Seitron Wi-time Manuale utente

Quick guide ENG

Touch buttons functionalities

Display icons

Heating mode On WiFi connected

WiFi disabled

(blinking icon)

Thermostat not connected to cloud

Device in conguration mode:

waiting for pairing

Tamper Proof mode On

Permanent Manual Mode

Program mode

Cooling mode On

Temporary Manual Mode (until 24)

Technical features

Type: Semi-recessed programmable thermostat

Available Colors: Black or White

Display: color TFT

Power supply: 100..253Vac 50..60Hz

Power absorption: less than 2W

Relay contacts ratings: max 5A @250V

Wi: 802.11 b/g/n

Temperature adjustment range: +5.0..+40.0 °C (±0.1)

Operation mode heating/cooling

Weekly or manual programming (temporary or permanent)

No-frost function

Settable Boost via App only (30-60-90 minutes)

Predisposition for a remote temperature sensor

Clock with buffer battery set via web

Protection rating: IP 30

Size: 122x82x15 mm

Temperatura sotto controllo

Temperature under control

Seitron Smart

App Android and iOS for Smartphone

Go to www.seitron.it for download instruction manual

WARRANTY

In the view of a constant development of their products, the manufacturer reserves

the right for changing technical data and features without prior notice. The consumer is

guaranteed against any lack of conformity according to the European Directive 1999/44/

EC as well as to the manufacturer’s document about the warranty policy. The full text of

warranty is available on request from the seller.

GIW01MR001SE 033296 141019

Long push (at least 1 sec.): ON/OFF

Brief push: returns to the previous menu Menu, Option selection

Temperature increase,

Moving up with the cursor

Temperature decrease,

Moving down with the cursor

WARNING!

• Before making any connections, make sure the mains power is disconnected.

• Device installation and electrical connections must be carried out by qualied

personnel and must comply with the laws in force.

If a thermostat is already present and it needs to be REPLACED, go to Point 2.

If it is a NEW installation skip to Point 3.

Cut off mains power.

Unhook the old thermostat from the wall and

take a picture of the wirings:

the power wires are usually blue and brown,

the boiler control ones are usually black or

gray.

Once the wires are located, unplug them and

remove the old thermostat.

Insert and x the Wi-Time thermostat

to the wall using the provided screws.

Place back the cover by rst hooking it to

the upper side of the plastic base (1) and

then locking it to the lower side clips (2).

The display shows the blinking icon ‘ ‘

Reconnect the mains power to the thermostat.

Dowload the Seitron Smart App

Start the App, login and complete the Wi-time conguration

Unhook and remove the front cover of the Wi-Time,

from its plastic base underneath, applying pressure

on the 2 clips located on the bottom side of the

thermostat and lifting the cover towards the upper

side.

INSTALLATION

83 mm

GIW01MR001SE 033296 141019

Connect the wires as shown:

4: Common to Boiler

6: Normally open to Boiler

7: Phase (Usually brown)

8: Neutral (Usually blue)

1-2: Remote room temperature

sensor (Optional)
