Seagull Models Decathlon 60-85cc-3D Manuale utente

Specications:

Wingspan--------------- 122.0 in (310.0 cm).

Wing area--------------- 2487.8 sq.ins (160.5 sq.dm).

Weight------------------- 26.4-27.4 lbs (12.5-13.0kg).

Length------------------- 84.6 in (215.0 cm).

Engine/Motor size----- 60-85cc gasoline.

Radio--------------------- 7 channels with 9 servos.

ASSEMBLY MANUAL

Code : SEA 314

DECATHLON 60-85cc-3D Instruction Manual.

ank you for choosing the DECATHLON 60-85cc-3D ARTF by SG MODELS . e

DECATHLON 60-85cc-3D was designed with the intermediate/advanced sport y-

er in mind. It is a semi scale airplane which is easy to y and quick to assemble. e air-

frame is conventionally built using balsa, plywood to make it stronger than the av-

erage ARTF, yet the design allows the aeroplane to be kept light. You will nd that

most of the work has been done for you already. e motor mount has been tted and

the hinges are pre-installed. Flying the DECATHLON 60-85cc-3D is simply a joy.

is instruction manual is designed to help you build a great ying aeroplane. Please read

this manual throughly before starting assembly of your DECATHLON 60-85cc-3D Use the

parts listing below to indentify all parts.

Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is ca-

pable of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU

ASSUME ALL RISK & REPONSIBILITY.

If you are inexperienced with basic R/C ight we strongly recommend you contact your R/C

supplier and join your local R/C model Flying Club. R/C Model Flying Clubs oer a variety

of training procedures designed to help the new pilot on his way to successful R/C ight.

ey will also be able to advise on any insurance and safety regulations that may apply.

INTRODUCTION

WARNING

KIT CONTENTS

SEA314 DECATHLON 60-85cc-3D

1. Fuselage

2. Wing set (2)

3. Tail set (2)

4. Canopy

5. Cowling

6. Wing tube

7. Pilot

8. landing gear

9. Fuel tank

10. Tail wheel

11. Pushrod set

12. Ep Motor box

ADDITIONAL ITEMS REQUIRED

TOOLS & SUPPLIES NEEDED

in cyanoacrylate glue.

Medium cyanoacrylate glue.

30 minute epoxy.

5 minute epoxy.

Hand or electric drill.

Assorted drill bits.

Modelling knife.

Straight edge ruler.

2mm ball driver.

Phillips head screwdriver.

220 grit sandpaper.

90° square or builder’s triangle.

Wire cutters.

Masking tape & T-pins.

read-lock.

Paper towels.

�60-85cc gasoline engine.

�Computer radio 7 channel with 9

servos.

�Glow plug to suit engine.

�Propeller to suit engine.

�Protective foam rubber for radio

system.

WINGTIP BULBS

Please see below pictures.

Two white lights for cowling and rud-

der, the green light for right wing tip, and

the red light for le wing tip. ey are

designed to operate on voltages 12 volts.

Connect four lights into switch circuit so

that optional the dierent ashes mode.

DECATHLON 60-85cc-3D Instruction Manual.

10.

11.

12.

13.

14.

15.

17.

16.

18.

19.

DECATHLON 60-85cc-3D Instruction Manual.

20.

21.

22.

23.

INSTALL THE AILERONS

CONTROL HORN

Fiberglass control horn

Epoxy.

24.

Because the size of servos dier, you

may need to adjust the size of the precut

opening in the mount. e notch in the

sides of the mount allow the servo lead to

pass through.

Place the servo between the mounting

blocks and space it from the hatch. Use

a pencil to mark the mounting hole loca-

tions on the blocks.

INSTALLING THE AILERON SERVOS

Use drill bit in a pin vise to drill the mout-

ing holes in the blocks.

Apply 2-3 drops of thin C/A to each of

the mounting holes. Allow the C/A to

cure without using accelerator.

1.5mm

Minimum servo spec.

Torque : 250 oz-in (18 kg-cm) @ 4.8V;

333 oz-in (24 kg-cm) @ 6.0V

Ailerons control horn

Epoxy.

40mm

C/A glue

DECATHLON 60-85cc-3D Instruction Manual.

Apply 1-2 drops of thin C/A to each of

the mounting tabs. Allow the C/A to cure

without using accelerator.

Remove the string from the wing at the

servo location and use the tape to attach

it to the servo extension lead. Pull the lead

through the wing and remove the string.

C/A glue

10.

11.

Set the aileron hatch in place and use a

Phillips screw driver to install it with four

wood screws.

12.

13.

Secure the servo to the aileron hatch us-

ing Phillips screwdriver and the screws

provided with the servo.

Use dental oss or heatshrunk tube to

secure the connection so they cannot be-

come unplugged.

3x10mm

14.

AILERON PUSHROD INSTALLATION

INSTALLING THE FLAP PUSHROD

15.

Attach the ap servo to the ap servo

cover. Center the ap servo (or set the

values to 0 for both up and down) and in-

stall the servo arm perpendicular to the

servo centerline. e clevis will attach to

the arm 13/16 inches (21mm) from the

center of the arm.

150mm.

130mm.

DECATHLON 60-85cc-3D Instruction Manual.

Use a pin vise and 3/32-inch (2mm) drill

bit to clear the paint from the ap control

horn.

Attach the ap linkage to the control

horn. Slide the clevis retainer over the

forks of the clevis.

Route the servo lead for the ap servo out

at the root of the wing. Connect the ap

servo to the radio system. With the radio

system on, place the ap servo into posi-

tion.

Attach the clevis to the ap servo arm.

Adjust the linkage so the ap is in the

mid-ap position. It may take a few tries

to properly adjust the linkage.

Once adjusted, make sure all clevis re-

tainers are in position. Apply a drop of

threadlock near the clevis, then tighten

the nut against the clevis to keep the link-

age from changing length inside the wing.
