Sena C1 Manuale utente
C1 Manual
Charging (The Bluetooth / LE function is not working while is charging.)
Red LED: Charging
Blue LED: Fully charged
Power On/Off
Power On : Press and hold the (+) Button and Center Button for 1 second
Power Off : Tap the (+) Button and Center Button.
Volume Adjustment
(+) Button - Increase the volume
(-) Button - Decrease the volume
Battery Check
Phone, Music Pairing
Initially Pairing the C1
The Bluetooth system will automatically enter the phone pairing mode
when you initially turn on the Bluetooth system or in the following
situation:
• Rebooting after executing Factory Reset
1. Press and hold the Center Button and (+) Button for 1 second.
2. Search for Bluetooth devices on your mobile phone. Select the C1 in the list of the devices
detected on the mobile phone.
3. Enter 0000 for the PIN. Some mobile phones may not ask for the PIN.
Music Operation
Play or pause music: Press the Center Button for 1 second.
Track back: Press the (-) Button for 1 second.
Track forward: Press the (+) Button for 1 second.
Mobile Phone Call Making and Answering
Answering a call: Tap the Center Button
Ending a call: Press the Center Button for 2 seconds.
Voice dial: Press the Center Button for 3 seconds.
Speed dial: Press the (+) Button for 3 seconds.
Rejecting a call: Press the (+) Button for 2 seconds.
Intercom
Intercom Pairing
1. Press and hold the Center Button of two headsets for 5 seconds until red LEDs of both units
start to flash rapidly.
2. Simply tap the Center Button of any one of the two headsets.
Intercom Start/End : Tap the Center Button
LED Taillight
LED On and Solid -> Night Flash -> Day Flash -> LED Off : Press the (-) Button for 1 second.
Setting
Configuration Menu: Press the Center Button for 15 seconds.
Troubleshooting
Factory Reset
If you want to restore the headset to factory default settings, use the Factory Reset in the
configuration menu. The headset automatically restores the default settings and turns off.
Certification and Safety Approvals
FCC Compliance Statement
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment on and off, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antennae
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC RF Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance.
The antenna used for this transmitter must not transmit simultaneously with any
other antenna or transmitter, except in accordance with FCC multi-transmitter
product procedures.
When equipped, the distance between antenna and one’s head surface is 21.5 mm.
FCC Caution
Any changes or modifications to the equipment not expressly approved by the
party responsible for compliance could void user’s authority to operate the
equipment.
CE Declaration of Conformity
This product is CE marked according to the provisions of the R&TTE Directive
(1999/5/EC). Hereby, Sena declares that this product is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC. For
further information, please consult www.sena.com. Please note that this product
uses radio frequency bands not harmonized within EU. Within the
EU this product is intended to be used in Austria, Belgium, Denmark, Finland,
France, Germany, Greece, Ireland, Italy, Luxembourg, The Netherlands, Portugal,
Spain, Sweden, United Kingdom and within EFTA in Iceland, Norway and
Switzerland.
Industry Canada(IC) Statement
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Le present appareil est conforme aux CNR d’Industrie Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisee aux deux conditions
suivantes :
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioelectrique subi,
meme si le brouillage est susceptible d’en compromettre le fonctionnement.
IC RF Exposure Statement
Cet équipement est conforme aux limites d'exposition aux radiations de la FCC/IC
définies pour un environnement non contrôlé. Les utilisateurs finaux doivent suivre
les instructions d'utilisation spécifiques pour satisfaire à la conformité d'exposition
RF.
Lorsque équipé, la distance entre l’antenne et la surface de la tête est de 21.5 mm.
This device can be operated in at least one Member State without infringing applicable
requirements on the use of radio spectrum."
- RF Range: 2402 ~ 2 480 MHz (Bluetooth/LE)
- Max Power :
BT: Max. 16.51 dBm(eirp), LE: Max. 4.92 dBm(eirp)
BT: Max. 16.69 dBm, LE: Max. 3.62 dBm
Trade name: SENA
