the Barista Touch™

Instruction Book – SES880

SAGE®

RECOMMENDS

SAFETY FIRST

At Sage‰we are very safety

conscious. We design and

manufacture consumer

products with the safety of you,

our valued customer, foremost

in mind. In addition we ask

that you exercise a degree of

care when using any electrical

appliance and adhere to the

following precautions.

IMPORTANT

SAFEGUARDS

READ ALL

INSTRUCTIONS BEFORE

USE AND SAVE FOR

FUTURE REFERENCE

•Before using for the ﬁrst

time please ensure that

your electricity supply

is the same as shown

on the rating label on

the underside of the

appliance. If you have any

concerns please contact

your local electricity

company.

•Your Sage‰appliance

includes a BS 13 amp

moulded mains plug on

the supply cord.

•Should you need to

change this plug, please

complete the rewiring as

follows (after safe disposal

of the moulded plug).

•Please note that a cut off

plug inserted into a socket

is a serious danger risk.

2Sage®recommends safety ﬁrst

8Components

10 Features

12 Functions

18Tips

23 Care & Cleaning

27 Troubleshooting

Contents

•Wires are coloured as

follows:

−Blue = Neutral

−Brown = Live

−Green & Yellow = Earth

•As the colours of the wire

may not correspond with

the coloured markings

which identify the

terminals in

your plug, please refer to

the following:

−The Blue wire must

be connected to

the terminal which

is marked ‘N’.

−The Brown wire

must be connected

to the terminal

which is marked

with the letter ‘L’.

−The Green & Yellow

wire must be connected

to the terminal which is

marked with the letter E

or the earth symbol .

•Please note that if a 13

amp plug is used, a 13

amp fuse should be used.

•To eliminate a choking

hazard for young children,

remove and safely discard

the protective cover ﬁtted

to the power plug of this

appliance.

•Do not place the Barista

Touch™ near the edge of

a bench or table during

operation. Ensure the

surface is level, clean and

free of water and other

substances.

•Do not use the Barista

Touch™ on a sink drain

board.

•Do not place the Barista

Touch™ on or near a hot

gas or electric burner, or

where it could touch a

heated oven.

•Always ensure the Barista

Touch™ is properly

assembled before

connecting to power

outlet and operating.

Follow the instructions

provided in this book.

•The appliance is not

intended to be operated

by means of an external

timer or separate remote

control system.

•Do not use attachments

other than those provided

with the Barista Touch™.

•Do not attempt to operate

the Barista Touch™ by any

method other than those

described in this book.

•Do not operate the

grinder without the

hopper lid in position.

Keep ﬁngers, hands, hair,

clothing and utensils away

from the hopper during

operation.

•Use only cold, tap water in

the water tank. Do no use

any other liquid.

•Never use the Barista

Touch™ without water in

the water tank.

•Ensure the portaﬁlter

is ﬁrmly inserted and

secured into the brewing

head before using the

machine.

•Never remove the

portaﬁlter during the

brewing operation as

the machine is under

pressure.

•Do not move the Barista

Touch™ whilst in

operation.

•Do not leave the Barista

Touch™ unattended when

in use.

•Do not touch hot surfaces.

Allow the Barista Touch™

to cool down before

moving or cleaning any

parts.

•Do not place anything,

other than cups for

warming, on top of the

Barista Touch™.

•Always switch off the

Barista Touch™ by

pressing the POWER

button to ‘Off’, switch

off at the power outlet

and unplug if appliance

is to be left unattended,

if not in use, before

cleaning, before

attempting to move the

appliance, disassembling,

assembling and when

storing the appliance.

•This appliance shall not

be used by children.

Keep the appliance and

its cord out of reach of

children. Appliances can

be used by persons with

reduced physical, sensory

or mental capabilities or

lack of experience and

knowledge if they have

been given supervision

or instruction concerning

use of the appliance in

a safe way and if they

understand the hazards

involved.

•Keep the appliance and

accessories clean. Follow

the cleaning instructions

provided in this book.

SPECIFIC

INSTRUCTIONS

FOR WATER

FILTER

•Filter cartridge should

be kept out of reach of

children.

•Store ﬁlter cartridges in

a dry place in the original

packaging.

•Protect cartridges from

heat and direct sunlight.

•Do not use damaged ﬁlter

cartridges.

•Do not open ﬁlter

cartridges.

•If you are absent for a

prolonged period of time,

empty the water tank and

replace the cartridge.

•Children should be

supervised to ensure

they do not play with the

appliance.

•It is recommended to

regularly inspect the

appliance. Do not use the

appliance if power cord,

power plug or appliance

becomes damaged in

any way. If damaged or

maintenance other than

cleaning is required,

please contact Sage®

Customer Service or go

to sageappliances.com.

•Any maintenance, other

than cleaning, should

be performed at an

authorised Sage®Service

Centre.

•This appliance is

recommended for

household use only.

•Heating element surface

is subject to residual heat

after use.

•Do not use this appliance

for anything other than its

intended use.

IMPORTANT

SAFEGUARDS

FOR ALL

ELECTRICAL

APPLIANCES

•Unwind the power cord

fully before use.

•Do not let the power cord

hang over the edge of

a bench or table, touch

hot surfaces, or become

knotted.

•To protect against electric

shock do not immerse

power cord, power plug or

appliance in water or any

other substance.

•This appliance is not

intended for use by

persons (including

children) with reduced

physical, sensory or mental

capabilities, or lack of

experience or knowledge,

unless they have been

given supervision or

instruction concerning

use of the appliance by

a person responsible for

their safety.

•Do not use in moving

vehicles or boats. Do not

use outdoors. Misuse may

cause injury.

•The installation of

a residual current

device (safety switch)

is recommended to

provide additional safety

protection when using

electrical appliances.

It is advisable that a

safety switch with a rated

residual operating current

not exceeding 30mA be

installed in the electrical

circuit supplying the

appliance.

See your electrician for

professional advice.

WARNING

Fully unwind the cord

before use.

SAVE THESE INSTRUCTIONS

The symbol shown

indicates that this

appliance should not

be disposed of in normal

household waste. It should

be taken to a local authority

waste collection centre

designated for this purpose

or to a dealer providing

this service. For more

information, please contact

your local council ofﬁce.

WARNING

To protect against

electric shock do not

immerse the power plug,

cord or appliance

in water or any liquid.

Components

A. 250g bean hopper

With locking system for easy removal,

storage and transfer of coffee beans.

B. Integrated conical burr grinder

C. Touch screen control panel

Displays current settings and provides

touch interface.

D. GRIND SIZE selector

Espresso grind settings from ﬁne to coarse.

E. POWER button

F. Integrated removable 54mm tamper

G. Grind outlet

H. Hands free grinding cradle

I. 54mm stainless steel portaﬁlter

With commercial style spouts.

J. Removable wet & dry coffee Separator

drip tray

With Empty Me! tray full indicator.

K. 2L removable water tank

With replaceable water ﬁlter to reduce

impurities and scale.

L. Group Head

M. Dedicated hot water outlet

N. Extra-tall cup clearance for tall mugs

O. Easy clean steam wand

For automatic milk texturing.

P. Milk temperature sensor

Q. Storage tray (located behind drip tray)

Houses accessories when not in use.

ACCESSORIES

1. Stainless steel milk jug

2. Cleaning disc

3. Cleaning tablets

4. Dual Wall ﬁlter baskets (1 cup & 2 cup)

Use with pre-ground coffee.

5. Single Wall ﬁlter baskets (1 cup & 2 cup)

Use when grinding fresh whole coffee

beans.

All parts of the Barista Touch™

that come into contact with coffee,

water and milk are BPA Free.

7 8 9

4 5

6. Water ﬁlter and holder

7. Cleaning brush

8. The Razor™ precision dose trimming tool

9. Steam wand cleaning tool

10.Water hardness test strip

Rating Information

220–240V~ 50–60Hz 1380–1650W

COLOUR TOUCH SCREEN

CONTROL PANEL

Swipe & Select from the drinks menu.

Adjust your shot volume, milk texture or milk

temperature, then save it as your personal

favourite.

AUTOMATIC HANDS FREE MILK

TEXTURING

Automatically textures milk to the selected

temperature and style from silky smooth

latté to creamy cappuccino. Automatic purge

removes residual milk from the steam wand

when returned to the downward position.

RAPID HEAT UP

Innovative heating system achieves ideal

extraction temperature in 3 seconds.

INTEGRATED CONICAL

BURR GRINDER

Stainless steel conical burrs maximise ground

coffee surface area for a full espresso ﬂavour.

Upper and lower burrs are removable

for cleaning.

ADJUSTABLE GRIND SIZE

Espresso grind settings from ﬁne to coarse

for optimal extraction.

ADJUSTABLE GRIND AMOUNT

Adjust the amount of fresh ground coffee

dosed into the ﬁlter basket to suit the ﬁneness

or coarseness of the grind.

AUTOMATIC DOSING

Use the FILTER SIZE button to tell the

machine if you are using a 1 CUP or 2 CUP

ﬁlter basket. The grinder will dispense the

required amount of ground coffee for a single

or double cup dose.

HANDS FREE GRINDING

Auto stop for hands free grinding directly into

the portaﬁlter.

THE RAZOR™ DOSE

TRIMMING TOOL

Patented twist blade trims down the puck

to the right level for precision dosing

and a consistent extraction.

ADJUSTABLE TEMPERATURE

CONTROL

For optimum coffee ﬂavour.

PID TEMPERATURE CONTROL

Electronic PID temperature control for

increased temperature stability.

INSTANT HOT WATER

Dedicated hot water outlet for making

Long Blacks and pre-heating cups.

LOW PRESSURE PRE-INFUSION

Applies low water pressure at the start

of the extraction to gently expand grinds

for an even extraction.

VOLUMETRIC CONTROL

Preset 1 & 2 cup volumes, manual over-ride

or programmable shot volumes.

DRY PUCK FEATURE

Removes excess water from the ground coffee

in the ﬁlter basket after extraction for easy

disposal of the coffee puck.

Barista Touch

Features

Altri manuali per Barista Touch SES880

Indice

Altri manuali Sage Macchina per il caffè

Sage

Sage the Bambino BES450 Manuale utente

Sage

Sage Barista Express BES875 Manuale utente

Sage

Sage Smart Grinder Pro Manuale utente

Sage

Sage Barista Touch Impress Manuale utente

Sage

Sage Oracle Touch SES990 Manuale utente

Sage

Sage Bambino Plus SES500 Manuale utente

Sage

Sage Nespresso Creatista Uno Manuale utente

Sage

Sage Bambino Plus Manuale utente

Sage

Sage Oracle Touch Manuale utente

Sage

Sage Barista Express BES875 Manuale utente

Sage

Sage Barista Express SES870 Manuale utente

Sage

Sage the Barist Express SES875 Manuale utente

Sage

Sage Oracle Touch SES990 Manuale utente

Sage

Sage Barista Touch BES880 Manuale utente

Sage

Sage Barista Express Impress BES876 Manuale utente

Sage

Sage the Dual Boiler BES920 Manuale utente

Sage

Sage Dual Boiler SES920 Manuale utente

Sage

Sage the Barista Pro BES878 Manuale utente

Sage

Sage Barista Touch SES880BSS Manuale utente

Sage

Sage SES990BTR Manuale utente

Sage

Sage BES980UK Manuale utente

Sage

Sage Oracle SES980 Manuale utente

Sage

Sage Precision Brewer SDC400 Manuale utente

Sage

Sage the Bambino SES450 Manuale utente

Manuali Macchina per il caffè popolari di altre marche

Taurus

Taurus Livorno 6 Manuale utente

Delta-q

Delta-q QUICK Manuale utente

Bunn

Bunn LCA-1 Guida alla risoluzione dei problemi

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Istruzioni per l'installazione

Saeco

Saeco Vienna Plus Sup 018M Manuale utente

DeLonghi

DeLonghi DC300 Manuale utente

INCAPTO

INCAPTO BXCO1470E Manuale utente

Bosch

Bosch TASSIMO finesse TAS16B Series Manuale utente

Exido

Exido 245-072 Manuale utente

Animo

Animo OptiVend Choco Manuale utente

Siemens

Siemens TQ505DF Series Manuale utente

DeLonghi

DeLonghi ECI341 Manuale utente

Krups

Krups KT406511 Manuale utente

Cimbali

Cimbali M32 Classic Manuale utente

Philips

Philips HL3844N Manuale utente

Bosch

Bosch TES 515 SERIES Manuale utente

Tekmatix

Tekmatix TMFM - 65 Manuale utente

Scarlett

Scarlett SC-CM33005 Manuale utente
