Safetec 2510037 Manuale utente
Safetec offers a Manual Dispenser for Instant Hand Sanitizer; and
a Manual Dispenser for SaniWash Antimicrobial Hand Soap.
Safetec Manual Dispenser
Manual Dispenser
(Hand Sanitizer & Soap)
2510037
Front Back
This drip tray can be used on
the Manual Dispenser
The product also has adhesive placed
on the back to easily adhere to surfaces,
as an alternative to using screws
Drip Tray 2510122
Manual Dispenser
Industry Uses
Healthcare: Hospitals, physician's offices, labs, pharmacies, long-term care facitlites and etc.
Occupational Health & Safety: Government agencies, shipping facilities, schools, jan-san and etc.
Manual Dispenser
and Refill
34465
2510037
Item# Description Case Qty. Case Wt.
2510037 Manual Dispenser 12 per cs. tbd
17360 800ml Manual Dispenser Refill 12 per cs. 22 lbs.
2510122 Drip Tray 1 each tbd
• Kills 99.9% of germs (Active ingredient: 66.5% Ethyl Alcohol)
• Formula evaporates completely, leaving no sticky residue on hands
• Enriching aloe vera adds moisture with each use, increasing
skin hydration
Instant Hand Sanitizer (Fresh Scent)
Manual Dispenser
and Refill
2510037
17360
• Aids in reducing the risk of cross-contamination
• Colorless soap, with a mild pleasant fragrance
• Uses PCMX for antimicrobial action and contains
aloe vera for added moisture with each use
SaniWash®Antibacterial Hand Soap
Drip Tray
2510122
Drip Tray
2510122
Compliance
Meets OSHA, APIC and CDC hand washing recommendations
in the absence of soap and water
*Meets ADA operability
Item# Description Case Qty. Case Wt.
2510037 Manual Dispenser 12 per cs. tbd
34465 800ml Manual Dispenser Refill 12 per cs. 22 lbs
2510122 Drip Tray 1 each tbd
Compliance
Meets OSHA and APIC hand washing recommendations
*Meets ADA operability
Dispenser Instructions
to open and
close locking unit,
insert key in this
release button release buttons
screw mounting holes (5)
tape
mounting clearance,
1 1/2" minimum
Tape Mounting
1. Only recommended for mirrors or other similar flat surfaces
(Clean flat surface with towelette with an abraisive cleanser prior
to using towelette. Dry surface thoroughly)
2. Remove backing from tape and press firmly against mounting
surface for 10 seconds. Open cover and press directly on back
plate for additional 10 seconds. Allow 8 hours before loading unit.
3. Opening Instructions: Push up on two release buttons on each
side of base with thumb and forefinger. With other hand, gently
pull cover away from wall at top of dispenser.
(For locking units – insert provided key into keyhole in right-hand release
button and press upward; key must remain in keyhole while closing dispenser)
Manual Dispenser Mounting Instructions
1
Screw Mounting
1. Recommended for surfaces that are not ideal for Tape Mounting
2. Hold dispenser against wall in desired position, open cover and mark
screw hole location on wall, insuring screw heads will not interfere
with release bar.
3. Use appropriate anchors and drill size for #10 x 1" self-taping screws
to attach dispenser firmly to the wall.
2
Manual Dispenser Refill Instructions
Arc of Half Moon Pump
1. Press finger into perforated
area and remove key-hole
perforated shaped area.
2. Locate nozzle and pull down
through bottom of box.
3. Place cartridge on dispenser
platform. Pull nozzle with
thumb and forefinger to rotate
top of tub so Arc of Half Moon
Pump is facing toward you.
5. Before closing the cover,
check to make sure Arc of
Half Moon Pump is facing
toward you and Ears of Half
Moon Pump are firmly seated
in slots of lower locator.
Upper Locator
Ears of Half
Moon Pump
Lower Locator Slots
4. Place top of tube firmly
in neck of upper locator
and fit Ears of Half Moon
Pump into Lower Locator Slots.
Select your Dispenser
Manual Dispenser
(Hand Sanitizer & Soap)
2510037
1Choose your Refill
Hand Sanitizer
Manual Refill
17360
SaniWash Soap
Manual Refill
34465
2Add a Drip Tray
Drip Tray
2510122
This Drip Tray can be used on
the Manual Dispenser and is
a nice add-on feature.
Adhesive tabs on the back easily
adhere to surfaces, as an alternative
to using screws.
3
