Sanyo CM14SW8S Manuale utente
POLYPRO 0.12U J 200V
ASSY,PWB,MAIN F8STG
414 009 5001
645 027 5739
403 082 6916
403 082 6916
403 082 7408 POLYPRO 0.15U J 200V
Page &
Section Key No
C441
L902 610 224 5783
Page 20
CRT A34KPU02XX
DEFLECTION YOKE
610 295 4333
POLYPRO 0.12U J 200V
C442 403 082 7408 POLYPRO 0.15U J 200V
SERVICE MANUAL
(SUPPLEMENT) Colour Television
Product Code:
1 113 506 13 (CM14SW8S)
1 113 506 33 (CM14SW8SA)
1 113 507 13 (CM20SW8S)
1 113 507 33 (CM20SW8SA)
1 113 508 13 (CM21SW8S)
1 113 508 33 (CM21SW8SA)
Original Version
Chassis Series: AC3-A
FILE NO.
Service Ref. No. CM14SW8S-00
CM14SW8SA-00
CM20SW8S-00
CM20SW8SA-00
CM21SW8S-00
CM21SW8SA-00
(Middle East)
Give complete “SERVICE REF. NO.” for parts
order or servicing.It is shown on the rating plate
at the cabinet back of the unit.
TV/AVM
VIDEOAUDIO
P
-NOTE-
These models (CM14SW8S, CM14SW8SA, CM20SW8S, CM20SW8SA, CM21SW8S,
CM21SW8SA) are electrically similar to original models (CM14SW8, CM14SW8A, CM20SW8,
CM20SW8A, CM21SW8, CM21SW8A).
Any information not contained in this manual will be found in the original model’s service manual
SM5110013 (Issue date-Nov., 1999).
REFERENCE NO. SS 5110250
CRT A34LRQ91X
414 010 3201
Q901
Page 17
Part No. Description
DEFLECTION YOKE
Model CM14SW8 & CM14SW8A Model CM14SW8S & CM14SW8SA
Part No. Description
-
610 284 2340 ASSY,PWB,MAIN F8ST
DIFFERENCES
CHASSIS ELECTRICAL PARTS LIST
F8SR/F8SRA/F8TR/F8TRA/F8VR/F8VRA
Model No. CM14SW8S
CM14SW8SA
CM20SW8S
CM20SW8SA
CM21SW8S
CM21SW8SA
TV/AVM
VIDEOAUDIO
P
TV/AVM
VIDEOAUDIO
P
TV/AV M
VIDEOAUDIO
P
Cabinet Parts List F8SR/F8SRA
1 610 263 3887 BUTTON POWER
610 229 8406 SPRING
2 610 291 7062 BUTTON UNITED
3 610 291 7222 DEC SHEET
4 610 291 6980 ASSY,CABINET FRONT
5 645 023 4316 BADGE,SANYO
6 610 292 0604 CABINET BACK
7 610 294 4792 LABEL RATING (CM14SW8S)
610 294 4808 LABEL RATING (CM14SW8SA)
8 610 011 6405 ROD ANTENNA ASSY
or 610 216 4886 ROD ANTENNA ASSY
or 610 217 1006 ROD ANTENNA ASSY
or 645 012 0428 ROD ANTENNA ASSY
or 645 042 4519 ROD ANTENNA ASSY
9 645 003 2837 ANT MATCHING BOX
or 610 230 3216 ANT MATCHING BOX
10 645 045 8606 ASSY,REMOCON JXMPA
11 610 291 6829 RC-BATTERY LID
610 293 8326 INSTRUCTIONS MANUAL
(English)
610 294 4365 INSTRUCTIONS MANUAL
(Arabic)
610 294 4372 SIMPLIFIED INST
(Spanish/Russian)
Key No. Part No. Description Key No. Part No. Description
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
0
7
14
8
5
23
6
9
P▲
P▼
BASS
JXMPA
PIC MODE SWAP
MENU
-/--
PP
TV/AV
A/B
CH SCAN
TIMER
10 11
Model CM14SW8S/CM14SW8SA
8
9
1
2
3
4
5
ANT. 75Ω
VIDEO IN
VIDEO OUT
AUDIO OUT
AUDIO IN
6
7
-2-
Cabinet Parts List
-3-
1 610 263 3887 BUTTON POWER
610 229 8406 SPRING
2 610 294 5676 BUTTON UNITED
3 610 294 5683 DEC SHEET
4 610 291 6973 ASSY,CABINET FRONT
5 645 023 4316 BADGE,SANYO
6 610 292 0598 CABINET BACK
7 610 294 4846 LABEL RATING (CM20SW8S)
610 294 4853 LABEL RATING (CM20SW8SA)
8 610 011 6405 ROD ANTENNA ASSY
or 610 216 4886 ROD ANTENNA ASSY
or 610 217 1006 ROD ANTENNA ASSY
or 645 012 0428 ROD ANTENNA ASSY
or 645 042 4519 ROD ANTENNA ASSY
9 645 003 2837 ANT MATCHING BOX
or 610 230 3216 ANT MATCHING BOX
10 645 045 8606 ASSY,REMOCON JXMPA
11 610 291 6829 RC-BATTERY LID
610 293 8326 INSTRUCTIONS MANUAL
(English)
610 294 4365 INSTRUCTIONS MANUAL
(Arabic)
610 294 4372 SIMPLIFIED INST
(Spanish/Russian)
Key No. Part No. Description Key No. Part No. Description
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
Model CM20SW8S/CM20SW8SA
F8TR/F8TRA
TV/AVM
VIDEOAUDIO
P
VIDEO IN
VIDEO OUT
AUDIO OUT
AUDIO IN
ANT. 75Ω
0
7
14
8
5
23
6
9
P▲
P▼
BASS
JXMPA
PIC MODE SWAP
MENU
-/--
PP
TV/AV
A/B
CH SCAN
TIMER
10 11
8
9
21
6
5
43
7
Cabinet Parts List
A14800 /May /’01 /300 BB SANYO Electric Co.,Ltd.
Printed in Japan
1 610 265 6381 BUTTON POWER
610 229 8406 SPRING
2 610 294 5980 BUTTON UNITED
3 610 294 6000 DEC SHEET
4 610 291 6997 ASSY,CABINET FRONT
5 645 003 9256 BADGE,SANYO
6 610 292 0611 CABINET BACK
7 610 294 4891 LABEL RATING (CM21SW8S)
610 294 4907 LABEL RATING (CM21SW8SA)
8 645 004 8616 ROD ANTENNA ASSY
or 645 004 8753 ROD ANTENNA ASSY
9 645 003 2837 ANT MATCHING BOX
or 610 230 3216 ANT MATCHING BOX
10 645 045 8606 ASSY,REMOCON JXMPA
11 610 291 6829 RC-BATTERY LID
610 293 8326 INSTRUCTIONS MANUAL
(English)
610 294 4365 INSTRUCTIONS MANUAL
(Arabic)
610 294 4372 SIMPLIFIED INST
(Spanish/Russian)
Key No. Part No. Description Key No. Part No. Description
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
Model CM21SW8S/CM21SW8SA
F8VR/F8VRA
TV/AV M
VIDEOAUDIO
P
ANT. 75Ω
VIDEO IN
VIDEO OUT
AUDIO OUT
AUDIO IN
0
7
14
8
5
23
6
9
P▲
P▼
BASS
JXMPA
PIC MODE SWAP
MENU
-/--
PP
TV/AV
A/B
CH SCAN
TIMER
10 11
8
9
1
2
3
4
5
6
7
