Sangean PR-D18 Manuale utente

Version 1

中文

PR-D18

Important safety instructions

10.

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with

the manufacturer’s instructions.

Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that

produce heat.

Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other.

A grounding type plug has two blades and a third grounding prong.

The wide blade or the third prong are provided for your safety. If the

provided plug does not t into your outlet. Consult an electrician for

replacement of the obsolete outlet.

Protect the power cord from being walked on or pinched particularly

at plugs, convenience receptacles, and the point where they exit

from the apparatus.

11.

12.

13.

14.

15.

16.

17.

Only use attachments/accessories specied by the manufacturer.

Use only with the cart, stand, tripod, bracket, or table specied by

the manufacturer, or sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus combination to avoid

injury from tip-over.

Unplug this apparatus during lightning storms or when unused for

long periods of time.

Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way, such

as power-supply cord or plug is damaged. liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has

been dropped.

To Reduce the Risk of Fire or Electric Shock, Do not Expose This

Appliance To Rain or Moisture.

The Shock Hazard Marking and Associated Graphical Symbol is

provided on the rear of unit.

Apparatus shall not be exposed to dripping or splashing and no

objects lled with liquids, shall be placed on the apparatus.

18.

19.

20.

Excessive sound pressure on ear- and headphones could impair

the hearing ability. Higher setting that idle on the equalizer leads to

higher signal voltages on the output for ear and headphones.

The power plug should be close to the radio, and easy to be

approached that during the emergency, to disconnect the power

from the radio, just unplug the power plug from the AC power slot.

Where the MAINS plug or an appliance coupler is used as the

disconnect device, the disconnected device shall remain readily

operable.

IMPORTANT NOTE:

To comply with the FCC RF exposure compliance requirements,

no change to the antenna or the device is permitted. Any change to

the antenna or the device could result in the device exceeding the

RF exposure requirements and void user’s authority to operate the

device.

Control

Speaker

Band / step button

Buzzer alarm button

Radio alarm button

Volume up / down button

LCD display

Power / Sleep button

Tuning up / down button

Display / Clock set button

Preset button

Headphone socket

DC jack socket

Battery compartment

Key lock switch

Telescopic aerial

Icon display

FM/AM indicator

PM indicator

Stereo indicator

Buzzer alarm indicator

Radio alarm indicator

Sleep timer indicator / Snooze indicator

Key lock symbol

Battery indicator

Volume indicator

Preset indicator

Frequency / Clock display

Using the radio for the rst time

Battery operation

1. Remove the battery cover on the rear of the unit by pressing the

catch.

2. Insert four UM-3 (AA size) batteries into the spaces in the compartment.

3. Take care to ensure all batteries are inserted with correct polarity

as shown on the rear cabinet. Replace the battery cover.

4. Reduced power, distortion, “stuttering sound” and the battery

icon ashing on the display are all signs that the batteries need

replacing.

5. If the radio is not to be used for any extended period of time, it is

recommended that the batteries are removed from the radio.

Using the AC power adaptor

The AC power adaptor required for this unit should be 6 volts DC at

0.4 A center pin positive.

Insert the adaptor plug into the DC socket on the left side of the

radio.

Plug the adaptor into a standard mains socket outlet.

Whenever the adaptor is used, the batteries are automatically

disconnected.

The AC adaptor should be disconnected from the main supply when

not in use.

Operating your radio - Search tuning AM / FM

1. Fully extend the antenna above the radio. Press the Power button

to switch on your radio.

2. Press the Band button to select the required band.

3. Press and hold the Tuning up/ down button to start the search

tuning. Your radio will scan in an upwards direction (low frequency

to high frequency) or downwards direction (high frequency to low

frequency) and stop automatically when it finds a station of

sufcient strength.

4. To find other stations, press and release the Tuning Up / Down

buttons.

5. Adjust the volume by pressing the Volume up/down button to the

required setting.

Note:

(1) FM stereo is only available when using headphones.

(2) To see time or frequency on the screen, press the Display button.

Manual tuning – AM / FM

1. Press the Power button to switch on your radio.

2. Press the Band button to select the required band. Fully extend

the antenna for best reception.

3. Press and release the Tuning up/down button to tune to a station.

The FM frequency will change in steps of 50/100kHz and AM

frequency will change in steps of 9/10kHz.

4. When the waveband end is reached the radio will recommence

tuning from the opposite waveband end.

5. Set the Volume using the Volume Up/Down buttons to the desired

settings.
