GSM / UMTS ( 2G & 3G) ELECTRONIC COUNTERMEASURE UNIT
Covers EGSM900, GSM1800, UMTS2100
Enhanced 3G algorithm to support 3.5G operations
Self calibrating
Synthesizer controlled oscillators with Digital Sweep.
Signal Waveforms optimized for each band
Two AA cells provide up to 6 hours’ operation
Low battery indicator
May be powered externally
Overview
The ECM606 is a small portable unit that is designed to secure areas of up to approximately 20m in
radius. The exact range depending on a variety of factors such distance to a relevant base station
(Mast) and its radiating power, local propagation conditions and the type of antenna used with the
ECM606.
Operation is simple. One switch activates the unit. The indicator LEDs show the operational and
battery status. An internal switch allows the user to select which bands are to be blocked.
Operating instructions
Switching on and blocking
Slide the Power switch to “On”to activate the unit. The Blue On indicator will flash to indicate that
the unit is active.
SECURINESS
ECM606
45 80 33 22 Kontakt os venligst for mere information
Stenlandsvej 12 2300 København S +45 45 80 33 22 www.securiness.com
The Battery LED will indicate Green if battery voltage is OK but will turn to Red if the batteries needs
replacing.
Antenna options
The unit comes as standard with 2 x omni-directional stubby antenna. This antenna gives good
around coverage and is the most convenient for most mobile applications.
Other types of antennas are available; please consult with SECURINESS for the most appropriate
product from its growing range of purpose designed antennas.
Setting the operating band
Remove the battery cover. Locate the 3 position Band switch which is recessed into the inner wall of
the battery compartment.
Position
Left
Centre
Right
Legend
2G
Both
3G
Bands
GSM900 plus
GSM1800
GSM plus UMTS2100
(3G)
UMTS2100 (3G)
Using something like the tip of a ball-pen, select the desired band, and replace the cover. The new
setting takes effect immediately.
Specifications
Blocking
(E) GSM 925-960 MHz
GSM1800 1805-1880 MHz
3G & 3.5G (UMTS) 2110-2170 MHz
Output Power: Hi : 100mW (+20dBm)
The GSM output is time multiplexed between the bands, whilst the UMTS signal is continuous.
Spurious outputs: -110dBrc/Hz at ±5MHz
Power
Internal: two AA (LR6) cells, alkaline or NiMH.
External: 3.3VDC at 600mA max via the mini-jack.
When the external power input is connected, the internal batteries are isolated; they are not charged
from the external source.
“Battery” LED: changes to Red at 2.1V (1.05V per cell).
Blocking time: 4 hrs typical (Both Bands)
6 hrs typical (one band or band pair)
(using 2.5AH cells)
Operating range
The main factor affecting the range of the unit is the proximity and power of the base station / mast
to which the phone is registered. Typical range is 10 –20* meters using the small stubby-antenna.
Stenlandsvej 12 2300 København S +45 45 80 33 22 www.securiness.com
Using alternate antennas which focus the signal into more specific areas increases the effective range
of the unit. The SA918 directional antenna has a 9dBi gain so the ERP (Effective Radiated Power) is
increased from 100mW to approximately 0.5 watt.
*
The exact range depending on a variety of factors such distance to a relevant base station (Mast), its radiating power and
local propagation conditions.
External Connection
The 3.5mm stereo mini-jack permits both external powering and remote control functions. When
connected to our CPD351 radio linked detectors, the 351 supplies the power to the ECM606 unit
whilst the detector can select the most appropriate band or bands to jam the detected cellular signal.
This combination allows the units to function as a responsive/reactive jammer.
External Amplifiers
The output of the ECM606 may be fed into a power amplifier if several watts of jamming power is
needed. The in-band(s) return loss should be better than 2:1 at 50 ohms.
Temperature
Range for normal operation: -10 to +50°C.
Physical
Size: 120 x 64 x 22mm.
Weight: 130g with battery.
Case: ABS to UL94-HB; IP45.
Warning
The use of mobile phone jamming equipment is illegal or restricted in many parts of the world. This unit is sold or supplied on
the basis that the end user is fully responsible for meeting any such local requirements.
