Samsung AQ 1O0 Manuale utente

AQ 1O0

I Ik yo_',) b yig _ $8 s i9 (}sr'e 8,

I s "i8 81wl eli}youle r o,'x_o J{'

i i {es, s at( o i, ilyoJ pioi:',)s, araedi

i; iotos w _ i(; 8coo ipsf'y I'; SOl_Wsr÷ _

II, ase '}ac ar al o'o _{F I',/,

instructions

Use this camera in the following order.

To use this camera with a PC, install

the application software first.After

you have done this, you can move

images in the camera to

edit them using an

If the

;s the

it on.

Open Windows's EXPLORER

and search for [Removable Disk].

(p.97)

Getting to Know your camera

Thank you for buying a Samsung Digital Camera.

• Prior to using this camera, please read the user manual thoroughly.

• If you require After Sales service, please bring the camera and

the cause of the camera malfunction (such as battery, Memory

card etc.) to a Samsung Authorized Service Center.

• Please check that the camera is operating properly before you

intend to use it (e.g. for a trip or an important event) to avoid

disappointment. Samsung takes no responsibility for any loss or

damage that may result from camera malfunction.

• Keep this manual in a safe place.

• If you use a card reader to copy the images on the memory card to

your PC, the images could be damaged. When transferring the

images taken with the camera to your PC, be sure to use the

supplied USB cable to connect the camera to your PC. Please note

that the manufacturer holds no responsibility for loss or damage of

images on the memory card due to the use of a card reader.

• The contents and illustrations of this manual are subject to

change without prior notice for upgrading the camera functions.

• It is advisable to replace waterproof components once a year to

maintain the waterproof performance. Contact your nearest Samsung

service center for the replacement of waterproof components.

Microsoft, Windows and Windows logo are registered trademarks

of Microsoft Corporation incorporated in the United States and/or

other countries.

Adobe and Reader are either trademarks or registered trademarks

in the United States and/or other countries.

All brand and product names appearing in this manual are

registered trademarks of their respective companies.

For Open Source License information, refer to the "OpenSourcelnfo.pdf"

in the providedCD-ROM. 1

Danger Warning

DANGER indicates an imminently hazardous situation which, if not

avoided, will result in death or serious injury.

• Do not attempt to modify this camera in any way. To do so may

result in fire, injury, electric shock, or severe damage to you or

your camera. Internal inspection, maintenance and repairs should

only be carried out by your dealer or Samsung Camera Service

center.

• Please do not use this prod ct in _jose proximity to flammable or

explosive gases, as this _u!_ i :_r_a_sethe risk of explosion.

• Shou d any form of qu _ or _fo_ gn Object enter the camera,

do not useit. Switch off the _ra, arid then disconnect the

powersource.You_st cont€!'yourde_erorSamsungCamera

Service center. D_'_ot continue:to use the #mere as this may

cause a fire or eJ'eCtricshock_: i .....

• Do not insert or_rop metallic or inflammable i0reign ob ects into

the camera card slot and

WARNING indicates a potentially hazardous situation which, if not

avoided, could result in death or serious injury.

• Do not use the flash in close proximity to people or animals.

Positioning the flash too close to your subject's eyes may cause

eyesight damage.

• For safety reasons keep this product and its accessories out of

reach of children or animals to,p _vent accidents e.g.:

- Swallowing battery or smal!_Camer_ _ocessories. If an accident

should occur, please con_ It a #t_ mmediatety.

- There is the possibility dinju_n t_"_camera'smovingparts.

• The batter and camera_may b_e,t'ne hot'_ur ng pro onged use

Y ......

and it may result in c_ 'era mal_tion. If ire camera or battery

becomes hot allow _ camera iQ_it idle for _ few minutes to

allow it time to coo!:i i

• Do not leave this camera in places' subject to extremely high

tempe ratu res, su nlight or other

risk of electric shock. components and could cause a fire.

• When in use, do not cover the camera or Charger. This may cause

heat to build up and distort the camera body or cause a fire. Always

use the camera and its accessories in a welt-ventilated area.

Caution

CAUTION indicates a potentially hazardous situation which, if not

avoided, may result in a minor or moderate injury.

• Leaking, overheating, or damaged battery could result in fire or

injury.

- Only use battery with the correct specifications for the camera.

- Do not short circuit, heat or dispose of battery in fire.

- Do not insert the battery with ;_ _larities reversed.

• Remove the battery when ngt'_lanni_g to use the camera for a

long period of time. Othe_i e _he_at_[y may leak corrosive

electrolyte and permane_tlly da _ th £amera's components.

• Do not fire the flash whi!_eit is i tact Witb hands or objects. Do

not touch the flash aff_ 'using it_c_ntinuousiy, it may cause burns.

• Do not move the ca _ra while i i_, switched on, if you are using

the AC adapter. A_er use, alwa_ iMtch off th_ £amera before

unplugging the cable from the Wai; socket. Then make sure that

any connector cor_ 8'_' _bl_s ts"8_d_vi:_ _re disconnected

before moving the _m_##. _ai_#re to _0 _ _#y damage the

cords or cables and _a_se _!fij:e d el _ i_s_ €:k.

• Take care not to touch the tens to avoid taking an unclear image

and possibly causing camera malfunction.

• Avoid obstructing the lens or the flash when you capture an image.

• When using this camera in low temperatures, you may experience

the following. These are not camera malfunctions. The camera

usually recovers at normal temperature.

- It takes longer to turn on the LCD screen and the coIor may differ

from the subject.

- After changing to a different subject or scene, there may be an

after image on the LCD screen.

• Credit cards may be demagnetized if left near case. Avoid leaving

magnetic strip cards near the case.

• Never connect the 20 pin connector to the USB port of a PC. This

carries a high risk of computer malfunction.

• Do not open the battery cover or the USB cover in the sea, a lake

or in similar underwater conditions. Do not open the battery cover

or the USB cover with a wet hand either. It may cause electric

shock or camera malfunction.

Contents

READY

RECORDING

007 System chart

007 Package Contents

007 Sold Separately

008 identification of features

008 Front & Top

009 Back

010 Bottom

010 5 Function button

011 Self-timer tamp

011 Camera Status Lamp

011 Mode icon

012 Connecting to aPower Source

015 inserting the memory card

016 instructionson how to use the memory card

018 Waterproof management

020 When using the camerafor the first time

021 LCD screen indicator

022 How to use the menu

023 Starting the recording mode

023 Selecting modes

023 How to use the Smart Auto mode

024 How to use the Program mode

025 How to use the Scene modes

027 How to use the Movie clip mode

028 Recording HD (High Definition)movieclips

028 Recording a movie clip without sound

029 Things to Watch Out for When Taking

Pictures

030 Using the camera buttons to set the camera

030 POWER button

030 SHUTTER button

031 Zoom button

032 Info (DISP) /Up button

033 Macro /Down button

034 Focuslock

035 Flash /Left button

037 Self-timer /Right button

038 MENU button

038 OK button

038 Shooting

039 How to Enable Functions Using the

MENU Button

040 Photo Size /Movie Size

040 Quaiity/ Frame rate (Image Resolution)

041 Exposure compensation

041 ISO

042 White balance

043 Face Detection

046 Smart FR Edit

Contents

047

048

049

O5O

051

052

053

054

SETUP 055

055

056

Face Tone

Face Retouch

Auto Focus type

Metering

Photo Style Selector

Smart Filter

image Adjust

ACB

Drive mode

DIS

Movie Clip frame stabitiser

Smart Scene Detection

Voice Memo

Voice Recording

Recording a movie clip without voice

Setting movie recording

Sound menu

Sound

Volume

Start up sound

Shutter sound

Beep sound

AF sound

Setup menu

PLAY

056 Display

056 Language

056 Function Description

057 Start up image

057 Display Brightness

057 Quick view

057 Display Save

058 Settings

058 Formatting a memory

058 Initialization

059 Setting up the Date /Time /Date type

059 Time Zone

059 File name

060 Imprinting the recording date

060 Auto power off

061 Auto Focus lamp

061 Selecting Video out type

062 Setting the USB

063 Starting play mode

063 Ptaying back a stitl image

063 Ptaying back a movie ctip

064 Movie ctip capture function

064 Ptaying back a recorded voice

065 Playing back a voice memo

Contents

065 LCD screen indicator

066 Using the camera buttons to set the camera

066 Play mode button

066 Thumbnail /Enlargement button

066 Smart Atbum

069 Info (DISP) /Up button

069 Play & Pause /OK button

070 Left /Right /Down /MENU button

070 Delete button

071 Setting the playback functions using the

LCD Screen

072 Setting the playback PictBridge function

using the LCD screen

073 Edit

073 Resize

074 Rotating an image

074 Photo Style Selector

075 Smart Filter

076 Image Adjust

077 Starting the Multi Slide Show

077 Start the Multi Slide Show

078 Selecting Images

079 Setting play interval

079 Setting Background Music

079 Configure Multi Slide Show effects

PICTBRIDGE

APPENDIX

SOFTWARE

080 File Options

080 Deleting images

080 Protecting images

081 Face List Edit

081 Voice memo

082 DPOF

084 Copy to Card

085 PictBridge

086 PictBridge :Picture Selection

086 PictBridge :Print Setting

087 PictBridge :Reset

087 important notes

089 Warning indicator

090 Before contacting aservice center

092 Specifications

095 Transferring flies to your computer

for Windows

095 For Windows users

099 Transferring files to your computer for

Mac

099 For Mac users

101 FAQ

System chart

Ptease make sure your package contains the contents listed below before using this product. The contents can vary depending on the sales

region. To buy the optional equipment listed under Sold Separately, contact your nearest Samsung dealer or Samsung service center. The

appearance of the parts and accessories in your package may differ from the illustrations betow.

_e Contents

Sold Separately

identification of features

Front &Top

Shutter button

Flash POWER button

Speaker

USB/AV /DC terminal

Strap eyelet

AF Lamp

_-- Microphone

identification of features

Back

LCD Screen

SANISUNG

Camera status lamp Zoom button

MENU button

MENU MOD£

-0 C.-

Play mode button

-- MODE button

-"5 function button

-- Fn /Detete button

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Samsung Macchina fotografica digitale

Samsung

Samsung S760 - Digital Camera - Compact Manuale di istruzioni

Samsung

Samsung VP-MS10 Series Guida all'installazione

Samsung

Samsung ES55 Manuale utente

Samsung

Samsung SAMSUNG_BL103 Manuale utente

Samsung

Samsung NV20 - Digital Camera - Compact Manuale utente

Samsung

Samsung QUARTZ DATE AF ZOOM 777i Manuale utente

Samsung

Samsung SMARTCAMERA WB152F Manuale utente

Samsung

Samsung SMARTCAMERA WB150 Manuale utente

Samsung

Samsung L100 - Digital Camera - Compact Manuale utente

Samsung

Samsung SCC-B2331P Manuale utente

Samsung

Samsung ST550 Manuale di istruzioni

Samsung

Samsung PL60 Manuale di istruzioni

Samsung

Samsung ST70 Manuale utente

Samsung

Samsung Digimax 101 Manuale utente

Samsung

Samsung SL630 Manuale utente

Samsung

Samsung L100 - Digital Camera - Compact Manuale utente

Samsung

Samsung SIR-4150 Series Manuale utente

Samsung

Samsung Vluu PL170 Manuale utente

Samsung

Samsung VLUU PL100 Manuale di istruzioni

Samsung

Samsung WB1100F Manuale utente

Samsung

Samsung NX1100 Manuale utente

Samsung

Samsung IT100 Manuale di istruzioni

Samsung

Samsung SCC-B2333(P) Manuale utente

Samsung

Samsung VLUU ST95 Manuale utente

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

Sony

Sony MCA-20 Manuale utente

Sony

Sony Alpha DSLR-A290 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Sony

Sony A6700 Guida utente

Canon

Canon EOS ELAN7 Manuale utente
