Samsung Wingo MY-MP200 Manuale utente

ELECTRELECTRONICS

MP3 PLAYER

MY-MP200

Instruction Manual

2MP3 PLAYER

Accessories Supplied

Contents

◆ Accessory Supplied ........................................................................... 2

◆ Locations of Controls........................................................................ 3

◆ To Get Started..................................................................................... 4

◆ MP3 Player

•Connecting to a PC........................................................................................................ 5

•To install the program to your PC .............................................................................. 6

•Using MP3 program...................................................................................................... 7

•When to play back MP3................................................................................................ 9

•Special features...............................................................................................................10

◆ Troubleshooting Guide..................................................................... 12

◆ Specifications...................................................................................... 12

Owner's Manual

(Including Warranty) CD-ROM DISC Parallel Cable

Earphone Smart Card Recording Protect

Sticker

Press Push Important Note

Symbols

3MP3 PLAYER

Location of controls

UNIT

DISPLAY UNIT

Repeat Button

Volume Increase Button

Volume Decrease Button

Insert a Smart Card

Hold Switch

Volume Decrease Button

Earphone Terminal

Skip/Search( )

PC Terminal

Volume Increase Button

Play/Stop Button

Skip/Search( )

S. bass Button

Repeat

Recording

MP3

Channel

Total File

Delete Files

S. bass

Display Digits

Battery Display

4MP3 PLAYER

To Get Started

Setting the Smart Card

Smart Card Erasure Protection Feature

Insert a Smart Card into the Unit

Use Downloading MP3 file.

To change Smart Card.

• Push the Eject Switch of Smart Card.

Eject Switch of Smart Card

(Front) (Back)

(Recording protect sticker)

• To keep a music file input not to be erased, attach the memory erasing

protection sticker to the memory protection tab.

• Be cautious to protect Smart Card from magnet, humidity, shock, etc.

• Be sure to power off when Smart Card is inserted into or out of MP3 player. Or

otherwise the music file stored in it may be damaged.

• Smart Card 16MB and 32MB only are available in this product.

• The smart card from other vendors cannot be used with this product.

• Please use the smart card provided by this company.

☛

Connecting to a PC

5MP3 PLAYER

Taking the steps shown below will prepare your Wingo for downloading MP3 files.

• Connect the MP3 Player to a PC using a parallel cable.

PARALLEL

Data In/Out

MP3 Player

PC.

• To download an MP3 file to your MP3 Player, the parallel port should be

available on your computer.

• If a printer is connected to the parallel port of your PC, disconnect it

temporarily to connect your MP3 Player.

• If your PC does not have a parallel port, inquire with the dealer's where you

purchased your PC and have a parallel port installed.

• For best results, your system requirements should be as follows:

- Pentium 120MHz or higher

- Window

95/98

- At least 20MB Hard Disk space

- Parallel Port supporting

ECP

- CD-ROM Drive

- 32MB RAM or higher

6MP3 PLAYER

To install the program to your PC

• The computer should be set while booting as shown below.

1) Turn on the computer.

2) While testing the RAM, press the F2 or Del key to enter the Setup screen.

3) Move to the Peripheral setting screen to set the Printer port.

4) Set the Printer port to the ECP mode.

5) Save the setting and reboot the computer.

Check the “Environment ➔options” menu of unit, set to the ECP mode by check.

• Refer to page 7.

In order to download MP3 files to MP3 Player, you should install

programs contained on the CD-ROM supplied for your PC.

• This program may not be installed normally depending upon the type of your PC if

MS EXPLORER version 4.01 or higher has not been installed, so install it by the

supplied CD-ROM disc and via Internet.

1Load the supplied software CD into the CD-ROM

drive of your PC and click on the "NEXT" Button.

• The MP3 Player setup program will start

automatically.

• If the setup does not start automatically, find the

"setup.exe" file using the File Finder, then double

click on it to execute the program.

• To install in another directory, use the Browse Button

to select.

2Check the icon of program path and then press

the "NEXT" Button.

• An icon will be created automatically.

3After installing procedures are completed, click

the "Finish" Button to exit the setup program.

Be sure to keep the CD supplied safe. If you lost it, or if you want to upgrade to the

newest version, you can download from the Internet Site below:

7MP3 PLAYER

Using MP3 program

• When the power MP3 Player is off and the connection cable is disconnected in the use of this

program, then the fatal error will be occurred, so you should take care of it. If the error is

occurred, turn off the power MP3 Player turn it on again, make the correct connection, and

run this program.

• If you stop this program during downloading or uploading a file, an error will be occurred.

Then, select "REFRESH" menu to initialize the program, and reconnect the communication.

File Window

Press the right button of the

mouse, then the menu

window will open.

To select options to see files in

the File Window

To show the files stored in

the MP3 Player

To show the progress of

file copying

To copy files from PC to the

Flash Memory of MP3 Player

To copy files from MP3 Player to PC

To delete all the data on the

Flash Memory of MP3 Player

To stop all the current jobs

To restore the updated data on PC

or MP3 Player

To adjust the screen font of the program

To select options to show files in the

File Window

To delete selected file

To copy files from MP3 Player to PC

Window for showing the

progress of the data transmitting

To delete the selected file

To finish all jobs and

exit the program

To move to Option screen

Not use When erasing all the

data on MP3 Player

To backup files

To update files

To read file information

Not use

Standby time at initial

connection

When reading data by PC

When writing on MP3

Player

When deleting files

Not use

* Communication: When error occurs, to set "Standby Time" (Unit: millisecond (1 sec. = 1000 millisecond)

To copy files from PC to MP3 Player

To stop the current job

Check on it when the computer

does support ECP mode

8MP3 PLAYER

Using MP3 program

When to transfer files from PC to MP3 Player

Double click on “MP3 Player Explorer icon” to execute the program.

Then choose "External Memory" command from "Copy to"

command.

Alternately, press the Button on the screen.

From the PC window, choose the "File" menu either by

clicking the left button of the Mouse or by using (ins) key.

Press the OPEN button on the screen.

When to transfer files from MP3 Player to PC

: Excepting MP3 files

From the MP3 Player window, choose the "File" menu either

by clicking the left button of the Mouse or by using (Ins) key.

Then choose "Flash Memory" command from "Copy to"

command. Alternately, press the Button on the screen.

From the PC window, choose the “Directory”, Press the

“SAVE” Button.

According to the copyright law for the MP3 file and audio file, these files cannot be uploaded

(saving to the PC). Only the general file (document file) can be uploaded.

When to delete files

From the MP3 Player window, choose the "File" menu either

by clicking the left button of the Mouse or by using (ins) key.

Then choose the "Delete" command from the File menu.

Alternately, press the Button on the screen.

When to delete all files in MP3 Player

Choose the "File" menu. Then choose the "Format"

command from the "File" menu to delete all the files.

•

Your unit (MP3 Player) can download up to 32 Mbytes. Hence, depending on the

size of MP3 file, the number of files to be downloaded may be limited.

•

The number on the Total Space of the window for the progress of the data

transmission indicates the remaining space for download.

9MP3 PLAYER

When to play back MP3

☛

Copy audio files from your PC to playback them with the set.

Press the Play/Stop Button.

• Switch the System on by pressing Play/Stop.

• Switch the System off by pressing Play/Stop for over 2 seconds.

If you want to pause MP3 music, press “Play/Stop” button

If you want to play MP3 music again,

press "Play/Stop" button again.

-MP3 music will restart to play at the point where it was stopped.

After connecting an earphone, adjust the volume.

• If the power is completely disconnected by replacing the battery, the first music

will be played at the beginning of that music.

☛

• The set automatically switches off if no keys are pressed within 100 seconds of

when playback is stopped, the end of a file is reached, or pause is activated.

☛

10 MP3 PLAYER

Special Features

Press PEPEAT button to select “REPEAT” or “REPEAT ALL”

To listen to the present song repeatedly:

• Press the REPEAT button to select, then “REP” appears on the LCD flash.

To repeat all the songs.

• Press the REPEAT button once more, then “REP ALL” appears on the LCD.

If you want to disable the repeat function.

• press REPEAT button once more to disappear “REP ALL” at the LCD.

During playback, momentarily press the " , " Button.

•Press and release the " " Button to select the next track.

Press and release the " " Button to replay the current track.

•

When in STOP mode, press and release the " " Button to playback the second track.

Press and release the " " Button to playback the last track.

To select a track

REPEAT Function

Repeat Button

During playback, hold down the " , " Button.

•Hold down " " Button to fast forward the track. Hold down " " Button for

the fast playback backwards.

•Release the button for playback at normal speed.

High-Speed Search
