Sennheiser Set 830 S Manuale utente

Set 830 S

Cordless TV Listening System

Instruction manual

Contents

Safety instructions ................................................................. 2

Delivery includes ..................................................................... 4

Product overview .................................................................... 5

Putting the Set 830 S into operation ................................. 6

Setting up the transmitter ............................................... 6

Connecting the transmitter to a sound source ............ 7

Connecting the transmitter to the mains ................... 10

Connecting headphones or the induction loop

for hearing aids to the receiver ..................................... 11

Wearing the receiver ....................................................... 12

Using the Set 830 S system ............................................... 14

Switching the transmitter on/off ................................. 14

Switching the receiver on/off ........................................ 15

Adjusting the volume ...................................................... 16

Searching for a sound source ......................................... 16

Adjusting the balance ..................................................... 17

Switching between mono and stereo operation ........ 17

Individually enhancing the speech intelligibility ....... 18

Storing and charging the receiver ................................ 19

Charging a rechargeable battery in the

transmitter’s charging compartment .......................... 20

What if... ................................................................................. 21

...this indicator lights up? ............................................... 21

...you press this button? ................................................. 21

...you change the position of this control/switch? .... 22

...you hear acoustic signals or warning signals? ........ 22

Cleaning the Set 830 S ........................................................ 24

Cleaning the transmitter and the receiver .................. 24

If a problem occurs ... ........................................................... 24

Additional technical information ...................................... 27

Fine adjusting the speech intelligibility ........................ 27

Changing the operating mode ........................................ 28

Accessories and spare parts ............................................... 30

Specifications ........................................................................ 32

Manufacturer Declarations ................................................. 34

Index ........................................................................................ 36

Safety instructions

• Please read this instruction manual carefully and completely before

using the devices.

• Make this instruction manual easily accessible to all users at all

times. Always include this instruction manual when passing the

devices on to third parties.

• Do not use the devices in situations which require special attention

(e.g. when performing skilled jobs).

• Always keep the devices dry and do not expose them to extreme

temperatures.

• Use the devices with care and set them up in a clean, dust-free

environment.

• Varnish or furniture polish may degrade the feet of the transmitter,

which could stain your furniture. You should therefore place the

transmitter on a non-slip pad to avoid potential staining of

furniture.

• Connected headphones contain magnets that generate a magnetic

field which could cause dangerous interference with cardiac pace-

makers and implanted defibrillators. Keep connected headphones at

least 1.2” (3 cm) from cardiac pacemakers or implanted defibrilla-

tors.

• This receiver allows you to set higher volumes than conventional

headphones. This can cause hearing damage in persons with healthy

hearing and especially in children.

• Refer all servicing to qualified service personnel. Servicing is

required if the devices have been damaged in any way, liquid has

been spilled, objects have fallen inside, the devices have been

exposed to rain or moisture, do not operate properly or have been

dropped.

• WARNING: To reduce the risk of fire or electric shock, do not expose

the device and the mains unit to rain or moisture.

• Use only the supplied mains unit.

• Disconnect the mains connector from the wall socket

– to completely disconnect the device from the mains,

– during lightning storms or when unused for long periods of time.

• Ensure that the mains unit is

– always readily operable and easily accessible,

– properly plugged into the wall socket,

– not covered or exposed to direct sunlight for longer periods of

time in order to prevent heat accumulation,

– only operated within the permissible temperature range (see

“Specifications” on page 32),

– not operated near heat sources.

Safety instructions

Intended use

Intended use includes:

• having read this instruction manual, especially the chapter “Safety

instructions”,

• using the devices within the operating conditions and limitations

described in this instruction manual.

“Improper use” means using the devices other than as described in this

instructions, or under operating conditions which differ from those

described herein.

Safety instructions for the Lithium-Polymer rechargeable battery

The BA 300 is a Lithium-Polymer rechargeable battery. If abused or

misused, this rechargeable battery may be damaged. Please under-

stand that Sennheiser does not accept liability for damage arising from

abuse or misuse.

WARNING! In extreme cases, the rechargeable battery may even

present a

•heathazard

•firehazard

• explosion hazard

•smokeandgashazard

Do not heat above

70°C/158°F, e.g. do

not expose to sunlight

or throw into a fire.

Only charge rechargeable

batteries with the appro-

priate Sennheiser chargers.

Do not expose to

moisture.

When not using the

rechargeable battery for

extended periods of time,

charge it regularly (every

six months for about one

hour).

Do not short-circuit. Only charge rechargeable

batteries at ambient

temperatures between

10°C/50°F and

40°C/104°F.

Do not mutilate or

dismantle.

Do not charge the

rechargeable battery if the

device is obviously defec-

tive.

!Store the devices/

rechargeable batteries

in a cool and dry place

at room temperature.

Return defective devices or

exhausted rechargeable

batteries to your specialist

dealer.

Delivery includes

Delivery of the Set 830 S system includes:

1 RI 830 S receiver

with BA 300 Lithium-Polymer rechargeable battery

1 TI 830 transmitter with integrated charging

compart-ments

1 EZT 3011 induction loop

1 NT 13 mains unit with

3 country adapters (EU, UK, US)

1 connection cable

with two 3.5 mm stereo jack plugs

for connection to a headphone socket

3 audio adapters:

1 adapter 3.5 mm to ¼“ (6.3 mm) jack plug

1 adapter for RCA socket

1 adapter for SCART socket

1lanyard

1 clip for attaching the receiver

1 instruction manual

Product overview

The overview pictures of the receiver and the transmitter

can be found on the inside front cover of this instruction

manual.

Receiver

1Channel indicator

2Volume control

3On/off button

4Balance control

5Channel search button

6Battery compartment

7Socket for headphones,

induction loop or

connection cable to

hearing aid

Transmitter

8Charging compartment for receiver

9Charging compartment for optional spare rechargeable

battery

0Charging indicator for optional spare rechargeable

battery

ACharging indicator for receiver’s rechargeable

battery

BOperation indicator

C“Speech intelligibility” button

DIndicator for the selected speech intelligibility

ESocket (marked blue) for connection of sound source or

external microphone

FMono/stereo slide switch

GTreble adjustment control

HDC socket (marked yellow) for connection of mains unit

Putting the Set 830 S into operation

Setting up the transmitter

왘Place the transmitter so that:

– there are no obstacles in the light path between trans-

mitter and receiver and

– transmitter and receiver are not exposed to direct

sunlight. Direct sunlight may interfere with the recep-

tion and may damage the transmitter.

If you are using a plasma TV screen:

Plasma TV screens radiate an infra-red signal that can

adversely affect the transmission quality.

왘Make sure that the transmitter is placed as far as

possible from your plasma TV screen.

왘If necessary, use a standard extension cable (3.5 mm

stereo jack plug) to reduce the distance between trans-

mitter and receiver. This extension cable is available from

your Sennheiser dealer.

Note:

One transmitter can be used to transmit to several

receivers on the same frequency.
