DR300 Quick Guide Pg32
Separate sheet 3 (Protocol setting)
7 8 Content
ON ON (Reserved)
ON OFF STATUS 3
OFF ON XON-XOFF
OFF OFF Ready/Busy
DIPSW 2
No. Setting Content
ON Direct Thermal1 OFF Thermal Transfer
ON (Reserved) / Reflecting type sensor2 OFF (Reserved) / See through type sensor
ON Head Check, Yes3 OFF Head Check, No
ON Hex dump function, Yes4 OFF Hex dump function, No
ON Multi items receive mode5 OFF 1 item receive mode
ON (Reserved)6 OFF (Reserved)
ON Size detection, Yes7 OFF Size detection, Yes
ON Tear off (Dispense), Yes8 OFF Tear off (Dispense), No
* Pitch sensor (DSW2-2) is effective only during service, test print. It is void during test print.
DR300 Quick Guide Pg1
Table of Contents
What You Get …………………………………………………………….. 2
Unpacking ………………………………………………………………… 3
Unpacking – Touch Screen (Optional Item) ……………………... 4
Accessories Checklist …………..................................................... 5
Name of Parts …………………………………………………………….. 6
Touch Screen / Keypad ………………………………………….. 7
Operation Panel Unit …………………………………………….. 8
Card Cover Unit …………………………………………………. 9
Back Panel Unit ………………………………………………….. 9
Media Loading …………………………………………………………… 10
Setting of Label and Carbon Ribbon …………………………….. 10
Setting Rolled Paper ……………………………………………... 10
Setting Large Diameter Rolled Label ……………………………. 13
Setting Carbon Ribbon …………………………………………… 14
Pitch Sensor Adjustment ………………………………………………… 16
Power Supply ……………………………………………………………... 18
Simple Troubleshooting ………………………………………………….. 20
Daily Maintenance ………………………………………………………... 23
Serial Interface ……………………………………………………………. 26
Specifications ……………………………………………………………… 27
Basic Specifications ……………………………………………… 27
Label and Carbon Ribbon Specifications ………………………… 28
Operating Environment Condition ……………..………………… 29
DR300 Software Specifications ………………………………….. 29
Printer Main Body Operation Unit ……………………………………… 30
DIP-Switch Setting ………………………………………………………... 31
DIPSW 2 …………………………………………………………………… 32
DIPSW 3 …………………………………………………………………… 33
