Samsung M337 Manuale utente

BASIC

User’s Guide

BASIC

User’s Guide

This guide provides information concerning installation, basic operation and

troubleshooting on windows.

ADVANCED

This guide provides information about installation, advanced configuration, operation and

troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

BASIC

1. Introduction

Key benefits 5

Features by models 8

Useful to know 13

About this user’s guide 14

Safety information 15

Machine overview 20

Control panel overview 23

Turning on the machine 27

Installing the driver locally 28

Reinstalling the driver 30

2. Menu Overview and Basic Setup

Menu overview 32

Machine’s basic settings 45

Media and tray 47

Basic printing 62

Basic copying 70

Basic scanning 75

Basic faxing 76

Using USB memory device 81

3. Maintenance

Ordering supplies and accessories 89

Available consumables 90

Available accessories 91

Storing the toner cartridge 92

Redistributing toner 94

Replacing the toner cartridge 97

Replacing the imaging unit 100

Installing accessories 101

Monitoring the supplies life 105

Setting the toner low alert 106

Cleaning the machine 107

Tips for moving & storing your machine 113

4. Troubleshooting

Tips for avoiding paper jams 115

Clearing jams 116

Understanding the status LED 134

Understanding display messages 137

BASIC

5. Appendix

Specifications 144

Regulatory information 152

1. Introduction

This chapter provides information you need to know before using the machine.

•Keybenefits 5

• Features by models 8

• Useful to know 13

• About this user’s guide 14

• Safety information 15

• Machine overview 20

• Control panel overview 23

• Turning on the machine 27

• Installing the driver locally 28

• Reinstalling the driver 30

Key benefits

Environmentally friendly

• To save toner and paper, this machine supports Eco feature (see "Eco

printing" on page 66).

• To save paper, you can print multiple pages on one single sheet of paper

(see "Using advanced print features" on page 270).

• To save paper, you can print on both sides of the paper (double-sided

printing) (see "Using advanced print features" on page 270).

• To save electricity, this machine automatically conserves electricity by

substantially reducing power consumption when not in use.

• We recommend using recycled paper for saving energy.

Fast high resolution printing

• You can print with a resolution of up to 1,200 x 1,200 dpi effective output

(1,200 x 600 x 2 bit).

• Fast, on-demand printing.

- M337x series

▪For single-side printing, 33 ppm (A4) or 35 ppm (Letter).

- M387x series

▪For single-side printing, 38 ppm (A4) or 40 ppm (Letter).

- M407x series

▪For single-side printing, 40 ppm (A4) or 42 ppm (Letter).

Convenience

• You can print on the go from your smartphone or computer using Google

Cloud Print™ enabled apps (see "Google Cloud Print™" on page 217).

• Easy Capture Manager allows you to easily edit and print whatever you

captured using the Print Screen key on the keyboard (see "Easy Capture

Manager" on page 313).

Key benefits

• Samsung Easy Printer Manager and Printing Status is a program that

monitors and informs you of the machine’s status and allows you to

customize the machine’s settings (see "Using Samsung Printer Status" on

page 324 or "Using Samsung Easy Printer Manager" on page 321).

• Samsung Easy Document Creator is an application to help users scan,

compile, and save documents in multiple formats, including .epub format.

These documents can be shared via social networking sites or fax (see

"Using Samsung Easy Document Creator" on page 320).

• AnyWeb Print helps you screen-capture, preview, scrap, and print the

screen of Windows Internet Explorer more easily than when you use the

ordinary program (see "Samsung AnyWeb Print" on page 314).

• Smart Update allows you to check for the latest software and install the

latest version during the printer driver installation process. This is available

only for Windows.

• If you have Internet access, you can get help, support application, machine

drivers, manuals, and order information from the Samsung website,

www.samsung.com > find your product > Support or Downloads.

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 146).

• Print watermark: You can customize your documents with words, such as

“Confidential” (see "Using advanced print features" on page 270).

• You can print in various operating systems (see "System requirements" on

page 148).

• Your machine is equipped with a USB interface and/or a network interface.

Supports various wireless network setting method

• Using the WPS (Wi-Fi Protected Setup™) button

- You can easily connect to a wireless network using the WPS button on

the machine and the access point (a wireless router).

• Using the USB cable or a network cable

- You can connect and set various wireless network settings using a USB

cable or a network cable.

• Using the Wi-Fi Direct

- You can conveniently print from your mobile device using the Wi-Fi or

Wi-Fi Direct feature.

See "Introducing wireless set up methods" on page 191.

Key benefits

Support XOA applications (M407xFX only)

The machine supports XOA custom applications.

• Regarding the XOA custom applications, please contact your XOA custom

application provider.

Features by models

Some features and optional goods may not be available depending on model or country.

Operating System

(●: Included, Blank: Not available)

Software

You can install the printer driver and software when you insert the software CD into your CD-ROM drive. For windows, select the printer driver and software

in the Select Software to Install window.

Operating System M337x series M387x series M407x series

Windows ● ● ●

Mac ● ● ●

Linux ● ● ●

Unix ● ● ●

Software M337x series M387x series M407x series

SPL printer driver ● ● ●

PCL printer driver ● ● ●

PS printer drivera● ● ●

XPS printer drivera● ● ●

Direct Printing Utilitya● ● ●

Samsung Easy

Printer Manager

Scan to PC Settings ● ● ●

Fax to PC Settings ● ● ●

Device Settings ● ● ●

Samsung Printer Status ● ● ●

Samsung AnyWeb Printa● ● ●

Samsung Easy Document Creator ● ● ●

Features by models

(●: Included, Blank: Not available)

Easy Capture Manager ● ● ●

SyncThru™ Web Service ● ● ●

SyncThru Admin Web Service ●●●

Easy Eco Driver ● ● ●

Fax Samsung Network PC Fax ● ● ●

Scan Twain scan driver ● ● ●

WIA scan driver ● ● ●

a. Download the software from the Samsung website and install it: (http://www.samsung.com > find your product > Support or Downloads). Before installing,

check whether your computer’s OS support the software.

Software M337x series M387x series M407x series

Features by models

Various features

Features M337x series M387x series M407x series

Hi-Speed USB 2.0 ● ● ●

Network Interface Ethernet 10/100 Base TX wired LAN ●●

Network Interface Ethernet 10/100/1000 Base TX wired LAN ●

IEEE 1284B parallel connectora○ ○ ○

Network Interface 802.11b/g/n wireless LANb●

(M387xFW only)

Google Cloud Print™ ●●●

AirPrint ●●●

Eco printing ●●●

Duplex (2-sided) printing ● ● ●

USB memory interface ● ●

Memory module ○ ○ ○

Optional tray (Tray2) ○ ○ ○

Mass Storage Device

Document

Feeder

Duplex Automatic Document Feeder (DADF) ●

(M387xFW only)

●

(M407xFR/M407xHR/M407xFX

only)

Automatic Document Feeder (ADF) ● ●

(M387xFD/M387xHD only)

●

(M4072FD only)

Handset ●

(M337xHD only)

●

(M387xHD only)

●

(M407xHR only)
