Sennheiser MX W1 - 06-08 Manuale utente

MX W1

digital wireless system

Instruction manual

Contents

Important safety instructions ............................................. 2

MX W1 digital wireless earphone system ......................... 4

Delivery includes .................................................................... 4

Product overview ................................................................... 5

LED indications of the devices ...................................................6

Putting the MX W1 into operation ..................................... 6

Charging the MX W1 ...................................................................6

Associating the earphones to the transmitter (Pairing) .....9

Setting up your MX W1 for usage ......................................... 12

Using the MX W1 .................................................................14

Switching the earphones on/off ............................................ 14

Switching the transmitter on/off .......................................... 15

Putting on the earphones ....................................................... 16

Care and maintenance ........................................................17

Get the most out of your Sennheiser MX W1! ................19

Troubleshooting ...................................................................20

Accessories and spare parts ...............................................22

Specifications ........................................................................23

Manufacturer declarations .................................................24

Important safety instructions

The MX W1 has been manufactured according to the accepted rules

of safety and current technology. However, there is still a danger of

damage to equipment if the following general safety instructions

are not complied with.

• Please read these instructions for use carefully and completely

before using the devices.

• Make these instructions for use easily accessible to all users at all

times. Always include these instructions for use when passing

the devices on to third parties.

• Do not use the devices in situations which require special

attention (e.g. in traffic or when performing skilled jobs).

• Always keep the devices dry and do not expose them to extreme

temperatures (normal operating temperatures: 0 °C to 40 °C).

• Use the devices with care and store them in a clean, dust-free

environment.

• Switch off the devices after use to conserve battery power.

Remove the batteries if the earphones will not be used for

extended periods of time.

• Do not listen to high volume levels for long periods of time as

this can lead to permanent hearing defects. Set the volume of

the connected audio device to the minimum before switching

the earphones on. Then increase the volume to the lowest

comfortable volume.

• Use only the Sennheiser supplied MX W1 charging cable and

power supply unit. Never use the power supply unit for purposes

other than stated in this instruction manual.

Intended use of the devices

Appropriate use of the devices includes:

• having read and understood these instructions, especially the

section “Important safety instructions”,

• using the devices within the operating conditions and

limitations described in this instruction manual.

Safety instructions for Lithium-Ion rechargeable batteries

If abused or misused, rechargeable batteries may leak. In extreme

cases, they may even present a

Please understand that Sennheiser does not accept liability for

damage arising from abuse or misuse.

•heathazard

•firehazard

• explosion hazard

• smoke and gas hazard

Keep away from

children.

Do not heat above

70°C/158°F, e.g. do

not expose to

sunlight or throw into

a fire.

Do not expose to

moisture.

Do not short-circuit.

Do not mutilate or

dismantle.

Do not get fully

charged but

unpacked

rechargeable

batteries mixed up.

Do not continue to

use defective

rechargeable

batteries.

Only use rechargeable

batteries

recommended by

Sennheiser.

Observe correct polarity.

Switch rechargeable battery-

powered devices off after

use.

Remove rechargeable

batteries when the unit is not

used for extended periods of

time.

Only charge rechargeable

batteries with the

appropriate Sennheiser

chargers.

When not using rechargeable

batteries for extended

periods of time, charge them

regularly (about every three

months).

Only charge rechargeable

batteries at ambient

temperatures between 10°C

and 40°C.

Immediately remove

rechargeable batteries from

obviously defective devices.

Dispose of rechargeable

batteries at special collection

points or return them to your

specialist dealer.

MX W1 digital wireless earphone system

Thank you for purchasing MX W1 - Sennheiser's completely

digital wireless earphone system. We trust that you will enjoy

using it and that it will satisfy your expectations.

The MX W1 is simple to operate. These instructions for use have

been designed to help you get started. Please take some time to

read them carefully so as to ensure your utmost listening

pleasure.

Enjoy your new MX W1!

Delivery includes

1 MX W1-T transmitter

2 MX W1-R earphones (left/right) incl.

– earpads (1 pair, foam)

– twist-to-fit pads (3 pairs: size S/M/L)

1 MX W1-C docking station

1 carrying case

1 elastic fabric strap

4 rubber bands (2 x S/2 x L)

1 charging cable with USB plug

1 power supply unit

PSC03R-050

with 4 country adaptors (US/UK/EU/AU)

1 instructions for use

Product overview

Earphones

Transmitter

Twist-to-fit pad

Speaker

LED (orange/blue)

Operation/pairing button of

the earphone

2.5 mm charging jack

Battery compartment

Operation/pairing button of

the transmitter

Reset button

LED (orange/blue)

2.5 mm charging jack

Connecting cable with

3.5 mm stereo jack plug

Dowel pin











쐋













Docking station

LED indications of the devices

Putting the MX W1 into operation

Charging the MX W1

Charge the rechargeable batteries of all MX W1 devices for

3 hours before first use.

When the battery is almost flat, the LEDs and flash blue or

the LED flashes orange. You then have to charge the device.

Charging compartment for

earphones

Charging plugs for

earphones (inside the

charging compartment)

LED (orange/red)

Charging button

2.5 mm charging jack

LED Description

orange Charging of a device (see following chapter)

Docking station: Battery capacity < 5%

red Charging of the docking station (see following chapter)

blue

Associating the earphones to the transmitter (see page 9)

Switching the devices on/off (see page 14)

Transmitter/earphones: Battery capacity < 5%











1s0 2s

Charging the devices

To charge the devices (simultaneously or separately):

왘Connect the charging cable to the power supply unit .

왘Connect the suitable country adaptor to the power supply

unit .

왘Connect the charging cable to the charging jack of:

– the transmitter and the docking station 

– or the earphones .

왘If you want to charge all devices at one go, insert the

earphones into the charging compartments of the

docking station.

왘Press the charging button .

Danger of damage to the USB interface!

The USB interface of your computer can be

damaged if you connect the docking station

using the charging cable . This can lead to an

overload of the USB interface.

왘Only charge the docking station using the

power supply unit .

 









CAUTION!

왘Plug the country adaptor into a wall socket.

The batteries are being charged. The corresponding LEDs

light up.

왘Charge the rechargeable batteries until the LEDs go off

(approx. 2 hours).

Note:

– The rechargeable batteries of the transmitter and the

earphones can also be charged via a computer USB socket.

However, to charge the rechargeable battery of the

transmitter while listening to music, use the supplied

power supply unit for charging in order to avoid hum.

– The transmitter has its own built-in rechargeable battery.

So it will not drain your audio device’s battery.

– With a fully charged rechargeable battery, the operating

time of the transmitter is approx. 10 hours and of the

earphones approx. 3 hours.

Charging the earphones on the move

When on the move, the earphones can be charged up to three

times in the docking station, without the docking station having

to be connected to the mains.







쐋

왘Insert the earphones into the charging compartments of

the docking station. Make sure that the earphones are

inserted correctly.

왘Press the charging button to start charging.

The rechargeable batteries are being charged. The LEDs 

and light up.

왘Charge the rechargeable batteries until the LEDs go off.

Associating the earphones to the transmitter

(Pairing)

The MX W1 earphones and transmitter are already paired on

delivery. To enable wireless transmission, both the earphones

and the transmitter have to recognize each other:

1. Enrollment mode

After switch-on, a suitable device is searched.

2. Association mode

If a suitable device is detected, both devices will exchange

device identification information.

1s0 2s
