Sena R1 Manuale utente
RIDE CONNECTED
Blast your favorite tunes, talk over the
intercom with your buddies, hear directions
from your GPS and more, all through your
Sena R1 Smart Cycling Helmet. With built-in
Bluetooth®capabilities, HD speakers and a
microphone using Advanced Noise Control™,
technology has never felt so minimal or
freeing.
Bluetooth®Integrated
Four-Way Intercom
Built-in Speakers and Mic
Advanced Noise Control™
900-Meter Intercom
GETTING STARTED
1. This product comes with a Quick Start
Guide, which is a basic version of the User’s
Guide. A FULL VERSION OF THE USER’S
GUIDE CAN BE DOWNLOADED AT
SENA.COM.
2. Update this product for free with the latest
firmware to fully enjoy the new advanced
features built into this product. Visit
sena.com to see how to update your
product.
3. Users can follow Sena on Facebook,
YouTube, Twitter and Instagram to
receive the most up to date information
on products, helpful tips and all other
announcements regarding Sena products.
GETTING STARTED
SENA Technologies, Inc.
Sena.com
Customer Support: sena.com/support
QUICK START GUIDE
How to Use This Guide
The legend and callouts are here to help you read the
illustrations. New technology can be confusing, but we’ve
created a simple way to perform actions using illustrations.
Function = Button(s) to Tap or Hold
=1s
HOLD
Buttons
(+) Button (-) Button
Center Button
QUICK START GUIDE
QUICK START GUIDE
Icon Legend
Tap button the
specified number
of times
Press and Hold button
for the specified amount
of time
Audible prompt
10 s
HOLD
1x
TAP
“Hello”
Helmet Structure
Left Side
Bluetooth System's Buttons
Speakers
Microphone
QUICK START GUIDE
Back Side
Fault
Reset Button
DC Power Charging &
Firmware
Upgrade Port
QUICK START GUIDE
Bluetooth System’s Buttons
Answer/End Phone Call
Reject an Incoming Phone Call
Start/End Intercom Conversation
Play/Pause Music
Enter Intercom Pairing Mode
Enter Voice Configuration Settings
Increase Volume
Track Forward
Scan Radio Stations
Speed Dial
Decrease Volume
Track Back
FM Radio On/Off
(+) Button (-) Button
Blue/Red/Green LED Lights
Center Button
QUICK START GUIDE
How To Fit the Helmet
1. Position the helmet on your head with the
front covering your forehead.
2. Position the strap adjuster centered, just
below your ears.
3. Position the helmet low on your forehead
with the buckle under the chin and back
against the throat. The straps should fit
comfortably around both ears.
Buckle
Strap Adjuster
QUICK START GUIDE
4. Adjust the chinstrap tension at the buckle
so the chinstrap is tight and comfortable
by pulling the chinstrap end through
the buckle to either tighten or loosen as
needed. Use the “O-Ring” to secure the
excess strap.
Chinstrap
O-Ring
Note: Check the chinstrap’s position and tension
regularly to ensure proper fit.
5. Turn the retention system knob clockwise
to tighten or counterclockwise to loosen.
Retention System Knob
QUICK START GUIDE
