Samsung SCX-3405W Manuale utente

Installing driver over the network

151

2. Using a Network-Connected Machine

On some UNIX OS, for example on Solaris 10, just added printers may not be

enabled and/or may not accept jobs. In this case run the following two

commands on the root terminal:

“accept <printer_name>”

“enable <printer_name>”

Uninstalling the printer driver package

The utility should be used to delete the printer installed in the system.

a Run “uninstallprinter” command from the terminal.

It will open the Uninstall Printer Wizard.

The installed printers are listed in the drop-down list.

b Select the printer to be deleted.

c Click Delete to delete the printer from the system.

d Execute the “. /install –d” command to uninstall the whole package.

e To verify removal results, execute the “. /install –c” command.

To re-install it, use the command “. /install” to reinstall the binaries.

Setting up the printer

To add the printer to your UNIX system, run ‘installprinter’ from the command

line. This will bring up the Add Printer Wizard window. Setup the printer in this

window according to the following steps:

1Type the name of the printer.

2 Select the appropriate printer model from the model list.

3 Enter any description corresponding to the type of the printer in the

Type field. This is optional.

4 Specify any printer description in the Description field. This is optional.

5 Specify the printer location in the Location field.

6 Type the IP address or DNS name of the printer in the Device textbox for

network-connected printers. On IBM AIX with jetdirect Queue type,

only the DNS name is possible-numeric IP address is not allowed.

7 Queue type shows the connection as lpd or jetdirect in the

corresponding list box. Additionally, usb type is available on Sun Solaris

OS.

8 Select Copies to set the number of copies.

9 Check the Collate option to receive copies already sorted.

10 Check the Reverse Order option to receive copies in the reverse order.

Installing driver over the network

152

2. Using a Network-Connected Machine

11 Check the Make Default option to set this printer as default.

12 Click OK to add the printer.

153

2. Using a Network-Connected Machine

IPv6 configuration

IPv6 is supported properly only in Windows Vista or higher.

• Some features and optional goods may not be available depending on

model or country (see "Features by models" on page 7 or "Menu

overview" on page 33).

• If the IPv6 network seems to not be working, set all the network setting

to the factory defaults and try again using Clear Setting.

In the IPv6 network environment, follow the next procedure to use the IPv6

address.

From the control panel

1Connect your machine to the network with a network cable.

2 Turn on the machine.

3 Print a Network Configuration Report that will check IPv6 addresses

(see "Printing a network configuration report" on page 141).

4 Select Start > Control Panel > Printers and Faxes.

5 Click Add a printer in the left pane of the Printers and Faxes windows.

6 Click Add a local printer in the Add Printer windows.

7 The Add Printer Wizard window appears. Follow the instructions in the

window.

If the machine does not work in the network environment, activate IPv6.

Refer to the next section followed by.

Activating IPv6

1Press the (Menu) button on the control panel.

2 Press Network > TCP/IP (IPv6) > IPv6 Activate.

3 Select On and press OK.

4 Turn the machine off and turn it on again.

5 Reinstall your printer driver.

IPv6 configuration

154

2. Using a Network-Connected Machine

Setting IPv6 addresses

The machine supports the following IPv6 addresses for network printing and

managements.

•Link-local Address: Self-configured local IPv6 address (Address starts with

FE80).

•Stateless Address: Automatically configured IPv6 address by a network

router.

•Stateful Address: IPv6 address configured by a DHCPv6 server.

•Manual Address: Manually configured IPv6 address by a user.

DHCPv6 address configuration (Stateful)

If you have a DHCPv6 server on your network, you can set one of the following

options for default dynamic host configuration.

1Press the (Menu) button on the control panel.

2 Press Network > TCP/IP (IPv6) > DHCPv6 Config.

3 Press OK to select the required value you want.

•DHCPv6 Addr.: Always use DHCPv6 regardless of router request.

•DHCPv6 Off: Never use DHCPv6 regardless of router request.

•Router: Use DHCPv6 only when requested by a router.

From the SyncThru™ Web Service

For models that do not have the display screen on the control panel, you

need to access SyncThru™ Web Service first using the IPv4 address and

follow the below procedure to use IPv6.

1Access a web browser, such as Internet Explorer, from Windows.GEnter

the machine IP address (http://xxx.xxx.xxx.xxx) in the address field and

press the Enter key or click Go.

2 If it’s your first time logging into SyncThru™ Web Service you need to

log-in as an administrator. Type in the below default ID and password.

•ID: admin

•Password: sec00000

3 When the SyncThru™ Web Service window opens, move the mouse

cursor over the Settings of the top menu bar and then click Network

Settings.

4 Click TCP/IPv6 on the left pane of the website.

5 Check the IPv6 Protocol check box to activate IPv6.

6 Check the Manual Address check box. Then, the Address/Prefix text

box is activated.

IPv6 configuration

155

2. Using a Network-Connected Machine

7 Enter the rest of the address (e.g.,:3FFE:10:88:194::AAAA. “A” is the

hexadecimal 0 through 9, A through F).

8 Choose the DHCPv6 configuration.

9 Click the Apply button.

Using SyncThru™ Web Service

1Start a web browser, such as Internet Explorer, that supports IPv6

addressing as a URL.

2 Select one of the IPv6 addresses (Link-local Address, Stateless

Address, Stateful Address, Manual Address) from Network

Configuration Report (see "Printing a network configuration report" on

page 141).

3 Enter the IPv6 addresses (e.g.,: http://[FE80::215:99FF:FE66:7701]).

Address must be enclosed in '[ ]' brackets.

156

2. Using a Network-Connected Machine

Wireless network setup

• Make sure your machine supports wireless networking. Wireless

networking may not be available depending on the model (see "Features

by models" on page 7).

• If the IPv6 network seems to not be working, set all the network settings

to the factory defaults and try again using Clear Setting.

Getting started

Understanding your network type

Typically, you can only have one connection between your computer and the

machine at a time.

Wireless network name and network key

Wireless networks require higher security, so when an access point is first set up,

a network name (SSID), the type of security used, and a Network Key are created

for the network. Ask your network administrator about this information before

proceeding with the machine installation.

Infrastructure mode

This is an environment generally used for homes and SOHOs

(Small Office/ Home Office). This mode uses an access point to

communicate with the wireless machine.

Ad hoc mode

This mode does not use an access point. The wireless

computer and wireless machine communicate directly.

Wireless network setup

157

2. Using a Network-Connected Machine

Introducing wireless set up methods

You can set wireless settings either from the machine or the computer. Choose the setting method from the below table.

Some wireless network installation types may not be available depending on the model or country.

Set up method Connecting method Description & Reference

From the machine’s

control panel

Using the WPS (recommended)

()

• See "Machines with a display screen" on page 160.

• See "Machines without a display screen" on page 161.

Using the menu button

()

• See "Using the menu button" on page 162.

Wireless network setup

158

2. Using a Network-Connected Machine

If problems occur during wireless set up or driver installation, refer to the troubleshooting chapter (see "Troubleshooting" on page 185).

From the computer

Access point via USB cable (recommended)

()

• Windows user, see "Access point via USB cable" on page 163.

• Macintosh user, see "Access point via USB cable" on page 172.

Access point via WPS button (without a USB cable

connection)

( , )

• Windows user, see "Access point via WPS button (without a USB cable connection)"

on page 167.

• Macintosh user, see "Setting the access point using the WPS button" on page 176.

Ad hoc via USB cable

()

• Windows user, see "Ad hoc via USB cable" on page 169.

• Macintosh user, see "Ad hoc via USB cable" on page 178.

Using a network cable • See "Using a network cable" on page 180.

Other set up methods Setting the Wi-Fi Direct for mobile printing • See "Setting up Wi-Fi Direct" on page 183.

Set up method Connecting method Description & Reference

Wireless network setup

159

2. Using a Network-Connected Machine

Using the WPS button

If your machine and an access point (or wireless router) support Wi-Fi Protected

Setup™ (WPS), you can easily configure the wireless network settings by

pressing the (WPS) button on the control panel without a computer.

• If you want to use the wireless network using the infrastructure mode,

make sure that the network cable is disconnected from the machine.

Using the WPS (PBC) button or entering the PIN from the computer to

connect to the access point (or wireless router) varies depending on the

access point (or wireless router) you are using. Refer to the user's guide

of the access point (or wireless router) you are using.

• When using the WPS button to set the wireless network, security settings

may change. To prevent this, lock the WPS option for the current wireless

security settings. The option name may differ depending on the access

point (or wireless router) you are using.

Items to prepare

• Check if the access point (or wireless router) supports Wi-Fi Protected

Setup™ (WPS).

• Check if your machine supports Wi-Fi Protected Setup™ (WPS).

• Networked computer (PIN mode only)

Choosing your type

There are two methods available to connect your machine to a wireless network

using the (WPS) button on the control panel.

The Push Button Configuration (PBC) method allows you to connect your

machine to a wireless network by pressing both the (WPS) button on the

control panel of your machine and the WPS (PBC) button on a Wi-Fi Protected

Setup™ WPS-enabled access point (or wireless router) respectively.

The Personal Identification Number (PIN) method helps you connect your

machine to a wireless network by entering the supplied PIN information on a Wi-

Fi Protected Setup™ WPS-enabled access point (or wireless router).

Factory default in your machine is PBC mode, which is recommended for a

typical wireless network environment.

You can change the WPS mode in control panel ( (Menu) > NetworkG>G

Wireless > OK > WPS Setting).

Wireless network setup

160

2. Using a Network-Connected Machine

Machines with a display screen

Connecting in PBC mode

1Press and hold the (WPS) button on the control panel for more than

2 seconds.

The machine starts waiting for up to two minutes until you press the WPS

(PBC) button on the access point (or wireless router).

2 Press the WPS (PBC) button on the access point (or wireless router).

The messages are displayed on the display screen in the order below:

a Connecting: The machine is connecting to the access point (or

wireless router).

b Connected: When the machine is successfully connected to the

wireless network, the WPS LED light stays on.

c AP SSID: After completing the wireless network connection process,

the AP’s SSID information appears on the display.

Connecting in PIN mode

1Press and hold the (WPS) button on the control panel for more than

2 seconds.

2 The eight-digit PIN appears on the display.

You need to enter the eight-digit PIN within two minutes on the

computer that is connected to the access point (or wireless router).

The messages are displayed on the display screen in the order below:

a Connecting: The machine is connecting to the wireless network.

b Connected: When the machine is successfully connected to the

wireless network, the WPS LED light stays on.

c SSID Type: After completing the wireless network connection

process, the AP’s SSID information is displayed on the LCD display.

Indice

Altri manuali Samsung Stampante tutto in uno

Samsung

Samsung SCX 6555N - MultiXpress Mono Multifunction Guida di riferimento

Samsung

Samsung SF-755P - B/W Laser - All-in-One Manuale utente

Samsung

Samsung MultiXpress M537x series Manuale utente

Samsung

Samsung SCX-4300 - SCX 4300 B/W Laser Manuale utente

Samsung

Samsung Xpress M2070 Series Manuale utente

Samsung

Samsung MultiXpress C9250ND Manuale utente

Samsung

Samsung SL-M2875FD Manuale utente

Samsung

Samsung SF 560R - ELECTRONICS , INC. Laser... Manuale utente

Samsung

Samsung CLX-4195FW Manuale utente

Samsung

Samsung SCX-3405FW Guida utente

Samsung

Samsung CLX-6200FX Manuale utente

Samsung

Samsung Xpress C46 series Manuale utente

Samsung

Samsung SCX-4200R Manuale utente

Samsung

Samsung CLX 3160FN - Color Laser - All-in-One Manuale utente

Samsung

Samsung SCX-4300 Series Manuale utente

Samsung

Samsung MultiXpress K220 Series Manuale utente

Samsung

Samsung MFP SCX-6345N Manuale utente

Samsung

Samsung Lazett Combo SCX-4216F Manuale utente

Samsung

Samsung SCX-4623F Manuale utente

Samsung

Samsung CLP-600 Series Manuale utente

Samsung

Samsung SF 4700 Manuale utente

Samsung

Samsung CLP 600N - Color Laser Printer Manuale utente

Samsung

Samsung MultiXpress X740x Series Manuale utente

Samsung

Samsung CJX-1050W Manuale utente

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Brother

Brother MFC-J430w Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Brother

Brother MFC-9760 Manuale utente

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Canon

Canon ImageCLASS 2300 Manuale

Ricoh

Ricoh Pro C900 Manuale utente

Lexmark

Lexmark X925 Manuale utente

Brother

Brother Business Smart MFC-J4510dw Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente
