SATO RWG500 Manuale utente

Quick Guide

for

RWG500

Label Rewinder

PN 9001128A

Introduction

Thank you for your purchase of the SATO RWG500 new

generation rewinder for SATO barcode printers.

This quick reference guide will lead you on a familiariza-

tion tour to help you start using the machine as soon as

possible.

To get the most out of the RWG500’s intelligent features,

make sure to read this manual carefully before using the

machine.

Table of Contents

Introduction.......................................................2

Safety Symbols ................................................3

Safety Precautions ..........................................4

FCC Notice ......................................................6

What’s In the Box ............................................7

Parts Identification ...........................................8

Parts Identification ...........................................9

Preparing the Joint Plate .................................10

Adjusting the Roller Height ...............................14

Installing the Joint Plate ...................................15

Label Setup ......................................................17

Basic Operation ...............................................23

Winding 6” labels ..............................................25

Installing the 6” Expansion Kit ..........................26

Basic Specifications..........................................27

Safety Symbols

About warning symbols

As a preventive measure to ensure safe usage of this

machine so as to safeguard against damage to yourself,

other people or property, several symbols and icons are

used in this guide. The following pages describe the

significance of each symbol. Please take time to read and

understand the content.

Examples

The triangle sign means ‘Be careful’.

The content within the triangle illustrates specific

hazards. In this case, the sign on

the left means ‘beware of electric shock’.

The circular sign means ‘prohibited’. The

content within the circle illustrates a specific

prohibition. In this case the sign on the left means

‘disassembly prohibited’.

The black circular sign means ‘must do’. The

content within the sign illustrates specific items

that must be carried out. In this case the sign on

the left means ‘the plug must be unplugged from

the socket’.

If this display and its warning is ignored, any

mishandling could result in death or serious

injuries.

If this display and its warning is ignored, any

mishandling could result in serious injuries as

well as damage to properties.

Caution

Safety Precautions

Do not place on an unstable place

Do not place the rewinder on an unstable place

such as an unsteady table, an inclined place or

a place with vibration. The rewinder may drop

or topple over and cause injuries.

Liquids

Do not place any containers with water or

chemicals, such as flower vases or cups, as

well as small metallic objects near the rewinder.

Continued use creates the danger of fire or

electrical shock.

* If any of these should fall into the rewinder,

immediately turn off the power and contact your

nearest dealer or service center.

Foreign Matter

Do not drop or insert metallic or flammable

objects into the openings on the rewinder.

Continued use creates the danger of fire or

electrical shock.

* If any of these should fall into the rewinder,

immediately turn off the power and contact your

nearest dealer or service center.

Dropping and Damage

Do not use if the product has been dropped or

damaged. Continued use creates the danger of

fire and electrical shock.

* Should the rewinder ever fall or otherwise

become damaged, immediately turn off the

power and contact your nearest dealer or

service center. Continued use creates the

danger of fire or electrical shock.

Caution

Abnormal Conditions

Do not use the rewinder if it is emitting smoke

or strange odors. Continued use creates the

danger of fire and electrical shock.

* Immediately turn off the power and contact

your nearest dealer or service center for

repairs. Do not try to service the rewinder by

yourself.

Disassembly

Never try to take the unit apart or modify it in

any way. Doing so creates the danger of fire or

electrical shock. Contact your nearest dealer or

service center for repairs.

Location

Do not locate the rewinder in areas subjected to

high humidity or dew. Doing so creates the

danger of electrical shock.

* If dew forms inside the rewinder, immediately

turn off the power and do not use it until it has

dried up.

FOR CONTINUED PROTECTION AGAINST

RISK OF FIRE.

REPLACE ONLY SAME TYPE AND RATING

OF FUSE.

LOCATION : F1 , F2 RATING : 125V 3.5A

Caution

FCC Notice

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation.

This equipment generates use and can radiate radio frequency energy and, if

not installed and used in accordance with instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation.

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the

following measures:

- Reorient or re locate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

What’s In the Box

RWG500 main unit Joint plate

EXT cable

Label Clip

3-inch core x 2 Label Guide

Quick Guide

Parts Identification

Second roller

First roller

Tension arm

Rewind

Start/Stop

button

Status

LED

Direction

Indicator LED:

Clockwise

winding

(face in)

Direction

Indicator LED:

Counter-clock-

wise winding

(face out)

Stopper

Plate

Rewind

Core

Parts Identification

Selector for

clockwise or

counterclock-

wise rewind

direction

Socket for

AC adaptor

EXT connector

(links to printer)

Earth

terminal

Power

Switch

Preparing the Joint Plate

The joint plate aligns the base of the RWG500 to the

base of a SATO printer. This alignment ensures a smooth

label path and prevents problems during long periods of

continuous operation.

The following procedure adjusts the joint plate to suit the

base of different SATO printers, as shown here:

Use a Phillips

screwdriver

to loosen the

two screws

that secure

the movable

portion of the

joint plate.

Slide the movable

portion of the joint

plate in various

directions to

reveal the names

of various SATO

printer models.

Main plate

Movable plate
