operating temperature:

-30°C (-22°F) to 60°C (140°F)

In accordance with MIL-STD-810G CHANGE1 Method 501.6 High Temperature

Procedure II - Operation

In accordance with MIL-STD-810G CHANGE1 Method 502.6 Low Temperature

Procedure II –Operation

Storage temperature:

-30°C (-22°F) to 70 °C (158°F)

In accordance with MIL-STD-810G CHANGE1 Method 501.6 High Temperature

Procedure I –Storage

In accordance with MIL-STD-810G CHANGE1 Method 502.6 Low Temperature

Procedure I - Storage

Relative humidity:5% to 95% @ 30°C (86°F) to 60°C (140°F) non-condensing in

accordance with MIL-STD-810G CHANGE1 Method 507.6 Humidity Procedure II

Aggravated Cycles (Fig 507.6-7)

Vibration Test:

Operating: MIL-STD-810G CHANGE1 Method 514.7 Category 4,

Fig 514.7C-2 Common carrier (US highway truck vibration exposure);

Fig 514.7C-3 Composite two-wheeled trailer;

Fig 514.7C-4 Composite wheeled vehicle

Non-Operating: MIL-STD-810G CHANGE1 Method 514.7 Category 24, Fig

514.7E-1 (General minimum integrity exposure)

Shock Test:

Operation: MIL-STD-810G CHANGE1 Method 516.7 Procedure 1 Functional

Shock

Non-Operation: MIL-STD-810G CHANGE1 Method 516.7 Procedure V Crash

Hazard Shock

Altri manuali per MT7000

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali RuggON Terminale touch

RuggON

RuggON MT7000 Manuale utente

Manuali Terminale touch popolari di altre marche

Wincor Nixdorf

Wincor Nixdorf iPOS plus Advanced Manuale utente

Ingenico

Ingenico AXIUM EX4000 Manuale utente

Heisei Electronics

Heisei Electronics Q-POS 815 Manuale utente

Amano

Amano MTX-15 Manuale utente

FLOWBIRD

FLOWBIRD CWT Compact Touch Manuale utente

Demco

Demco SP7 Manuale utente

Lathem

Lathem PC600 Series Manuale utente

Partner

Partner MF-2352 Manuale utente

NCR

NCR RealPOS 7460-2 Manuale

Simrad

Simrad MS50 Istruzioni per il montaggio

Unitech

Unitech MR350 MKII Guida rapida

Jungheinrich

Jungheinrich WMT 210 Manuale utente

Motorola

Motorola MTP850 Manuale utente

YASKAWA

YASKAWA 62H-MDC0 Manuale utente

MVG industries

MVG industries NeptuLink Manuale utente

Price Industries Limited

Price Industries Limited FDC Manuale di istruzioni

Honeywell

Honeywell TemaKey Manuale utente

EBN

EBN BPC65-B-A16G Manuale utente
