Sanyo XACTI VPC-SH1EX Istruzioni per il montaggio
VPC-SH1EX
VPC-SH1
VPC-SH1GX
VPC-SH1PX
VPC-SH1TA
GUIDE FOR
BASIC OPERATION
Dual Camera
Please read these instructions carefully before using the camera.
Make sure to read and understand the separate booklet “SAFETY MANUAL”.
Keep this manual in a safe place for later reference.
Important note
This manual explains how to safely operate the VPC-SH1EX, VPC-SH1, VPC-
SH1GX, VPC-SH1PX and VPC-SH1TA.
Any information regarding only one of these products will be labeled as such.
iEnglish
Warning
TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
FOR AMERICAN USERS
The following advisory is included in accordance with the laws of the State of
California (USA):
WARNING:
This product contains chemicals, including lead, known to the State of
California to cause cancer, birth defects or other reproductive harm. Wash
hands after handling.
iThis equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
hReorient or relocate the receiving antenna.
hIncrease the separation between the equipment and receiver.
hConnect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
hConsult the dealer or an experienced radio/TV technician for help.
iChanges or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Declaration of Conformity
Model number: VPC-SH1
Trade Name: SANYO
Responsible party: SANYO North America Corporation
Address: 21605 Plummer Street, Chatsworth, California 91311
Telephone No.: (818) 998-7322
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interfer-
ence that may cause undesired operation.
English ii
FOR CANADIAN USERS
iThis Class B digital apparatus complies with Canadian ICES-003.
FOR EU USERS
The symbol mark and recycling systems described below apply to EU
countries and do not apply to countries in other areas of the world.
Your SANYO product is designed and manufactured with high quality
materials and components which can be recycled and/or reused.
The symbol mark means that electrical and electronic equipment, batteries
and accumulators, at their end-of-life, should be disposed of separately from
your household waste.
Note:
If a chemical symbol is printed beneath the symbol mark, this chemical
symbol means that the battery or accumulator contains a heavy metal at a
certain concentration. This will be indicated as follows: Hg: mercury, Cd:
cadmium, Pb: lead
In the European Union there are separate collection systems for used
electrical and electronic equipment, batteries and accumulators.
Please, dispose of them correctly at your local community waste collection/
recycling centre.
Please, help us to conserve the environment we live in!
FOR RUSSIAN USERS
This product is certified by an official certification company
which is authorized by the Russian Federation.
SANYO Sales & Marketing Europe GmbH
Stahlgruberring 4, D-81829 München, Germany
SANYO Electric Co., Ltd.
1-1, Sanyo-cho, Daito City, Osaka 574-8534, Japan
iii English
HOW TO READ THIS MANUAL
For first-time users
Please read this manual to familiarize yourself with your camera’s
operation.
↓
To use the various camera features
The Instruction Manual that explains the features in detail can be
obtained from our website (page 48).
↓
To use additional features
Visit the Sanyo website to learn how to adjust the camera settings for
various shooting scenes. There you’ll also find information about the
software for playing back data recorded with your camera and for
burning (recording) DVDs.
You may find the answers to questions or problems concerning camera
operation in the sections “COMMONLY ASKED QUESTIONS” (page 54).
Symbols used in this manual
HINT Points giving some extended instructions or special points to pay
attention to.
CAUTION Points that require special attention.
(page xx) Refer to the page indicated for detailed information.
English iv
SHOOT, PLAY BACK AND SAVE
Preparing the camera
1 Connect the AC adaptor to the camera.
About saving your recorded data
hIf you wish to use an SD Memory Card, refer to page 12 to install the
card in the camera.
hAn SD Memory Card is not included with your camera. Please
purchase a commercially sold card.
This camera has an internal memory, so you can shoot and record
without an SD Memory Card installed.
1Open
AC adaptor
DC IN terminal cover
To power outlet
vEnglish
SHOOT, PLAY BACK AND SAVE
Shooting
1 Press the ON/OFF button
for at least 1 second to
turn the camera on.
hIf the screen to set the
date and time appears,
press the MENU button 2
times to cancel it.
For how to set the date
and time, see page 22.
2 Record.
To record a video clip:
hPress the [ ] button to
begin recording a video
clip.
hPress the [ ] button
again to end the
recording.
To take a photo:
hPress the [ ] button.
hA still image is captured.
15 000:00:22
15 000:00:22
15 000:00:22
Full-HD
10
M
ON/OFF button
[ ] button
[]button
MENU button
English vi
Before capturing those important shots, be sure to first take a
test shot to confirm that your camera is set up and ready to go
i
Sanyo declines any claim for compensation for recorded contents etc. in case
of photographing or recording failure due to a chance camera or card flaw.
Playback
1 Press the REC/PLAY
button.
hThe display changes to
the Playback Screen.
2 Select the image to play
back.
hToggle the SET button
left, right, up or down to
move the orange frame
to the image you wish to
play back.
hThe image information
for the framed image is
shown in the bottom
part of the monitor.
3 Press the SET button.
hPlayback begins.
<To return to the
recording mode>
hPress the REC/PLAY
button.
100-0006
00:00:05
6.5MB
OK
Full-HD
SET button
REC/PLAY button
Remaining battery power Indication
Orange frame
vii English
SHOOT, PLAY BACK AND SAVE
Deleting files
1 On the screen in step 2, move the orange frame to the file you wish
to delete, and press the MENU button.
2
Select “DELETE”,
and press the SET button.
3 Select “DELETE SINGLE”, and press the SET button.
4
Select “DELETE”,
and press the SET button.
hIf you toggle the SET button to the left or right, the screen to delete a
different file will appear.
5 When you are finished deleting files, press the MENU button.
hPressing the MENU button 3 times will return you to the screen in step
2.
When you are finished using the camera...
Press the ON/OFF button for at least 1 second to turn the camera off.
To continue to the next operation...
Please confirm that your computer is connected to the Internet.
English viii
Burn your recorded video clips onto a DVD
Using the supplied CD-ROM (Xacti Software CD), you can store your
captured images on a DVD.
Install application program
1 Set the supplied CD-ROM in your computer’s DVD drive.
hThe installation window opens.
2 Click on [TotalMedia Extreme for SANYO].
hAfter clicking on the application program, follow the instructions shown
on the monitor to install the program.
hWhen the window appears requesting to restart your computer, click
the [Finish] button to reboot.
3 Remove the CD-ROM from the computer’s DVD drive.
<About the Kodak online service>
hWhen the installation window closes, a dialog box to connect to the
website introducing Kodak’s online service appears. Check the [No
thanks !] option button, and then click on the [OK] button.
ix English
SHOOT, PLAY BACK AND SAVE
Connect your camera to a computer
Connect your camera to a computer, and copy the desired files to the
computer.
1 Use the supplied dedicated USB interface cable to connect your
camera to the computer.
2 Turn on the camera.
hThe USB Connection Screen appears on the camera’s monitor.
COMPUTER
PRINTER
CANCEL
OKCANCEL
USB CONNECTION
To USB connector on the
computer
Supplied dedicated USB
interface cable
To USB/AV
terminal
* Connect with the [n] mark facing downwards.
