Samsung VAC7049G Foglio di istruzioni

CODE NO : DJ68-00006T (REV 0.1)

Operating lnstructions

Manuel d’instructions

For household use only

Pour usage résidentiel seulement

Models

VAC7049G

VACUUM CLEANER

ASPIRATEUR

☞Before operating this unit, please read the instructions carefully.

☞Avant de vous servir de cet appareil, veuillez lire les instructions attentivement.

-1

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including the

following:

READ ALL INSTRUCTIONS BEFORE USING THIS

VACUUM CLEANER.

WARNING

To reduce the risk of fire, electric shock, or injury.

1. Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.

2. Do not use outdoors or on wet surfaces.

3. Do not allow to be used as a toy. Close attention is necessary when used by or near children.

4. Use only as described in this manual. Use only manufacturer’s recommended attachments.

5. Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped,

damaged, left outdoors, or dropped into water, take it to a service center.

6. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp

edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.

7. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

8. Do not handle plug or appliance with wet hands.

9. Do not put any object into openings. Do not use with any opening blocked: keep free of dust, lint,

hair, and anything that may reduce air flow.

10. Keep hair, loose clothing, fingers, and all other parts of the body away from openings and moving

parts.

11. Do not vacuum anything that is burning or smoking, such as cigarettes, matches, or hot ashes.

12. Do not use without dust bag and filters in place.

13. Turn off all controls before unplugging.

14. Use extra care when cleaning on stairs.

15. Do not use to vacuum flammable or combustible liquids such as gasoline or use in areas where

they may be present.

16. Store your vacuum cleaner indoors in a cool, dry area.

17. Do not use extension cords or an outlet with inadequate current carrying capacity.

18. Hold plug when rewinding onto cord reel. Do not allow plug to whip when rewinding.

19. Always turn off this appliance before connecting or disconnecting turbine nozzle.

20. Unplug before connecting turbine nozzle.

SAVE THESE INSTRUCTIONS

To reduce the risk of electric shock, this appliance has a polarized plug(one blade is wider than the

other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet,

reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not

change the plug in any way.

-2

PARTS IDENTIFICATION

Features marked with * may vary according to model.

ASSEMBLING THE VACUUM CLEANER FOR USE

▲

1) Connect the suction hose to the suction

tube.

3) Connect the nozzle to the suction tube.

2) Connect the suction tubes together

(depending on model).

4) Connect the hose clamper to the body of

the cleaner.

-3

HANDLE SUCTION HOSE

TOOL STORAGE COVER

DUST-FULL INDICATOR

CORD REWIND BUTTON

POWER CONTROL SWITCH*

ON/OFF BUTTON

CLAMPER FOR DUST BAG

COMPARTMENT

AIR REGULATOR

TUBE*

FLOOR NOZZLE* RUG/FLOOR SELECTOR

BUTTON FOR

SUCTION HOSE

REMOVAL

CARRYING

HANDLE

POWER CORD

ON/OFF SWITCH

1) PULLING OUT

The power cord is long enough to be drawn out

for convenience.

2) REWINDING

When you have finished cleaning, disconnect the

plug from the electrical outlet and simply press

the cord rewind button lightly with your toe.

With the cord plugged into an electrical outlet, start

or stop the vacuum cleaner by pushing lightly down-

ward on the switch with your toe.

POWER CONTROL (VARIABLE CONTROL TYPE ONLY)

The vacuuming power can be adjusted to suit any

situation with the electrical power control.

MIN = For delicate fabrics, e.g. net curtains.

MAX = For hard floors and heavily soiled carpets.

NOTE: When removing the power cord from the electrical outlet, grasp the plug, not the cord.

-4

-5

DUST-FULL INDICATOR

USING THE ACCESSORIES

If the “Dust-Full” indicator changes to “RED” while you are cleaning, the dust bag requires replacement.

NOTE: If the “Dust-Full” indicator continues to display “RED” even after changing the dust bag,

turn the cleaner off and check whether the hose, tube or nozzle is clogged.

Pull the tool storage cover upward.

• Crevice tool: for radiators, crevices, corners, between

cushions.

• Upholstery brush: for cushions and drapery.

• Dusting brush: for furniture, shelves, books, etc.

USING THE BLOWER

Located on the left rear side of the cleaner.

1) Disconnect the hose from the body of the cleaner.

2) Connect the hose clamper to the blow hole.

DUSTING BRUSH

CREVICE TOOL

UPHOLSTERY

BRUSH

CREVICE DUSTING

UPHOLSTERY

-6

PARK POSITION

Located in the top rear side of the vacuum cleaner,

there is a nozzle support that can be used to park

the nozzle during pauses in cleaning.

TRANSPORTING AND STORING THE VACUUM CLEANER

For easy storage and transportation, this vacuum

cleaner has a clip system built onto the body, which

will keep the tube, hose and nozzle in a vertical

position.

REPLACING THE DUST BAG

1) To open the dust cover of the dust bag compart-

ment, press the clamper upward.

(The clamper is located at the front of the dust cover)

2) Remove the carrying bag from the cleaner

-7

NOTE: Used dust bag can be sealed by remov-

ing the film from the paper and sticking

the latter over the suction opening.

TROUBLESHOOTING

FOR CLOTH FILTER BAG

MAINTENANCE OR REPLACEMENT OF THE FILTERS

PROBLEM CAUSE REMEDY

Motor does not start. No power supply. Check cable, plug and socket.

Suction force is gradually Filter, nozzle, suction hose or Remove the object.

decreasing. tube is blocked.

Cord does not rewind fully. Check that the cord is Pull the cord out 2~3 m. & push

not twisted or wound unevenly. down the Cord rewind button.

After using, if the cloth filter bag is full of dust, clean the cloth filter bag and use it again.

1) INLET-FILTER.

• Open the dust cover.

•

After detaching the filter, wash it lightly with water, dry

it in the shade, then insert it in its original position.

• Close the dust cover.

2) OUTLET-FILTER.

• Open the dust cover, then pull the grille-filter

forward.

• Remove and replace the eshausted outlet-filter.

•

Push the grille filter back, then close the dust cover.

3) After removing the used dust bag, insert the

cardboard bag collar of the new dust bag into

the carrying bag, and then insert it in its origi-

nal position

4) Press the dust cover down gently until the

clamper relocks.

-1

CONSIGNES DE SÉCURITÉ IMPORTANTES

Lors de l’utilisation de tout appareil électrique, il est important de prendre des précautions telles que

les suivantes :

LIRE TOUTES LES INSTRUCTIONS AVANT D’UTILISER

CET ASPIRATEUR

AVERTISSEMENT

Pour réduire le risque d’accident, de chocs électriques ou de blessures.

1. Ne pas laisser l’appareil branché, débrancher l’appareil de la sortie électrique lorsqu’il n’est pas util-

isé et avant un appel de service.

2. Ne pas l’utiliser à l’extérieur ou sur une surface mouillée.

3. Ne pas utiliser comme jouet. Faire attention lorsque l’appareil est utilisé près d’enfants.

4. Utiliser seulement tel que décrit dans ce manuel. N’utiliser que les accessoires recommandés par le

manufacturier.

5. Ne pas utiliser si le cordon ou la fiche sont endommagés. Si l’appareil ne fonctionne pas de façon

normale, s’il a été échappé, endommagé, laissé à l’extérieur, ou immergé dans l’eau, il faudra l’ap-

porter au centre de service.

6. Ne pas tirer sur le cordon ou prendre l’appareil par le cordon, ne pas utiliser le cordon comme une

poignée, ne pas fermer la porte sur le cordon ou tirer sur le cordon pour qu’il fasse le tour d’objets

pointus ou de coins pointus. Ne pas passer l’aspirateur sur le cordon. Ne pas placer le cordon près

d’une surface qui dégage de la chaleur.

7. Ne pas tirer sur le cordon pour débrancher l’appareil. Pour débrancher l’appareil, prendre la fiche et

non le cordon.

8. Ne pas manipuler le cordon ou la fiche avec les mains mouillées.

9. Ne pas insérer d’objets dans les ouvertures de l’appareil. Ne pas utiliser si les ouvertures sont

obstruées; enlever la poussière, cheveux et tout ce qui pourrait réduire la circulation d’air.

10. Ne pas approcher les cheveux, vêtements décontractés, doigts et toute autre partie du corps qui

pourrait obstruer les ouvertures et pièces mobiles.
