Russell Hobbs 24732 Manuale utente

I www.russellhobbs.com

24732

Visit uk.russellhobbs.com/product-registration You must register within 28 days of purchase

h b

Read the instructions, keep them safe, pass them on if you pass the appliance on. Remove all

packaging before use.

IMPORTANT SAFEGUARDS

Follow basic safety precautions, including:

This appliance can be used by persons with reduced physical,

sensory or mental capabilities or lack of experience and knowledge

if they have been supervised/instructed and understand the

hazards involved. Children must not use or play with the appliance.

Keep the appliance and cable out of reach of children.

c To avoid injury, take care handling the blades, emptying the jug,

and cleaning.

h Don’t add hot liquid (over 40°C), as it may be ejected due to

sudden steaming.

Misuse of the appliance may cause injury.

Unplug the appliance before assembly, disassembly, or cleaning.

Don’t leave the appliance unattended while plugged in.

If the cable is damaged, it must be replaced by the manufacturer, its

service agent, or someone similarly qualied, to avoid hazard.

• Don’t put the motor unit in liquid.

• Switch o (0) before tting the jug to the motor unit.

• Switch o (0), and wait till the blades come to a stop before removing the lid from the jug,

or removing the jug from the motor unit.

• Don’t put utensils into the jug while the appliance is plugged in.

• Don’t use accessories or attachments other than those we supply.

• Don’t use the appliance for any purpose other than those described in these instructions.

• Don’t operate the appliance if it’s damaged or malfunctions.

• Don’t run the motor continuously for more than 1½ minutes, it may overheat. After 1½

minutes switch o for at least 2 minutes, to recover.

HOUSEHOLD USE ONLY

PARTS

1. Speed control

2. Motor unit

3. Spindle

4. Blender jug

5. Jug

6. Drive shaft

7. Chopper attachment

8. Mixer attachment

9. Creamer attachment

10. Tab

11. Lid

12. Tube

13. Pusher

14. Disc

15. Cap

` dishwasher safe

BEFORE USING FOR THE FIRST TIME

Turn to “CARE AND MAINTENANCE” and clean the appliance, to remove manufacturing dust, etc.

PREPARATION

1. Sit the motor unit on a dry, rm, level surface.

2. Route the cable so it doesn’t overhang, and won’t trip or catch.

3. Lower the jug on to the motor unit, then turn the jug clockwise, to lock it in place.

4. Remove the lid.

5. Put the ingredients into the jug – don’t ll past the max mark.

6. Put the lid on the blending jug.

7. Check that the speed control is set to 0.

8. Put the plug into the power socket (switch it on, if it’s switchable).

9. Turn the speed control to the speed you want (1 = low, 2 = high).

10. Turn the speed control back to 0 to turn the motor o.

11. Turning the speed control anti-clockwise to Ywill give you a short burst at high speed. In

this direction, the knob is spring-loaded. When you let go, it’ll return to 0.

USING THE BLENDER

1. Lower the blender jug on to the motor unit, then turn the jug clockwise, to lock it in place.

2. Remove the lid.

3. Put the ingredients into the blender jug.

4. Replace the lid.

5. Align the pips on the cap with the slots in the hole in the lid, t the cap, and turn it

clockwise to lock it.

6. Don’t run the appliance without tting the cap.

7. To add ingredients while the blender is working, remove the cap, pour the new ingredients

through the hole, then replace the cap.

8. Once nished, switch the appliance o (0) and unplug it.

9. Turn the blender jug anti-clockwise, and lift it o the motor unit.

CRUSHED ICE

1. For best results, full the jug with between 150ml and 500ml of ice cubes.

2. Put the lid on the blender, then:

3. Turn the speed control to Yfor a second or two, then release it.

4. Check the results, and adjust.

USING THE PROCESSOR

1. Switch the appliance o () and unplug it.

2. Fit the spindle to the top of the motor unit.

3. Lower the jug on to the motor unit, then turn the jug clockwise, to lock it in place.

4. Choose the attachment you need.

5. Hold the lid with the tube slightly behind the jug handle, set it on the jug, then turn it

clockwise, to lock the tab into the top of the handle.

6. Once nished, switch the appliance o (0) and unplug it.

7. Turn the jug anti-clockwise, and lift it o the motor unit.

USING THE CHOPPER/MIXER/CREAMER ATTACHMENT

Use the chopper for pulverizing ingredients.

Use the mixer to mix ingredients together.

Use the creamer to thicken cream, to beat eggs, and to cream eggs and sugar together.

1. Lower the drive shaft into the bowl over the spindle.

2. Put the ingredients into the jug.

3. Hold the lid with the tube slightly behind the jug handle, set it on the jug, then turn it

clockwise, to lock the tab into the top of the handle.

4. To add ingredients while the motor is running, lift the pusher out of the tube, add the

ingredients through the tube then replace the pusher.

5. To remove the lid, turn it anti-clockwise to unlock it, then lift it o.

SLICING/GRATING

1. Fit the slicer or one of the graters into the disc.

2. Lower the disc over the top of the spindle.

3. Hold the lid with the tube slightly behind the jug handle, set it on the jug, then turn it

clockwise, to lock the tab into the top of the handle.

4. Remove the pusher, and drop the ingredients down the tube.

5. Replace the pusher, and use it to push the ingredients gently down the tube.

6. Don’t use ngers or cutlery to push food down the tube – only the pusher.

7. The blade(s) on top of the disc will slice or grate the food into the jug.

8. Don’t let the jug get more than about half full – stop and empty it.

9. To remove the lid, turn it anti-clockwise to unlock it, then lift it o.

10. Turn the disc over, and press one of the metal ends in and down, to remove the slicer/grater.

RECIPE

QUICK CHEESE AND TOMATO PIZZA (makes 2 medium pizzas)

• 440g white our

• 14g dried yeast

• 2 tbsp olive oil

• 240 ml lukewarm water

• 2 tsp sugar

• 1 tsp salt

• 200 g mozzarella cheese

Mix the water, yeast, and sugar in a bowl, and leave it for 5 minutes. Fit the mixer. Process the

our and salt at low speed. Add the water, yeast, and sugar mixture. Add the oil, increase speed

till a dough ball forms, then stop. Now run for 20 seconds, and rest for 2 minutes. Do this twice

more, then let the dough rest for 10 minutes.

Divide the dough into 2 balls, and stretch or roll each ball to t a lightly oiled baking tray. Top

with the pizza sauce. Use the coarse grater to grate the mozzarella cheese. Spread the cheese

over the pizzas and add other toppings if desired. Bake in a pre-heated oven at 190°C/gas mark

5 for 15-20 minutes.

CARE AND MAINTENANCE

1. Switch the appliance o (0) and unplug it.

2. Wipe the outside of the motor unit with a clean damp cloth.

3. Hand wash the removable parts.

4. If you use a dishwasher, the harsh environment inside the dishwasher will aect the surface

nishes.

5. The damage should be cosmetic only, and should not aect the operation of the appliance.

` You may wash these parts in a dishwasher.

T22-9001379

RECYCLING

WTo avoid environmental and health problems due to hazardous substances,

appliances and rechargeable and non-rechargeable batteries marked with

one of these symbols must not be disposed of with unsorted municipal

waste. Always dispose of electrical and electronic products and, where

applicable, rechargeable and non-rechargeable batteries, at an appropriate

ocial recycling/collection point.

SERVICE

If you ring Customer Service, please have the Model Number to hand, as we won’t be able to

help you without it. It’s on the rating plate (usually underneath the product).

The product isn’t user-serviceable. If it’s not working, read the instructions, check the plug fuse

and main fuse/circuit breaker. If it’s still not working, consult your retailer.

If that doesn’t solve the problem – ring Customer Service – they may be able to oer technical

advice.

If they advise you to return the product to us, pack it carefully, include a note with your name,

address, day phone number, and what’s wrong. If under guarantee, say where and when

purchased, and include proof of purchase (till receipt). Send it to:

Customer Service

Spectrum Brands (UK) Ltd

Fir Street, Failsworth, Manchester M35 0HS

email: support@russellhobbs.com

telephone: 0345 658 9700 (local rate number)

Please note: If you have purchased the product within the last 6 months, please contact the

retailer in the rst instance to deal with any matters relating to warranty.

GUARANTEE

Defects aecting product functionality appearing within the guarantee period will be corrected

by replacement or repair at our option provided the product is used and maintained in

accordance with the instructions. Your statutory rights are not aected.

Guarantee period = 2 years from rst retail purchase.

To claim an extra 1 year guarantee, register your product online within 28 days of purchase.

Consumables are guaranteed only for their recommended lifecycle. Replacement/Spare parts*

are excluded and are only covered by a 1 year warranty.

* Examples include lters, removable grill plates, drip trays/crumb trays etc.

JONLINE

www.russellhobbs.com for more products
