Samsung SRG-058 Manuale utente

REFRIGERATOR

EN.............ENGLISH

ENGLISH

Before operating the unit, please read this manual thoroughly, and

retain for future reference.

DA68-60314C(2) Register your product at www.samsung.com/global/register

SRG-118

SR-CT89W

OWNER'S INSTRUCTIONSOWNER'S INSTRUCTIONS

EN:All the safety and operating instructions should be read

before the appliance is operated.

EN:The safety and operating instructions should be retained

for future reference.

EN:All warnings on the appliance and in the operating

instructions should be adhered to.

EN: All operating and use instructions should be followed

EN:Please refer to both model and serial numbers in any cor-

respondence concerning your freezer/refrigerator.

Data of Purchased:............................

Model No:...............................................

Serial No ...................................................

Heed Warnings/Advertencias

Follow Instructions

Model and serial numbers

CONTENTS

SAFETY PRECAUTIONS .................................................................................................1

SAFETY INSTRUCTIONS.................................................................................................2

PARTS DESCRIPTION....................................................................................................4

TEMPERATURE CONTROL.............................................................................................6

TO MAKE ICE CUBES......................................................................................................7

DEFROSTING..................................................................................................................8

STORAGE AND CLEANING............................................................................................9

TROUBLESHOOTING....................................................................................................11

SAFETY PRECAUTIONS

Read Instructions

Retain Instructions

SAFETY INSTRUCTIONS MEMO

INSTALLATION

EN:

Keep regular intervals

This refrigerator is designed for free standing only.

Avoid the direct sunlight or heater

Never install the unit near water.

Install on a stable, level surface.

For personal safety, this appliance must be properly grounded.

- Leave a space of 2 inches between refrigerator back and wall be-

hind. If your refrigerator is going into a recessed area in the wall,

allow at least 10 inches or more clearance above the refrigerator.

- This refrigerator should not be recessed or built in.

- As plastic and electrical components are affected by direct heat,

never place the unit near cookers, radiators or in places exposed

to direct sunlight.

- Normal room temperature is recommended.

- Avoid locations which may be affected by delete dampness

as this will impair the efficiency of the insulation.

- Make sure it is placed on a flat, level surface.

- This refrigerator should not be grounded with telephone line,gas

pipe,etc.

30cm

EN:

Do not use the appliance if it is not operating correctly or has

been damaged. Disconnect it from the power supply and call

your local service center.

Be careful not to splash water on the back of the refrigerator .

Avoid leaving the door open any longer than necessary as this

will impair the efficiency of the unit making it more costly to run.

Do not use flammable sprays such as lacquer and paint near

the refrigerator, because there is a possible danger of ignition.

Do not put volatile chemicals such as ether and benzene in the

refrigerator, because there is a danger of explosion.

Don't allow children to hang on the door.

-The insulation of the electric parts will be impaired by water.

-Children should not be left alone or unattended in an area where

the appliance is in use. They may be hurt and could damage the

refrigerator.

CAUTIONS WHILE USING

If the power is damaged, avoid a hazard by replacing it

through the manufacturer or its service agent or a

similarly qualified person.

Don t use the appliance outdoors or let it be

rained on.

EN:

When out of operated for a long time .

When you get ready to move

Power failure

- Remove all food and disconnect the power supply cord.Dry your refrigerator, opening the door for 2-3days.

- Securely fasten removable interior part (or remove and package them separately).

- Do not place your refrigerator horizontally, or compressor may be damaged.

- You should keep the door closed. while the power is off (1-2 hours).

MAINTENANCE / SITUACIONES EVENTUALES

PARTS DESCRIPTION

FRONT OF THE REFRIGERATOR

EN: There are unusual noises

- Check if the unit is installed in a firm place or not.

- Is shelving or storage loose inside the unit?

- Is evaporating tray inserted properly?

TROUBLESHOOTING

SYMPTOMS CHECKS

EN: Refrigerator does not operate

EN: Refrigerator is warmer than usual

EN:

- Check if there is electrical power to equipment

- Check if the home's main circuit breakerbox is

working .

- The refrigerator control dial "on".

- Check if control is set properly.

- Check if the door has been open for a long time.

- Have you recently added a large quantity of food?

En:

EN:

1. Ice tray

2. Evaporator

Do not use keen knife to scrape the frost off of this

surface.

3. Drip water tray

Use this tray to gather drip water.

4. Storage shelf

5. Vegetable corner

Use for storing fresh fruits and vegetable.

6. Levelling leg

Turn the levelling leg to make the refrigerator .

7. Freezer door

8. Temperature control

9. Egg rack

10. Door rack

Use for small items.

11.Can carry

12.Bottle rack

Put all kinds of bottles of bottles in the bottle rack.

level

EN:

- Wipe with a damp sudsy cloth, then dry.

- For stubborn strains and for periodic waxing, use silicon wax.

- Wash entire compartments with a baking soda solution (two table-

spoon of baking soda to one quart of warm water). Rinse and dry.

- Wash compartment shelves, door shelves etc.

With either the baking soda solution or a mild detergent and warm

water. Rinse and dry.

-Wash with warm sudsy water,rinse throughly and dry.

-Insert all parts to proper location and set "Temperature control

to desired setting.

Exterior

Interior

Interior parts

Magnetic door gaskets

The finishing touch

The drip water tray

- To take out the drip water tray slide it out at a downward slant

Clean it once in a month.

- It it is not inserted properly, water will not evaporate or it will cause

unusual vibrating noises.

HOW TO CLEAN THE UNIT

INITIAL USING METHOD

EN:

1. Place all shelves, all kinds of vessels in their proper positions

which have been removed for transportation.

2. Clean refrigerator and parts to remove dust incurred during

shipping

3. Set cold control knob at "COLD" position and let refrigerator oper-

ate for one hour. Freezer compartment should get slightly chilled

and motor should run smoothly with no noise but soft hum.

4. Store food after the temperature in the refrigerator gets suffi-

ciently low. It takes a few hours after starting the refrigerator to

reach the proper temperature.

5. Your refrigerator is operated by a compressor which switchs "on

and off" to maintain the intemal temperature. When the compre-

ssor is new it requires running in for a period of up to 2 months.

During this period it may operate a little noiser than normal. This

is quite normal and does not represent a fault.

EN: FOLLOW THE STEPS BEFORE TO BEGIN OPERATION OF YOUR REFRIGERATOR.

EN:

Do not load your refrigerator or freezer with hot food. Allow suffi-

cient time for cooling.

It saves energy consumption and for freezing .

Be sure not to store bottles such as beer, cokes, etc. in the

freezer compartment.

Do not overload your set with a lot of foods.

This refrigerator is not suitable for storing scientific items

or medicines.

time

STORAGE AND CLEANING

TEMPERATURE CONTROL

TO STORE FOOD EFFICIENTLY

The procedures for replacing the bulb:

1.Unplug and disconnect the power.

2.Open the door and remove the water tray.

3.Remove the burned out bulb by rotating it.

4.Replace it with a new bulb.

5.Put the water tray back and plug the power.

OFForDEF

Summer

Normal

Winter

TEMPERATURE CONTROL

TEMPERATURE

CONTROL

SITUATION

EN: The nearer to COLD the dial setting,the colder it

will become.

.................When large quantity of foods are stored.

.................For quick ice-marking,set the dial at

COLD position.

EN: Set the dial at DEF or OFF position with the door

opened.

.................After about 40 minutes, the frost on the

surface of the evaporator will begin to

melt and can be easily removed.

EN: To maintain the optimum food storage condition set

thecontroldialat MIDposition

.................For normal use.

EN: The nearer to WARM the dial setting,the warmer

it will become.

.....................When small quantity of foods are stored.

EN: To adjust the refrigerator s temperature, adjust the temperature

control dial.

Do not set the refrigerator temperature lower than necessary.

After operation as continuous operation, be sure to adjust the

thermostat to original position.

FREEZER

COMPARMENT

EN: If you want to make ice cubes put the ice tray in

the freezer compartment.

EN: Hold both ends of the ice tray, remove the

ice cubes from the tray by twisting it gently.

Do not bend the ice tray or it will crack.

TO MAKE ICE CUBES

EN: Fill water into the ice tray to the about 80%capacity.

EN: Slide the ice tray into the freezer compartment.

EN: When you want to make ice cubes rapidly, the

thermostat should be set at COLD .

DEFROSTING

HOW TO DEFROST

EN: Remove ice tray and frozen foods to the

fresh food compartment.

Empty freezer.

Remove the frost with a soft cloth only. /

Retire la escarcha solo con un trapo suave.

EN: Remove the frost with a cloth and wipe the

freezer bottom.

EN: With the freezer door opened, set the temperature

control to "OFF" . In 30 to 40 minutes, the frost on the

freezer wall will begin to melt and can be easily re-

moved.

Set the temperature control to "OFF".

EN: If the frost is forced off with a knife or a screwdriver,

the surface of the freezer will be damaged or have

a hole made in it. From the hole ,refrigerator would

leak and result in inability to refrigerate.

Do not use sharp objects.

/ No emplee objetos punzo cortantes.

Altri manuali per SRG-058

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Samsung Frigorifero

Samsung

Samsung RS22T5201 Series Manuale utente

Samsung

Samsung RF62DE Manuale utente

Samsung

Samsung RF23J9011SR Manuale utente

Samsung

Samsung RL48RWCIH1 Manuale utente

Samsung

Samsung RT53K Series Manuale utente

Samsung

Samsung RS6HA8880S9 Manuale utente

Samsung

Samsung RB38T634DSA Manuale utente

Samsung

Samsung RFG29PEPN Manuale utente

Samsung

Samsung RF265 Manuale utente

Samsung

Samsung BRD27 Series Manuale utente

Samsung

Samsung RFG23UERS Manuale utente

Samsung

Samsung RL37J Series Manuale utente

Samsung

Samsung RB12A3006 Series Manuale utente

Samsung

Samsung RM25JWSH Guida di sicurezza

Samsung

Samsung SRF679SWLS Manuale utente

Samsung

Samsung RF221NCTASP Manuale utente

Samsung

Samsung RF323TE Manuale utente

Samsung

Samsung RF263BEAE SERIES Manuale utente

Samsung

Samsung RS25J500DSR Manuale utente

Samsung

Samsung RF261BEA Istruzioni operative

Samsung

Samsung RS22 55 Series Manuale utente

Samsung

Samsung RB29H Series Manuale utente

Samsung

Samsung RS25H50 SERIES Manuale utente

Samsung

Samsung rb195ab** xaa Istruzioni operative

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Beko

Beko CSA31022 Manuale utente

IKEA

IKEA FROSTIG C 185 E Manuale utente

Electrolux

Electrolux ER 6821 D Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Beko

Beko LSP4579W Manuale utente

Teledyne

Teledyne 6712FR and Istruzioni operative
