SERVICE DOCUMENT

CTS Service Manual

December, 2022

Published, December, 2022

Updates of this manual may be available at SawStop.com

SawStop, the SawStop blade logo, and the configuration of this product are either registered trademarks or

the following U.S. patents: 6857345, 6997090, 7024975, 7098800, 7100483, 7197969, 7210383, 7225712, 7231856,

7284467, 7308843, 7350445, 7481140, 7536238, 7600455, 7610836, 7644645, 7707918, 7788999, 7971613, 7991503,

7997176, 8011279, 8061245, 8079292, 8079295, 8087438, 8469067, 8489223, 8505424, 8646369, 9623498, 9724840,

9844891, 10022811, 10052786, 10071499, 10118308, 10442107, 10442108, 10864651, 10875210, 10882207, 10933554,

10967536, 11027452, 11098849, 11273504. Additional U.S. and foreign patents pending.

Warranty

SawStop warrants to the original retail purchaser of a new Compact Table Saw from an authorized SawStop

distributor that the saw will be free from defects in material and workmanship for ONE YEAR from the date of

purchase.

This warranty does not apply to defects arising from misuse, abuse, negligence, accidents, normal wearand-tear,

unauthorized repair or alteration, or lack of maintenance. This warranty is void if the saw or any portion of the saw

is modified without the prior written permission of SawStop, LLC, or if the saw is located or has been operated

outside of the country where the authorized SawStop distributor from whom the saw was purchased resides.

Please contact SawStop to take advantage of this warranty. If SawStop determines the saw is faulty in material or

workmanship, and not due to misuse, abuse, negligence, accidents, normal wear-andtear, unauthorized repair or

alteration, or lack of maintenance, then SawStop will, at its expense, and upon proof of purchase, send replacement

parts to the original retail purchaser necessary to cure the defect. Alternatively, SawStop will repair the saw

provided the saw is returned to SawStop, shipping prepaid, with proof of purchase and within the warranty period.

SawStop disclaims any and all other express or implied warranties, including merchantability and fitness for a

particular purpose. SawStop shall not be liable for death, injuries to persons or property, or incidental,

consequential, contingent or special damages arising from the use of the saw.

This warranty gives you specific legal rights. You may have other rights, which, in the United States, vary from state

to state.

Revision History

Version Date Description

1.0 November 2022 Initial Release

Table of Contents

Motor Cover (CTS-015) 1

Trunnion Motor Cover (CTS-016) 6

Dust Shroud (CTS-013) 10

Fence Rails (CTS-002, CTS-003) 14

Fence Rail Guides "Pucks" (CTS-005) 21

Rail Lock Handle (CTS-010) 26

Rail Lock Pinion (CTS-011) 31

Elevation Control Shaft (CTS-036) 38

Rail Lock Rocker (CTS-012) 44

Switch Box Assembly (CTS-038) 49

Alignment Block (CTS-032) 54

U-Joint (CTS-037) 60

Retraction Bracket (CTS-029) 65

Brake Cartridge Bracket (CTS-027) 72

Motor/Gear Box Assembly (CTS-042, CTS-043) 78

Contact SawStop 83

Motor Cover (CTS-015)

Use the instructions in this chapter to install the Motor Cover service kit you received.

WARNING:

To ensure safety during maintenance, disconnect all electrical power to the saw and remove

the saw blade.

NOTE:

For an optimal experience using this service manual, begin maintenance on your saw by

starting with the chapter most directly associated with the CTS service kit you received

containing replacement parts.

IMPORTANT:

If you have the optional stand for the CTS, remove the saw from the stand and perform this

maintenance on a suitable workbench.

Certain maintenance operations may be best performed with your CTS tipped on its edge or

perhaps even flipped upside down to rest on its top. As a result, many photos in this service

manual do not depict the CTS in its normal, upright orientation.

Description

The Motor Cover is a curved, plastic shroud visible from the outside of your CTS. It includes an oval pattern of

ventilation holes and some instructional decals on its exterior.

Below are step-by-step instructions for the disassembly required to remove and then replace the Motor Cover. The

disassembly instructions in this section are a common prerequisite to servicing other aspects of your CTS.

1|CTS Service Manual

Motor Cover (CTS-015)

Exploded View

Service Kit Parts List (CTS-015)

ITEM DESCRIPTION QTY

1 Motor Cover 1

2 Screw - M4 x 1.8, 16mm, Button Head, Phillips 5

Tools Required

#2 Phillips Head Screwdriver

Prerequisites

None.

CTS Service Manual |2

Motor Cover (CTS-015)

Disassembly Steps

IMPORTANT: To ensure thorough understanding, please read the instructions all the way

through before starting this procedure.

1. At the front of the saw, adjust the CTS

bevel adjustment to 45 degrees.

2. At the rear of the saw, unlatch and

remove the Accessory Storage

Compartment.

3|CTS Service Manual

Motor Cover (CTS-015)

3. Fasteners are now revealed that

secure part of the

Motor Cover [1]

place. Remove the three

Screws - M4 x

1.8, 16mm, Button Head, Phillips [2]

indicated in the photo.

4. From the left side of your CTS, remove

the two

Screws - M4 x 1.8, 16mm, Button

Head, Phillips [2]

indicated in the photo.

5. The

Motor Cover [1]

is now free. Use the handle at the left side of the saw to tilt your CTS up to rest on its

right side.

CTS Service Manual |4

Motor Cover (CTS-015)

6. Slide the motor cover down and

remove it through the bottom of the

frame of your CTS. Once removed, set

it aside if it is to be re-installed later.

Discard it if a replacement has been

provided in the service kit you received

from SawStop.

Assembly Steps

1. Perform the Disassembly Steps described immediately above in reverse order. If a service kit containing

new parts to replace those removed above was provided, use only the new parts during re-assembly.

2. In reverse order, re-visit each of the chapter(s) listed in the Prerequisites section in this chapter and

perform the Disassembly Steps in reverse order for each.

Inspection Steps

Confirm that the

Motor Cover [1]

is secure. All fasteners should be snug such that the cover does not move or vibrate

when the CTS is running.

5|CTS Service Manual

Motor Cover (CTS-015)

Trunnion Motor Cover (CTS-016)

Use the instructions in this chapter to install the Trunnion Motor Cover service kit you received.

WARNING:

To ensure safety during maintenance, disconnect all electrical power to the saw and remove

the saw blade.

NOTE:

For an optimal experience using this service manual, begin maintenance on your saw by

starting with the chapter most directly associated with the CTS service kit you received

containing replacement parts.

IMPORTANT:

If you have the optional stand for the CTS, remove the saw from the stand and perform this

maintenance on a suitable workbench.

Certain maintenance operations may be best performed with your CTS tipped on its edge or

perhaps even flipped upside down to rest on its top. As a result, many photos in this service

manual do not depict the CTS in its normal, upright orientation.

Description

The Trunnion Motor Cover is a plastic shroud visible from the outside of your CTS. It acts as an extension to the

Motor Cover and covers the Trunnion assembly.

Below are step-by-step instructions for the disassembly required to remove and then replace the Trunnion Motor

Cover. The disassembly instructions in this section are a common prerequisite to servicing other aspects of your

CTS.

CTS Service Manual |6

Trunnion Motor Cover (CTS-016)
