Sennheiser MKH 418-S

MKH 418S Shotgun Microphone

The MKH 418S is a compact MS stereo shotgun microphone utilizing Sennheiser's

exclusive RF condenser microphone technology. The MKH418S incorporates a mid

capsule based on that of the legendary MKH416 which is combined with a newly

designed figure-of-eight side capsule. Its high constant articulation, excellent feedback

rejection and functional versatility make the MKH418S a superb all-round cost-effec-

tive choice for film, television, and multi-media applications.

Delivery includes

Case

User manual

MKH 418S

Continued

Polar Pattern S

Polar Pattern M

Frequency Response

Technical Data

Acoustic operating principle M:pressure gradient/interference tube

S: pressure gradient

Pick-up pattern M: super cardioid/lobar

S: figure-of-eight

Sensitivity at 1K Hz M: 25 mV/Pa (-32 dBV)

S: 10 mV/Pa (-40 dBV)

Frequency response 40 - 20,000 Hz

Max. SPL 130 dB SPL (63 Pa)

Max. output voltage 1.5 V

Equivalent noise level M: 14 dB-A / 26 dB-CCIR

S: 22 dB-A / 34 dB-CCIR

Output impedance at 1 kHz < 25 ohms

Min. load impedance 1 kohms

Power supply P48: 48 ± 4 V / 2 x 2.3 mA

Connector 5-pin XLR, male

Dimensions Ø 19 mm x 280 mm

Weight 220 g

Operating temperature range -20 to +60 °C

Humidity range < 95 % relative humidity

Features and Benefits

·Matt black finished brass body is rugged and weather resistant

·Low inherent self noise insures an optimal signal to noise ratio

· Rugged MKH capsules are impervious to extreme climate conditions

· Independant capsule outputs allow variable matrixing capabilities and

multi-functional use.

Recommended Accessories

MZW415 windscreen

AC418 cable, 1m.

ACS5 Y cable adapter

MZQ 100 mic stand clip

MZS20-1 shockmount

MZW60-1 basket windshield

MZH60-1 hairy cover

True Systems P2A mic preamp

True Systems Precision 8 Mic Preamp

Sennheiser Electronic Corporation, 1 Enterprise Drive, Old Lyme, CT 06371

Telephone: 860-434-9190 Fax: 860-434-1759 Web: http://www.sennheiserusa.com

Sennheiser Mexico: Av. Xola 613, PH6, Col. Del Valle 03100, Mexico, DF. Telephone: (525) 639-0956. Fax: (525) 639-9482

Sennheiser Canada: 221 Labrosse Ave, Pte-Claire, PQ H9R 1A3. Telephone: 514-426-3013. Fax: 514-426-3953

Manufacturing Plant: Am Labor 1, 30900 Wedemark, Germany

Polar Pattern R

Polar Pattern L
