RunningSnail MD-090P Manuale utente
● RADIO OPERATION
● SOS ALARM
● FLASHLIGHT
● READING LAMP
● MOTION SENSOR
●
CHARGE & DISCHARGE FUNCTION
● BATTERY PROTECTION
● 4 POWER METHODS
● POWER INDICATOR
● KIND REMINDER
● SPECIFICATION
● WARRANTY
● PACKING LIST
CONTENTS:
MD-090P Owner's Manual
RADIO OPERATION
● Turn the “Volume” Dial clockwise to power on the
radio and adjust volume.
● Select FM/AM/WB with radio band switch. Extend
the antenna to get better signal reception, especially
listening to the FM and NOAA broadcasts.
● Turn Tuner Dial to select station. Green tune indicator
turns on when the station selected is fully engaged.
● Turn the “volume” dial to the OFF position and the
radio will turn off.
SOS
Solar Panel
Volume Dial
Tuner Dial
Band Switch
SOS Button
Charging Indicator
Tune Indicator
Antenna
Far and
Dipped Beam
Flashlight Button
4 blue power
indicator lights
①
③
②
④⑤
⑥
⑦
⑧
⑨
⑩
11
MD-090P Owner's Manual
SOS ALARM
FLASHLIGHT
READING LAMP
●
Hold the SOS button for once, the device will activate
a loud siren and a flashing far beam.
● Press the SOS button again to turn it off.
● The first press on the flashlight button, the far beam
lights up. The second press on the flashlight button,
the dipped beam lights up. The third press with both
far and dipped beam light up. The forth press with
both light off.
●
Turn the sensor switch to the LIGHT position, open
the solar panel, the reading lamp lights up. Close
the solar panel, and the reading light goes out.
Reading Lamp
Crank Handle
Lithium Battery
Sensor Switch
Motion
Sensor Probe
MD-090P Owner's Manual
CHARGE & DISCHARGE FUNCTION
MOTION SENSOR
●
Turn the sensor switch to the AUTO position,open
the solar panel, when there’s movement within
3 meters, the reading lamp lights up. When there
is no movement in this range, after 30 seconds,
the reading lamp will turn off. Close the solar panel,
the reading lamp will extinguish.
● Please turn the sensor switch to the LIGHT position
when not in use.
● The waterproof cover on the side of this product
has a USB output port and a USB input port.
●
Connect the USB device to the USB output port of
the unit via USB cable to power the USB device.
When the device is used as a power bank
(discharge),
the power indicator lights will diminish.
Micro USB Input
Micro USB Output
1.
This feature is suggested to use in emergency, do
not use it as a normal power bank.
NOTE:
MD-090P Owner's Manual
4 POWER METHODS
● Connect the supplied Micro USB cable to the Micro
USB Input port on the right side of the unit to charge
built-in lithium battery. Meanwhile. 4 blue power
indicator lights will light up in sequence.
● The radio can also be charged by turning the handle
at the back of the device and activating the
dynamo.
●The handle can be turned either clockwise or coun
-terclockwise. Spin the handle for 1 minute at the
speed of 130 rpm. It can be used for high beam
illumination for 30 minutes or radio for 6 minutes.
USB charging
A
Hand Crank
B
BATTERY PROTECTION
●
This emergency radio is designed with a feature of
shutdown in low voltage. To protect the chip, the
power supply will be cut off to protect the battery
from damage when there is an overload or a short
circuit in this unit.
● It will cut of the power source when the voltage is
lower than 2.7V and protects the battery from being
over-discharged and damaged.
●
Please have the radio charged at least once
every three months.
MD-090P Owner's Manual
● Expose the solar panel in clear sunlight to let it cha
-rges as efficiently as possible.
●
The red power indicator lights will light up when
the radio received enough sunlight to start charging
up.
●
It is mostly used for maintaining the battery, to prolong
the battery life.
SOLAR POWER
c
Crank Handle
1.The battery is damaged.
2.
You can replace two fully charged battery when the
built-in battery is dead in power outage.
● Open on the battery cover by using screwdriver.
● Take out two of 18650 Li-ion battery and then put
two brand new 18650 Li-ion batteries into the battery
compartment, then close the battery cover.
● We suggest that you can replace the battery by this
two situation:
REPLACEABLE LI-ION BATTERY
d
MD-090P Owner's Manual
POWER INDICATOR
KIND REMINDER
● For the first use or when the unit idles over 60 days,
please hand crank for 1 minutes to activate the internal
battery.
● The device shall not be exposed to dripping or spla
-shing, and objects filled with liquids should not be
placed on the device.
● Please do not over discharge the unit, so as not to
reduce the internal battery life, or even damage the
battery.
● Avoid flashlight light directly into the eyes, or it will
hurt the eyes.
● This unit has 4 blue power indicator lights to show
the power capacity.The power indicator will light up
for 30 seconds when turn on the radio/ flashlight/
reading lamp and the indicator light stays on when
charging and discharging.
● 4 lights up：C>75%
● 3 lights up：50 %<C<75%
● 2 lights up：25 %< C<50%
● 1 lights up：3 %< C<25%
● The first light flash：C<3%
● C means capacity
4 blue power indicator lights
MD-090P Owner's Manual
WARRANTY
PACKING LIST
SPECIFICATION
● The device has a full 18-month warranty agains manuf-
acturing defects from the date of purchase.
● Radio x 1
● Micro USB Cable x 1
● User Manual x 1
● iPhone Adapter x 1
Frequency range
Dimensions
FM 87~108MHz
AM 520~1710KHz
WB 162.400~162.550MHz
160*63*81mm/
6.23*2.48*3.19in
380g
10w (Max)
2.7~4.2V
4000mAh/3.7V Li-ion
5V, 1A
5-6 h
IPX3
135LM(Max)
LED lighting：
Far beam or dipped beam：＞16h
Far beam and dipped beam: ＞10h
Reading lamp: ＞20h
Broadcast (middle volume):
＞2000min
Weight
Power consumption
Working voltage
Power source
USB output
Charging time(USB)
Waterproof level
LED flashlight
After fully charged,
the device supports
MD-090P Owner's Manual
