Samsung BRZ22 Series Manuale utente

Refrigerator

User manual (freezer only)

BRZ22*

SEUK Built-in Appliance

Untitled-1 1 2022-11-25  10:36:57

English2

Contents

Safety information 3

What you need to know about the safety instructions 3

Important safety symbols and precautions: 5

Important safety precautions 6

Severe warning signs for transportation and site 9

Critical installation warnings 10

Installation cautions 14

Critical usage warnings 14

Usage cautions 19

Cleaning cautions 21

Critical disposal warnings 23

Additional tips for proper usage 24

Instructions about the WEEE 26

Installation 27

Refrigerator at a glance 27

Step-by-step installation 28

Operations 39

Main panel 39

SmartThings (applicable models only) 42

Maintenance 44

Handle and care 44

Cleaning 46

Replacement 46

Troubleshooting 47

General 47

Do you hear abnormal sounds from the refrigerator? 49

SmartThings (applicable models only) 51

Appendix 52

Safety Instruction 52

Install Instruction 52

Temperature Instruction 53

Information for model and ordering spare parts 56

Open Source Announcement 57

Untitled-1 2 2022-11-25  10:36:58

English 3

Safety information

Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure

that you know how to operate the features and functions that your new appliance offers

safely and efciently.

What you need to know about the safety

instructions

• Warnings and Important Safety Instructions in this manual

do not cover all possible conditions and situations that

may occur.

It is your responsibility to use common sense, caution,

and care when installing, maintaining, and operating your

appliance.

• Because these following operating instructions cover

various models, the characteristics of your refrigerator

may differ slightly from those described in this manual and

not all warning signs may be applicable. If you have any

questions or concerns, contact your nearest service center

or nd help and information online at www.samsung.com.

• R-600a or R-134a is used as a refrigerant. Check the

compressor label on the rear of the appliance or the rating

label inside the appliance to see which refrigerant is used

for your appliance. When this product contains ammable

gas (Refrigerant R-600a), contact your local authority in

regard to safe disposal of this product.

• In order to avoid the creation of a ammable gas-air

mixture if a leak in the refrigerating circuit occurs, the size

of the room in which the appliance may be sited depends

on the amount of refrigerant used.

• It is hazardous for anyone other than an Authorized

Service Person to service this appliance.

Safety information

Untitled-1 3 2022-11-25  10:36:58

Safety information

English4

Safety information

• Never start up an appliance showing any signs of damage.

If in doubt, consult your dealer. The room must be 1 m3

in size for every 8 g of R-600a refrigerant inside the

appliance.

The amount of refrigerant in your particular appliance is

shown on the identication plate inside the appliance.

• Refrigerant squirting out of the pipes could ignite or cause

an eye injury. When refrigerant leaks from the pipe, avoid

any naked ames and move anything ammable away

from the product and ventilate the room immediately.

- Failing to do so may result in re or explosion.

• To avoid contamination of food, please respect the

following instructions:

- Opening the door for long periods can cause a

signicant increase of the temperature in the

compartments of the appliance.

- Clean regularly surfaces that can come in contact with

food and accessible drainage systems.

- Clean water tanks if they have not been used for 48 h;

ush the water system connected to a water supply if

water has not been drawn for 5 days.

- Store raw meat and sh in suitable containers in the

refrigerator, so that it is not in contact with or drip onto

other food.

- Two-star frozen-food compartments are suitable for

storing pre-frozen food, storing or making icecream and

making ice cubes.

- One-, two- and three-star compartments are not suitable

for the freezing of fresh food.

Untitled-1 4 2022-11-25  10:36:58

English 5

Safety information

- If the refrigerating appliance is left empty for long

periods, power off, defrost, clean, dry, and leave the

door open to prevent mould developing within the

appliance.

Important safety symbols and precautions:

Please follow all safety instructions in this manual. This

manual uses the following safety symbols.

WARNING

Hazards or unsafe practices that may result in severe personal

injury, property damage, or death.

CAUTION

Hazards or unsafe practices that may result in severe personal

injury or property damage.

NOTE

Useful information that helps users understand or benet

from the refrigerator.

These warning signs are here to prevent injury to you and

others.

Please follow them carefully.

After reading this section, keep it in a safe place for future

reference.

Untitled-1 5 2022-11-25  10:36:58

Safety information

English6

Safety information

Important safety precautions

WARNING; Risk of re / Flammable materials

WARNING

• When positioning the appliance, ensure the supply cord is

not trapped or damaged.

• Do not locate multiple portable socket-outlets or portable

power supplies at the rear of the appliance.

• Keep ventilation openings, in the appliance enclosure or in

the built-in structure, clear of obstruction.

• Do not use mechanical devices or any other means

to accelerate the defrosting process, other than those

recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type

recommended by the manufacturer.

• This appliance is not intended for use by persons

(including children) with reduced physical, sensory, or

mental capabilities, or those who lack experience and

knowledge, unless they have been given supervision or

instruction concerning the use of the appliance by a person

responsible for their safety.

Untitled-1 6 2022-11-25  10:36:58

English 7

Safety information

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge

if they have been given supervision or instruction

concerning use of the appliance in a safe way and

understand the hazards involved. Children shall not play

with the appliance. Cleaning and user maintenance shall

not be made by children without supervision. Children

aged from 3 to 8 years are allowed to load and unload

refrigerating appliances.

• If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualied

persons in order to avoid a hazard.

• The socket must be easily accessible so that the appliance

can be quickly disconnected from the supply in an

emergency.

- It must be outside the area of the rear of the appliance.

• Do not store explosive substances such as aerosol cans

with a ammable propellant in this appliance.

• If the product is equipped with LED lamps, do not

disassemble the Lamp Covers and LED lamps yourself.

- Contact a Samsung service center.

- Use only the LED Lamps provided by the manufacturer

or its service agents.

• If the interior or exterior LED lamp has gone out, contact

your nearest service center.

• For the most efcient use of energy, please keep the all

inner ttings such as baskets, drawers, shelves on the

position supplied by manufacturer.

Untitled-1 7 2022-11-25  10:36:58

Safety information

English8

Safety information

• To get the best energy efciency of this product, please

leave all shelves, drawers and baskets on their original

position.

How to minimize the energy consumption

• Install the appliance in a cool, dry room with adequate

ventilation.

• Ensure that it is not exposed to direct sunlight and never

put it near a direct source of heat (radiator, for example).

- Not to block any vents or grilles is recommended for

energy efciency.

- Allow warm food to cool down before placing it in the

appliance.

- Put frozen food in the refrigerator to thaw. You can

then use the low temperatures of the frozen products to

cool food in the refrigerator.

- Do not keep the door of the appliance open for too long

when putting food in or taking food out.

- The shorter time for which the door is open, the less ice

will form in the freezer.

- Clean the rear of the refrigerator regularly. Dust

increases energy consumption.

- Do not set temperature colder than necessary.

- Ensure sufcient air exhaust at the refrigerator base

and at the back wall of the refrigerator. Do not cover air

vent openings.

- Allow clearance to the right, left, back and top when

installing. This will help reduce energy consumption and

keep your energy bills lower.

Untitled-1 8 2022-11-25  10:36:58

English 9

Safety information

• Select 560 mm cavity depth. A smaller cavity depth will

result in a higher energy consumption.

This appliance is intended to be used in household and similar

applications such as

- staff kitchen areas in shops, ofces and other working

environments;

- farm houses and by clients in hotels, motels and other

residential type environments;

- bed and breakfast type environments;

- catering and similar non-retail applications.

Severe warning signs for transportation and site

WARNING

• When transporting and installing the appliance, care should

be taken to ensure that no parts of the refrigerating circuit

are damaged.

- Refrigerant leaking from the pipe work could ignite

or cause an eye injury. If a leak is detected, avoid any

naked ames or potential sources of ignition and air

the room in which the appliance is standing for several

minutes.

Untitled-1 9 2022-11-25  10:36:58

Safety information

English10

Safety information

- This appliance contains a small amount of isobutane

refrigerant (R-600a), a natural gas with high

environmental compatibility that is, however, also

combustible. When transporting and installing the

appliance, care should be taken to ensure that no parts

of the refrigerating circuit are damaged.

Critical installation warnings

WARNING

• Do not install the refrigerator in a damp location or place

where it may come in contact with water.

- Deteriorated insulation on electrical parts may cause an

electric shock or re.

• Do not place this refrigerator in direct sunlight or expose it

to the heat from stoves, room heaters, or other appliances.

• Do not plug several appliances into the same multiple

power strip. The refrigerator should always be plugged

into its own individual electrical outlet which has a voltage

rating that matches the voltage listed on the refrigerator’s

rating plate.

- This provides the best performance and also prevents

overloading of house wiring circuits, which could cause

a re hazard from overheated wires.

• If the wall socket is loose, do not insert the power plug.

- There is a risk of electric shock of re.

• Do not use a power cord that has cracks or abrasion

damage along its length or at either end.

Untitled-1 10 2022-11-25  10:36:58

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Samsung Frigorifero

Samsung

Samsung SRF665CDBLS Manuale utente

Samsung

Samsung RFG297ACRSXAC Manuale utente

Samsung

Samsung RF28HM Manuale utente

Samsung

Samsung RH68B Series Manuale utente

Samsung

Samsung RF25HMEDBSR Manuale utente

Samsung

Samsung RFG237AAPN - 23 cu. ft. Refrigerator Manuale di istruzioni

Samsung

Samsung RT59PMSW Manuale utente

Samsung

Samsung RF32CG Series Manuale utente

Samsung

Samsung RF4289HB Manuale utente

Samsung

Samsung SR-S25NTA Manuale utente

Samsung

Samsung RF32FMQDBSR Manuale utente

Samsung

Samsung FDR AW2-14 Manuale utente

Samsung

Samsung RL26DCAS Manuale utente

Samsung

Samsung RB215LASH Manuale utente

Samsung

Samsung RFG298HDRS Manuale utente

Samsung

Samsung RS50N3513SA Manuale utente

Samsung

Samsung RF24 Series Manuale utente

Samsung

Samsung RF30HD Series Manuale utente

Samsung

Samsung RF24FSEDBSR/AA Manuale utente

Samsung

Samsung RF26HF Series Manuale utente

Samsung

Samsung RF265ADPN Manuale utente

Samsung

Samsung RF263T Series Manuale utente

Samsung

Samsung RS265LA series Guida di sicurezza

Samsung

Samsung RS51K5 Series Manuale utente

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Beko

Beko CSA31022 Manuale utente

IKEA

IKEA FROSTIG C 185 E Manuale utente

Electrolux

Electrolux ER 6821 D Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Beko

Beko LSP4579W Manuale utente

Teledyne

Teledyne 6712FR and Istruzioni operative
