Samsung MFP SCX-6345N Manuale utente

Samsung MFP SCX-6345N

Digital Copier | Network Printer | Colour Scanner | Network Fax

imagine an office solution capable

of the highest workflow demands

Take a look at this one-stop digital solution that can manage your

entire printing workflow. An MFP copier that can match the output of

large contract-based A3 copiers, and can also scan, print and fax.

Add in high performance features like duplex, high capacity paper

trays and simple one touch operations and you have a solution capa-

ble of the highest workflow demands. With Samsung SCX-6345N, it's

not that hard to imagine.

04 Quick Overview

06 Product Concept & Positioning

07 Product Configuration

08 Why A4 Copier?

09 Why SCX-6345N?

10 Because it is Effortless

12 Because it is Effective

17 Because it is Economical

18 Because it is Enhanced

22 Samsung Printers Service

24 Product Line-up

28 Options & Supplies

30 Specifications

Quick Overview

Standard Features

• 43cpm Copier Based MFP

• 2 Beam Laser Scanning Unit and Electro Photography

• 50 Sheet Duplex-ADF

• Duplex Copy / Print

• Ethernet 10/100 base TX

• Half VGA size touch screen pannel

• JAM-Trouble Shooting Animation Guide

• FCOT Less than 6.0 seconds

• 256MB memory (max 384MB available)

• 45ppm digital scanning speed at 600dpi

• 1-999 multiple copying (number keypad)

• 550-sheet cassette & 100 by pass tray

• Digital copier features such as Scan-Once - Copy-Many / ID Copying / Legal Size / Standard Duplex /

Auto-fit / Clone / Poster / N-up (up to 16) / Margin Shift / Book copy / Auto Suppress / Outline erased /

Cover / Transparent film / Booklet

• Internal 40Gbyte HDD

• Colour CCD Scan Type

• Standard PCL6, PostScript3 Emulation

• Foreign Device Interface

Optional Features

• Maximum 2,180-sheet input paper capacity

• Finisher (50-sheet stapler, offset catching)

• Maximum 384Mbyte Memory Capacity

• Colour Fax (If receiver’s fax available)

• Duplex Transmission and 2-sided printing

• JBIG Data Compression Method

• Super G3 Facsimile

• Advanced Fax Communication such as Secure Fax / Delay Fax / Toll-Saving Fax /

Priority Fax / Batch TX / Fax Forwarding / ECM (Error Correction Mode)

• Network Scan Kit Enable Kit

Product Concept & Positioning

Concept

Samsung Digital Multi Function Printer | 4+ 5

Product Concept

The SCX-6345N has been developed to expand Samsung’s copier-based

Laser MFP Line-up with SCX-6322DN/6122FN. In addition, this model is

designed to make inroads into A3 Copier markets.

The SCX-6345N fits into the general office environments, whatever the

department. As it comes with 43 PPM speed, an embedded network

card, Scalable paper handling Capacity(Max 2180 Sheet capacity), Simple

Finisher with staple and collation(Optional), Wide Touch Screen Panel,

network scan function that supports various OS, and device manage-

ment tool without installation, it can be easily installed in

any network environment. In the past, the entire office

had to use one centralized device. The needs of the

office environment have been changing and today

people what efficient and easy-to-use networked

multi-function product functionality.

Customers today will no longer hesitate to buy new Laser

MFPs because they are now more efficient and offer high per-

formance with economic device maintenance cost.

The Samsung SCX-6345N has a lower TCO and an easy to use

interface that can replace centralized A3 copiers in the office.

Moreover, one centric A3 copier can be easily replaced by one or more

SCX-6345N.

Product Positioning

Product Positioning Strategies

A) Cost Efficiency Approach

This A) positioning is based on speed and allows a much improved approach on cost efficiency. In this case the SCX-6345N has

advantages in Total Cost of Ownership.

B) Performance Efficiency approach

On the other hand, when applying the B) positioning the performance-efficiency can be promoted thanks to its various features

including speed.

All prices in this part are US retail averages price (June 2006)

Type

Benefit

Better Cost

- Lower Purchasing Cost

- Better TCO

- Easy to Install & Maintenance

Better Performance

- Speed : Copy and Print

- Easy to Use : User Interface

A - Positioning B - Positioning

Product Configuration

Configuration

Standard Feature

Optional Feature

SCX-6345N

• Printing Resolution : 600 x 600 dpi ( 1200 dpi class )

• Internal HDD : 40 GB Capacity

• Wide Touch Screen Panel (640 x 240)

• 50-sheet Duplex Auto Document Feeder Standard

• Standard Paper Cassettes (250 sheets)

• USB 2.0 & Ethernet 10/100 base TX

(SCX-D6345A) 20K

Toner

(SCX-R6345A) 60K

Drum

Optional Finisher Short StandOptional Cassette

SCX-DSK10S

Tall Stand

SCX-DSK10TSCX-S6345A

SCX-FIN10S

FDI Kit

SCX-KIT11S

N/W Scan Kit Optional Fax KitOptional Fax Kit

SCX-FAX101

Memory

256 MB MemorySCX-FAX100

SCX-FIN10S

Staple Cartridge

SCX-6320NA

Samsung Mono Laser MFP SCX-6345N

Just unpack and

get to work in no time!

1 Optional Cassette

520 sheets

Max 3 Optional Cassette

520 sheets X 3

Trays can be

interchangeable

Atype

Btype

Samsung Digital Multi Function Printer | 6+ 7

Positioning Configuration

The SCX-6345N is a digital multifunctional system designed as a console unit. It is ready for external expansion with vertical additions of paper-handling options.

In the past customers always considered they needed an A3 Copier However,

according to a recent report *, just 2.35% of the total page volume printed is on

A3 paper. Given that the average office worker produces 8,636 pages a year,

just 202 pages are A3, which is less than a page a day. Because people are

moving towards scanning and printing original documents, which can be

scaled to fit the paper size available, the need for A3 output has declined. In

addition, a few years ago there was no software such as Microsoft Office,

Acrobat Reader and several types of Internet Browsers. Just think. When is

the last time you copied or printed on an A3 Copier?

Office space is also a big issue. In general, A3 centric copiers

occupy more office space. Typically, the footprint of a mono A3

capable device is much larger than that of an A4 device, 70%*

larger by volume on average. An A3 device takes up a lot

of space with its console. But an A4 device only

needs the corner of your desk or room.

In terms of TCO then generally,

the A3 copier is more expensive

to purchase and maintain than an

A4 MFP. The premium is between

100% and 220%* depending on the man-

ufacturer. Also the cost of a maintenance

kit for an A3 copier is 26%* higher than

that of an A4.

Finally, an A3 capable MFP device

consumes more operating power

and cost as the fuser unit is 41%

larger.

It doesn’t matter if an A4 page is being

printed or an A3 page because the whole

fuser unit is heated up.

*Source:

UK Research Study 2006

“NewField IT” Report

Samsung Mono Laser MFP SCX-6345N

Why A4 Copier?

Because it is Enhanced

Because it is Economical

Because it is Effortless

Why choose the Samsung SCX-6345N among the many other A4 MFPs? In addition to its economical features

and A4 copying/printing capability, this model offers simple user interface and easy administration tool, mean-

ing that users don’t have to study in great detail the User’s Manual and IT managers don’t have to spend too

much time monitoring the device. The SCX-6345N can drastically decrease the cost of maintenance.

Because it is Effective

Samsung Digital Multi Function Printer | 8+ 9

Why SCX-6345N?

Effortless

Because it is Effortless

Keyboard Network Scan

Main Menu Copy Setting Admin Setting

to Use

• Wide Touch Screen/UI design

Samsung’s exclusive 640 x 240 wide LCD touch screen and 3-dimen-

tional UI design can help users make selection simple and reduces time

spent learning user manuals and educating new staff members.

• Paper Handling

Additional paper trays can be added to provide up to 2,180 sheets of

paper on line, reducing the need to frequently refill with paper .

Also print job rescheduling manages the printing jobs based on FIFO

(First In First Out) order. So when the previous printing job mismatches

the property of the paper the next job can continue to print so reducing

working time and running on the system.

50-sheet DADF

100-sheet Bypass Tray

520-sheet CST Tray

520-sheet 2

CST

Tray (Option)
