Samsung TL110 Manuale di istruzioni

FOR TECHNICAL SUPPORT, PLEASE CALL 1-800-SAMSUNG (726-7864)

POR FAVOR LLAMAR 1-800-SAMSUNG (726-7864) PARA ASISTENCIA TECNICA

Quick Start Manual

TL110

ENG / SPA

Health and safety informationContents

Warnings

Do not use your camera near ﬂammable or explosive

gases and liquids

Do not use your camera near fuels, combustibles, or

ﬂammable chemicals. Do not store or carry ﬂammable

liquids, gases, or explosive materials in the same

compartment as the camera or its accessories.

Keep your camera away from small children and pets

Keep your camera and all accessories out of the reach of

small children and animals. Small parts may cause choking

or serious injury if swallowed. Moving parts and accessories

may present physical dangers as well.

Prevent damage to subjects’ eyesight

Do not use the ﬂash in close proximity (closer than 1m/3 ft) to

people or animals. Using the ﬂash too close to your subject’s

eyes can cause temporary or permanent damage.

Health and safety

information…………………… 2

Camera layout ……………… 4

Setting up your camera …… 5

Unpacking ……………………… 5

Inserting the battery and

memory card …………………… 6

Charging the battery …………… 6

Turning on your camera………… 7

Selecting options ……………… 7

Capturing photos or videos

… 8

Playing ﬁles ………………… 9

Transferring ﬁles to a PC

(Windows) …………………… 10

Speciﬁcations ……………… 11

English

Exercise caution when connecting cables or adapters•

and installing batteries and memory cards. Forcing

the connectors, improperly connecting cables, or

improperly installing batteries and memory cards can

damage ports, connectors, and accessories.

Do not insert foreign objects into any of your camera’s•

compartments, slots, or access points. This type of

damage may not be covered by your warranty.

Protect batteries, chargers, and memory cards from

damage

Avoid exposing batteries or memory cards to very•

cold or very hot temperatures (below 0° C/32° F or

above 40° C/104° F). Extreme temperatures can

reduce the charging capacity of your batteries and

can cause memory cards to malfunction.

Prevent memory cards from making contact with•

liquids, dirt, or foreign substances. If dirty, wipe the

memory card clean with a soft cloth before inserting

in your camera.

Handle and dispose of batteries and chargers with

care

Use only Samsung-approved batteries and chargers.•

Incompatible batteries and chargers can cause serious

injuries or damage to your camera.

Never place batteries or cameras on or in heating•

devices, such as microwave ovens, stoves, or

radiators. Batteries may explode when overheated.

Cautions

Handle and store your camera carefully and sensibly

Do not allow your camera to get wet—liquids can•

cause serious damage. Do not handle your camera

with wet hands. Water damage to your camera can

void your manufacturer’s warranty.

Avoid using or storing your camera in dusty, dirty,•

humid, or poorly-ventilated areas to prevent damage

to moving parts and internal components.

Speaker

Shutter button

Zoom W Lever (Thumbnail)

Zoom T Lever (Digital zoom)

POWER button

Microphone

Smart button

AF-assist light/timer lamp

Lens / Lens cover

USB / AV / DC terminal

Flash

Camera layout

MENU button

Status lamp

MODE button

Strap eyelet

Navigation button/OK button

Fn / Delete button

Battery chamber cover

Playback button

Tripod mount

LCD monitor

English

Setting up your camera

Please check that you have the correct contents before using this product. The contents can vary depending on the sales region.

To buy the optional equipment, contact your nearest Samsung dealer or Samsung service centre.

Unpacking

Camera Rechargeable Battery

AD43-00194A

AC adapter/USB cable

AD44-00143A/

AD39-00165A

Camera strap

AD63-02596A

AD63-02604A

Quick Start Manual

AD68-04771A

Software CD-ROM

(User manual included)

AD46-00323A

Memory card

(microSD

)

Camera case

A/V cable

AD39-00146A

Battery charger

AD44-00164A

Optional accessories

Setting up your camera

Inserting the battery and memory card Charging the battery

Push gently until the card

disengages from the camera

and then pull it out of the slot.

▼

Removing the memroy card

▼

Removing the battery

Indicator light

Red▪: Charging

Green▪: Fully charged

Before using the camera for the ﬁrst time, you must

charge the battery.

With the Samsung logo

facing up

With the gold-coloured

contacts facing down

English

In Shooting mode, press [

Use the navigation buttons to scroll to an

option or menu.

Back

Photo Size

Move

To move left or right, press [▪] or [ ].

To move up or down, press [▪] or [ ].

Press [

] to conﬁrm the highlighted option or

menu.

Press [▪] again to go back to the previous

menu.

Selecting options

Press [

POWER].

The intial setup screen appears.▪

Press [

] to select Language and press [ ].

Press [

] or [ ] to select a language and

press [ ].

Press [

] or [ ] to select Date & Time and

press [ ].

Press [

] or [ ] to select an item.

Press [

] or [ ] to change the number or

select another date format and press [ ].

Press [

] or [ ] to select Time Zone and

press [ ].

Press [

] or [ ] to select a time zone and press

[].

Turning on your camera

Taking a photo

Press [

] to select ( ).

(Press [ ], [ ] to select ( ).)

Align your subject in the frame.

Press [

Shutter] halfway down to focus

automatically.

A green frame means the subject in focus.▪

Press [

Shutter] all the way down to take the

photo.

Recording a video

Press [

] to select ( ).

(Press [ ] to select ( ).)

Align your subject in the frame.

Press [

Shutter].

Press [▪] to pause or resume.

Press [

Shutter] again to stop the recording.

Note

Number of photos by resolution (for 1 GB microSD

)

Resolution Super ﬁne Fine Normal

4320 x 3240 129 240 292

4272 x 2848 154 255 321

4224 x 2376 183 291 367

3264 x 2448 232 391 510

2592 x 1944 412 583 824

2048 x 1536 600 802 965

1024 x 768 1,584 1,765 1,993

These ﬁgures are measured under Samsung’s standard

conditions and may vary depending on shooting conditions

and camera settings.

Capturing photos or videos

English

Playing ﬁles

Viewing photos

Press [

] or [ ] to scroll through ﬁles.

Press and hold to view ﬁles quickly.▪

Viewing videos

Press

[ ].

Press [

Play Capture

Use the following buttons to control playback.

[ ] Scan backward

[]Pause or resume playback

[]Scan forward

[Zoom] left or right Adjust the volume level

1110

Transferring ﬁles to a PC (Windows)

Connect the camera to your computer with the

USB cable.

Note

Make sure that the PC Software option is set to On in the

settings menu.

Turn on the camera.

The computer recognises the camera automatically.▪

For Windows Vista, select▪Run iStudio.exe from

the AutoPlay window.

Select a folder on your computer to save new

ﬁles.

If your camera has no new ﬁles, the pop-up window▪

for saving new ﬁles will not appear.

Select

Yes.

New ﬁles will be transferred to your computer.▪

You can now use the Intelli-studio program.

Note

About Intelli-studio

Intelli-studio is a built-in program that allows you to play

back and edit ﬁles. You can also upload ﬁles to websites,

such as Flickr or YouTube.
