Russell Hobbs RHTTLF1 Manuale utente

FREESTANDING TABLE TOP

LARDER FRIDGE

USER’S GUIDE

Model number:

RHTTLF1/RHTTLF1B

For Customer Services & Spare Parts please call 0845 208 8750 Opening

times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at

www.productcareuk.com

IMPORTANT: RETAIN FOR FUTURE

REFERENCE

Page

BEFORE USING THE APPLIANCE

Safety Instructions

……………………………………….

Before Switching On

………………………………………. 3

Installing and Switching on the Appliance

………………………………………. 4

The Appliance and the Compartments

…………………………….………… 5

Usage Information

Thermostat Setting

……………………………………….

Cleaning and Maintenance

……………………………….……… 7

Important Notes

Product Specification

………………………….……………

……………………………………….

Connection to the Mains Supply

…………………………….………… 9

Transportation and Handling

Where to put your Appliance

Reversing the Door

…………………………………….…

……………………………………….

Troubleshooting

Guarantee

……………………………………….

For Customer Services & Spare Parts please call 0845 208 8750 Opening times: Monday - Friday 8am –

6pm & Saturday 9am – 1pm or visit us at

www.productcareuk.com

BEFORE USING THE APPLIANCE

Safety Instructions

•The model contains R600a (the coolant, Isobutene), a natural refrigerant gas that is

environmentally friendly but also combustible. When transporting and installing

the unit, care must be taken to ensure that none of the refrigeration circuit

components are damaged. In the event of damage avoid naked flames or ignition

sources and ventilate the room in which the unit is placed for a few minutes. Contact

a local service engineer.

Warning: Keep ventilation openings, in appliance enclosure or structure for building in,

clear of obstruction.

•The appliance must not be placed or rested on the power cord.

•Do not use mechanical devices or other artificial means to accelerate the defrosting

process.

•Do not use electrical appliances in the refrigerator compartment of the appliance.

•If this appliance is to replace an old refrigerator with a lock, break or remove the lock

as a safety measure before storing it, to protect children while they play locking

themselves inside.

•Old refrigerators and freezers contain insulation gases and refrigerant, they must be

disposed of properly. Entrust the disposal of the scrap unit categorically to the

competence of your local waste disposal service. Contact your local authority or

your dealer if you have any questions. Please ensure that you do not damaged the

scrap unit prior to being picked-up by the relevant waste disposal service.

Important Note: Please read this booklet before installing and switching on this

appliance. The manufacturer assumes no responsibility for incorrect installation

and usage as described in this booklet.

For Customer Services & Spare Parts please call 0845 208 8750 Opening times: Monday - Friday 8am –

6pm & Saturday 9am – 1pm or visit us at

www.productcareuk.com

Safety Instructions

Warning:

•This appliance can be used by children aged from 8 years and above and persons with

reduced physical, sensory or mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning use of the appliance in a

safe way and understand the hazards involved. Children shall not play with the

appliance.

•Do not use adaptors , multiple receptacles or extension leads.

•Do not plug in damaged plugs.

•Do not pull, twist or damage the power cable.

•Do not put the appliance or any other objects on the power cord.

•This appliance is designed for the use by adults, do not allow children to play with the

appliance or let them hang over the door.

•Do not plug-in or un-plug the appliance with wet hands to prevent electrical shock.

•Do not place explosive or flammable material in your fridge for your own safety.

•Bottles containing a high percentage of alcohol must be sealed well and placed

vertically in the refrigerator.

•Do not cover the body or the top of the appliance with lace. This affects the

performance of your fridge.

•Fix down the accessories in the fridge during transportation to prevent damage to

them.

Before Switching On:

•Let the appliance rest for 4 hours before plugging into the main power to ensure

proper performance.

•There can be an odour when you first switch on the appliance, this is normal and will

disappear when the appliance starts to cool.

•Before using your appliance, add a teaspoon of bicarbonate of soda to warm water

and with a damp clothe wipe down all parts of the new appliance, then repeat the

process with a clean damp clothe and dry. (ENSURE THEAPPLIANCE IS NOT

CONNECTED TO THE POWER WHEN PERFORMING THIS TASK)

For Customer Services & Spare Parts please call 0845 208 8750 Opening times: Monday - Friday 8am –

6pm & Saturday 9am – 1pm or visit us at

www.productcareuk.com

Installing and Switching on the Appliance

•Operating voltage for your fridge is 220-240V at 50Hz.

•If you need help or are unsure how to install the unit, please contact Customer

Services on 0845 208 8750 or visit www.productcareuk.com.

•Before plugging in the power supply, ensure that the voltage on the nameplate

corresponds to the working voltage of your electrical system in your home.

•Insert the plug into an efficient Ground (Earth) connection. If the socket has no

Ground (Earth) contact or the plug does not match, we suggest you call an authorised

electrician for assistance.

•We do not take responsibility of the damages that occur due to Ungrounded (Un-

earthed) usage.

•Place your fridge in a place that is not exposed to direct sunlight.

•Your appliance should be placed at least 500 mm away from stoves, ovens and

other heating cores.

•It should never be used outdoors or left in the rain.

•When your fridge is placed next to a chest freezer or freezer, there should be at least

50 mm between them to prevent humidity on the outer surface.

•Do not place anything on your fridge and install your fridge in a suitable place so that

there is at least 300 mm clear above the appliance.

•If placing your fridge next to kitchen cabinets, leave 50 mm between them.

•The rear of the appliance should be at least 60 mm away from the back wall.

•The appliance must be used in the vertical position and on a flat surface. To level the

appliance use the adjustable foot on the front of the appliance.

•Do not place your appliance on a carpeted surface as this will prevent adequate

ventilation.

•Do not place hot food or containers in the fridge as this can damage your appliance.

For Customer Services & Spare Parts please call 0845 208 8750 Opening times: Monday - Friday 8am –

6pm & Saturday 9am – 1pm or visit us at

www.productcareuk.com

THEAPPLIANCE AND THE COMPARTMENTS

Parts may vary according to the appliance model.

1. Ice-cube compartment

2. Thermostat OFF 1 2 3 4 5 6

3. Upper hinge

4. Handle recess

5. Door shelves

6. Lower hinge

7. Driptray

8. Shelf

9. Adjustable foot

For Customer Services & Spare Parts please call 0845 208 8750 Opening times: Monday - Friday 8am –

6pm & Saturday 9am – 1pm or visit us at

www.productcareuk.com

USAGE INFORMATION

Thermostat Setting

•The thermostat automatically regulates the inside temperature of the refrigerator

compartment. By rotating the knob from position « 1 » to « 6 », colder

temperatures can be obtained. (1 being low and 6 being high)

•« 0FF » position shows thermostat is closed and no cooling is available.

•For short-term storage of food in the refrigerator compartment, you can set the

knob between minimum and medium position.(1-4)

•For long-term storage of food in the refrigerator compartment, you can set knob to

medium position.(4-6)

•Note that: the ambient temperature, (the temperature of the freshly stored food

and how often the door is opened) affects the temperature in the refrigerator

compartment. If required, change the temperature setting.

•When you first switch on the appliance, for starting suitable cooling, the appliance

should work 24 hours continuously until it cools down to sufficient temperature.

•During this time do not open the door frequently or place a lot of food inside

the appliance.

•If the unit is switched off or unplugged, you must allow at least 5 minutes before

restarting or re-plugged the unit in order not to damage the compressor.

Your fridge is designed to operate in the ambient temperature intervals stated in

the associated standards, according to the climate class stated on the information

label. We do not recommend operating your fridge out of stated temperatures,

value limits in terms of cooling effectiveness.

Climate Class

For Customer Services & Spare Parts please call 0845 208 8750 Opening times: Monday - Friday 8am –

6pm & Saturday 9am – 1pm or visit us at

www.productcareuk.com

CLEANING AND MAINTENANCE

•Disconnect the appliance from the power supply before cleaning.

•Do not pour water directly over or on the appliance.

•The refrigerator compartment should be cleaned periodically using a solution of

bicarbonate of soda and lukewarm water.

•Do not use abrasive products, detergents or soaps. After cleaning wipe down with a

damp clean clothe.

•Note: Reconnect to the power after you have dried your hands.

For Customer Services & Spare Parts please call 0845 208 8750 Opening times: Monday - Friday 8am –

6pm & Saturday 9am – 1pm or visit us at

www.productcareuk.com

IMPORTANT NOTES:

The cooling gas which circulates in the refrigerator circuit may make a slight

noise (bubbling sound) even when the compressor is not running. This is quite

normal. If these sounds are different check that ;

•The appliance is level.

•Nothing is touching the rear of the appliance.

If the problem persists after you have followed all the instructions above, please

consult Product Care on 0845 208 8750.

•Compressor protection function will be activated after sudden power breakdowns

or after unplugging the appliance, because the gas in the cooling system will

not have stabilized sufficiently. Your fridge will start after a short period of time, this

is quite normal.

•If you do not use your appliance for a long period of time (e.g. in summer holidays)

unplug it. Clean and leave the door open to prevent humidity and bad odours.

For Customer Services & Spare Parts please call 0845 208 8750 Opening times: Monday - Friday 8am –

6pm & Saturday 9am – 1pm or visit us at

www.productcareuk.com

Product Specification

• Energy efficiency performance rating: A+

• Energy consumption: 110kWh/year

• Net Fridge Capacity: 45 Litre / 1.59 cubic feet

• Noise level: 45dB

• Compartments, racks & shelving:

- 2 Fixed door racks

- 1 Removable wire shelf

• Reversible Door

• Adjustable thermostat

• Adjustable foot

• Dimensions (CMs): (H)49.2 x (W)47.2 x (D)45.0

Voltage: 220 – 240V

Frequency: 50Hz

Connection to the mains supply

For UK use only – Plug fitting details (where applicable):

As the colours of the wires in the mains lead of this appliance may not

correspond with the coloured markings identifying the terminals in your plug,

proceed as follows:

The GREEN/YELLOW wire is the EARTH and must be connected to the

terminal which is marked with the letter E or by the earth symbol or coloured

GREEN or

GREEN/YELLOW.

The BLUE wire is the NEUTRAL and must be connected to the

terminal marked with the letter N or coloured BLACK. The

BROWN wire is the LIVE wire and must be connected to the

terminal marked with the letter L or coloured RED.

Always ensure that the plug cord grip is fastened correctly.

If a 13A (BS1363) fused plug is used it must be fitted with a

13amp fuse conforming to BS1362 and be BSI or ASTA approved.

For Customer Services & Spare Parts please call 0845 208 8750 Opening times: Monday - Friday 8am –

6pm & Saturday 9am – 1pm or visit us at

www.productcareuk.com

Altri manuali per RHTTLF1

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Russell Hobbs Frigorifero

Russell Hobbs

Russell Hobbs RHTTLF1 Manuale utente

Russell Hobbs

Russell Hobbs 21270 Manuale utente

Russell Hobbs

Russell Hobbs RHLF1 Manuale utente

Russell Hobbs

Russell Hobbs RHTTLDR2 Manuale utente

Russell Hobbs

Russell Hobbs RHBU60LARDER-N Manuale utente

Russell Hobbs

Russell Hobbs RHBU60FRIDGE-N Manuale utente

Russell Hobbs

Russell Hobbs RH55UCLF4B Manuale utente

Russell Hobbs

Russell Hobbs RHUCLF55-H Manuale utente

Russell Hobbs

Russell Hobbs RHBI55177LF2 Manuale utente

Russell Hobbs

Russell Hobbs RH120 Manuale utente

Russell Hobbs

Russell Hobbs RHUCLF55(B) Manuale utente

Russell Hobbs

Russell Hobbs RH54FF170B Manuale utente

Russell Hobbs

Russell Hobbs RHUCF55-H Manuale utente

Russell Hobbs

Russell Hobbs RH55FF171-ML Manuale utente

Russell Hobbs

Russell Hobbs RH140 Manuale utente

Russell Hobbs

Russell Hobbs RH50FF145 Manuale utente

Russell Hobbs

Russell Hobbs RH48UCFF2 Manuale utente

Russell Hobbs

Russell Hobbs RH55FFWD180-M Manuale utente

Russell Hobbs

Russell Hobbs RHTTF67 Manuale utente

Russell Hobbs

Russell Hobbs RHTTF67B-LCK Manuale utente

Russell Hobbs

Russell Hobbs RHFR520MB-4D Manuale utente

Russell Hobbs

Russell Hobbs RH50FF144 Manuale utente

Russell Hobbs

Russell Hobbs RH55FF176W Manuale utente

Russell Hobbs

Russell Hobbs RHUCLF1 Manuale utente

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Samsung

Samsung RF323TE Manuale utente

Beko

Beko CSA31022 Manuale utente

IKEA

IKEA FROSTIG C 185 E Manuale utente

Electrolux

Electrolux ER 6821 D Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Beko

Beko LSP4579W Manuale utente
