Samsung SR-PS40(R) Manuale utente

OWNER S INSTRUCTIONSOWNER S INSTRUCTIONS

SRG-148

SRG149PT

SRG-149B

SRG-149G

SRG-148

SRG149PT

SRG-149B

SRG-149G

REFRIGERATORREFRIGERATOR

Before operating the unit,please read this manual thoroughly,

and retain for future reference.

Before operating the unit,please read this manual thoroughly,

and retain for future reference.

ENGLISH

All the safety and operating instructions should be read

before the appliance is operated.

The safety and operating instructions should be retained

for future reference.

Heed Warnings

All warnings on the appliance and in the operating

instructions should be adhered to.

Follow Instructions

All operating and use instructions should be followed

Model and serial numbers

Please refer to both model and serial numbers in any cor-

respondence concerning your freezer/refrigerator.

Data of Purchased............................

Model No...............................................

Serial No ...................................................

CONTENTS

SAFETY PRECAUTIONS...................................................................................................1

SAFETY INSTRUCTIONS..................................................................................................2

PARTS DESCRIPTION...................................... ...............................................................4

DOOR REVERSAL ............................................................................................................6

TO MAKE ICE CUBES.......................................................................................................7

DEFROSTING....................................................................................................................8

STORAGE AND CLEANING...............................................................................................9

TROUBLE SHOOTING ...................................................... ...............................................11

SAFETY PRECAUTIONS

Read Instructions

Retain Instructions

SAFETY INSTRUCTIONS

INSTALLATION

Keep regular intervals

- Leave a space of 2inch between refrigerator back and wall behind. If your refrigerator is going into a recessed

area in the wall, allow at least 10 inches or more clearance above the refrigerator.

This refrigerator is designed for free standing only.

- This refrigerator should not be recessed or built in.

Avoid the direct sunlight or heater

- As plastic and electrical components are affected by direct heat, never place the unit near cookers, radiators or in places

exposed to direct sunlight.

- Normal room temperature is recommended.

Never install the unit near water.

- Avoid locations which may be affected by or dampness as this will impair the efficiency of the insulation.

Install on a stable, level surface.

- Make sure it is placed on a flat, level surface.

For personal safety, this appliance must be properly grounded.

- This refrigerator should not be grounded with telephone line,gas pipe,etc.

30cm

CAUTIONS WHILE USING

If the power is damaged, avoid a hazard by replacing it through the manufacturer or its service agent or a

similarly qualified person.

Don t use the appliance outdoors or let it be rained on.

Do not use the appliance if it is not operating correctly or has been damaged. Disconnect it from the power supply

and call your local service center.

Be careful not to splash water on the back of the refrigerator to use it in safety .

-The insulation of the electric parts will be impaired by water.

Avoid leaving the door open any longer than necessary as this will impair the efficiency of the unit making it more

costly to run.

Do not use flammable sprays such as lacquer and paint near the refrigerator, because there is a possible danger of

its ignition.

Do not put volatile chemicals such as ether and benzene in the refrigerator, because there is a danger of explosion.

Don't allow children to hang on the door.

-Children should not be left alone or unattended in an area where the appliance is in use. They may be hurt and could damage

the refrigerator.

The appliance is not intended foruse by young children orinfirm persons without supervision.

Young children should be supervised to ensure thatthey do not play withthe appliance.

If astationaryappliance is not provide with a supply for and a plug or with other means for

disconnection form the supply havingan air gap contact separation inallactive(phase)

conductors,the instructions shall state that such means for disconnection shall be

incorporation in the fixed wiring accordingto the wiring rules.

1. TOP TABLE (OPTION)

2. COVER FREEZER

3. DRIP WATER TRAY

4. CASE THERMO

5. SHELF UP

6. COVER VEGETABLE

7. VEGETABLE-BOX

8. FOOT

9. GUARD BOTTLE UPP

10.GUARD CAN

11.GUARD BOTTLE LOW

811

1. TOP TABLE (OPTION)

2. COVER FREEZER

3. DRIP WATER TRAY

4. CASE THERMO

5. SHELF UP

6. SHELF LOW

7. GUARD DOOR

8. FOOT

9. GUARD DOOR

10.GUARD CAN

11.GUARD BOTTLE

NAME OF REFRIGERATOR AND OPERATION

FRONT THE REFRIGERATOR

1. Place all shelves, all kinds of vessels in their proper positions which have been removed for transportation.

2. Clean refrigerator and parts to remove dust incurred during shipping.

3. Set cold control knob at "COLD" position and let refrigerator operate for one hour. Freezer compartment should get slightly chilled

and motor should run smoothly with no noise but soft hum.

4. Store food after the temperature in the refrigerator gets sufficiently low. It takes a few hours after starting the refrigerator to

reach the proper temperature.

5. Your refrigerator is operated by a compressor which switchs "on and off" to maintain the intemal temperature. When the

compressor is new it requires running in for a period of up to 2 months.During this period it may operate a little noiser than normal.

This is quite normal and does not represent a fault.

CONTROL SETTINGS

The temperature control maintains the temperature in the refrigerator. Setting the control at COOL is the

warmest setting. Setting the control at COLDEST is the coldest setting. Set the control at COLD.

Allow 24 hours for the refrigerator to reach the COLD temperature. If you want a colder or warmer

temperature,move the dial one setting at a time. Moving the control to OFF stops cooling but does

not turn off the power to the refrigerator. Setting the control to one of the snowflake positions may cause

freezing the refrigerator depending on the room temperature.

How To Test Temperatures

Use the milk test. Place a container of milk on a shelf and check it a day later. If the milk is too warm

or too cold, adjust the temperature control.

After changing the control, allow 24 hours for the refrigerator to reach the temperature you have set.

OFF

COLD

COOL

COLDEST

All of the following should be satisifed when tested in the followingorder, check electricity supply.

When the cause of trouble can not be located, contact your dealer.

INITIAL USING METHOD

1. Remove the two screws at the back of the top cover.

2. Remove the top cover by lifting the back up about 2 inches

and then sliding it forward.

3. Remove the small plug button on the left side of the door

top cap.

4. Remove the three screws on the upper hinge (right side ).

Remove the hinge .

5. Remove the three screws at the left hinge location on the

top plate .

6. Remove the screw in the middle of the top plate and remove

the top plate .

7. Lift the door up and off the bottom hinge (right side ).

8. Tilt the refrigerator cabinet back to remove the right leveling

leg.

9. Romove the secrews on the bottom hinge (right side )and the

left leveling leg. Move the bottom hinge to the left side and

secure it with the screws and leveling leg.

IMPORTANT:The left leg has a spacer that must be moved

to the right side leveling leg when the door swing is reversed.

10. Screw the right leveling leg ,with the spacer in place,back

in place on the right side.

11. Position the door on the left bottom hinge .with the

magnetic gasket holding the door in place replace the top

plateand screws.

12. Make sure the door is aligned with the refrigerator

cabinet before continuing .

13. Secure the top hinge with screws.

14. Slide the top cover back in place and replace the tow screws.

15. Put the plug button in the hole on the right side of the door top cap.

DOOR REVERSAL

Top cover

/ cubierta por cima

Left hinge location

/ colocacion izquierda de gozne

Plug button

/ taco boton Door top cap

/ tapapor cima

de puerta

Spacer

/ anillo de espaciar Levelinglegs

/ pie de nivelacion

Upper hinge

/ gozne superior

Top plate

/ lamina por

cima

Bottom hinge

/ gozne inferior

FREEZER

COMPARMENT

If you want to make ice cubes put the ice tray in

the freezer compartment.

Hold both ends of the ice tray, remove the

ice cubes from the tray by twisting it gently.

Do not bend the ice tray or it will crack.

TO MAKE ICE CUBES

Fill water into the ice tray to the about 80%capacity.

Slide the ice tray into the freezer compartment.

OFF

COLD

COOL

COLDEST

When you want to make ice cubes rapidly, the

thermostat should be set at COLDEST .

DEFROSTING

HOW TO DEFROST

Empty freezer.

Remove ice tray and frozen foods to the

fresh food compartment.

Remove the frost with a soft cloth only.

Remove the frost with a cloth and wipe the

freezer bottom.

Set the temperature control to "OFF".

With the freezer door opened, set the temperature

control to "OFF" . In 30 to 40 minutes, the frost on the

freezer wall will begin to melt and can be easily re-

moved.

OFF

COLD

COOL

COLDEST

Do not use sharp objects.

If the frost is forced off with a knife or a screwdriver,

the surface of the freezer will be damaged or have

a hole made in it. From the hole ,refrigerator would

leak and result in inability to refrigerate.

STORAGE AND CLEANING

TO STORE FOOD EFFICIENTLY

The procedures for replacing the bulb:

1.Unplug and disconnect the power.

2.Open the door and remove the water tray.

3.Remove the burned out bulb by rotating it.

4.Replace it with a new bulb.

5.Put the water tray back and plug the power.

Do not load your refrigerator or freezer with hot food. Allow sufficient time for cooling.

It saves energy consumption and time for freezing.

Cover moist foods with tight lids plastic containers or wrapped in vinyl film. It prevents smell from soaking

in the refrigerator.

Be sure not to store bottles such as beer, cokes, etc. in the freezer compartment.

Do not overload your set with a lot of foods.

This refrigerator is not suitable for storing the scientific data and medicines.
