Wireless Systems Manager
You‘re
in Control
WSM
BRS_WSM_D+GB.indd 1BRS_WSM_D+GB.indd 1 08.09.2009 9:15:00 Uhr08.09.2009 9:15:00 Uhr
The new dimension of real-time monitoring: the Wireless Systems Manager (WSM) is your software solution for monitoring and
remotely controlling wireless Sennheiser microphone and monitoring systems. Using this software, you can constantly monitor
connected devices and easily configure them at any time. The WSM ensures maximum reliability and control with wireless audio
transmissions and also saves valuable time when setting up your system.
The Wireless Systems Manager is the first choice in live performances, TV studios, theaters and musical productions. The extensive
range of functions ensures that your production runs smoothly.
The software integrates wireless microphones and monitoring systems as well as professional and semi-professional series of
different generations (3000, 2000, evolution wireless gand g) into a single platform.
Download the Wireless Systems Manager free of charge at www.sennheiser.com. Thanks to regular updates, you are always on the
cutting-edge.
Absolute control
over your wireless
audio transmission.
Anytime. Anywhere.
BRS_WSM_D+GB.indd 2BRS_WSM_D+GB.indd 2 08.09.2009 9:15:05 Uhr08.09.2009 9:15:05 Uhr
Live on stage Concerts and shows become unforgettable
experiences. For this to happen, you need a system that you can depend
on 100 % of the time. The WSM makes configuration more reliable and
easier than ever before, particularly in constantly changing venues when
on tour.
Broadcast/TV studio Whether recorded or broadcast
live: perfect sound and reliability are the fundamental requirements for a
successful television broadcast. Using the Wireless Systems Manager, you
can monitor all connected devices and keep a cool head especially during
hectic production schedules. The strengths of the software become espe-
cially apparent on complex studio networks. With special administrative
rights, you can also manage the workflow in a large team and ensure that
the show runs smoothly and successfully.
Theater During spectacular stage productions and musicals with
m
any performers and channels, control during every scene is fundamental
to a successful show. Using the Wireless Systems Manager, you can
maintain an overview and ensure interference-free and reliable audio
transmission.
Office The preparation of major events require absolute concentra-
tion. Using the Wireless Systems Manager, you can make the adjustments
for your event in peace and quiet from the office thanks to the off-line
mode.
BRS_WSM_D+GB.indd 3BRS_WSM_D+GB.indd 3 08.09.2009 9:15:37 Uhr08.09.2009 9:15:37 Uhr
Wide range
of functions
fast and clear
Off-line configuration: Time saving and comfort Using
the WSM, you can prepare all of your settings in off-line mode without
having the necessary hardware connected. You can configure your
system on the computer practically anywhere – even in the office or
the tour bus – as you need it for the production later on.
At the production venue, the WSM loads the configuration, defined
off-line, into the connected devices. This saves valuable time and you
can focus on what matters most: perfect sound for your event.
Multi-Access: control and reliability on the network
The WSM turns you into a team manager: you can provide essential
information to colleagues located elsewhere and check device settings
online without having to leave the room.
You can determine which users have the right to change settings in
the system, with up to six PCs or Macs used at the same time on the
network.
“Scenes”: Able to handle any event Depending on how
many channels you operate, the WSM can be flexibly adapted to your
area of application. You can specify which panels you would like
displayed at a certain point in time in what order and at what size.
These scenes give you a realtime overview over your system.
BRS_WSM_D+GB.indd 4BRS_WSM_D+GB.indd 4 08.09.2009 9:15:55 Uhr08.09.2009 9:15:55 Uhr
Panels All important information at a glance, even during hectic
productions: the panels of the WSM display all the necessary parameters
of the system in real-time, such as the RF level, audio level, name,
frequency, status of the battery and more.
The intelligent warning system informs you of possible irregularities
quickly and reliably, such as if a battery has a low charge. You can
customize the size and display format of the panels (e.g. night mode)
for the individual production.
RF level recorder Using this flexible tool, you can ensure that your
wireless microphone system is transmitting the individual signals per-
fectly to every point of the stage or studio. At each antenna, the RF level
recorder determines the signal strength of a wireless transmitter, based
on its position in the room and precisely locates points of poor reception.
This results in interference-free sound and reliable transmission.
RF spectrum analyzer More up-to-date and more dependable than
any list, the WSM displays the frequencies available for your transmission
within a matter of seconds. At a glance, you can see the size of the avail-
able slots in the frequency spectrum and monitor the field strength of all
radio signals present.
One-of-a-kind
Tools
flexible and reliable
BRS_WSM_D+GB.indd 5BRS_WSM_D+GB.indd 5 08.09.2009 9:16:30 Uhr08.09.2009 9:16:30 Uhr
System
example
There are many differ-
ent sides to working
with the Wireless
Systems Manager,
depending on the size
of your system. The
full capacity of this
intelligent software un-
folds when used with
complex multi-channel
systems.
WSM online Discover the Wireless Systems Manager online. Go to
“www.sennheiser.com/WSM” for further information and a compre-
hensive range of application examples.
You can also download the newest version of the WSM directly from
this website for free.
Studio 3Studio 3
Studio 2
Studio 1
Control Room B
Control Room A
Equipment Room
TV studio
BRS_WSM_D+GB.indd 6BRS_WSM_D+GB.indd 6 08.09.2009 9:16:59 Uhr08.09.2009 9:16:59 Uhr
Type Size Switching
bandwidth
IR-sync
between
transmitter
and receiver
Network
connection Audio output
EM 3731 / EM 3732 /
EM 3732-COM single / dual receiver 19'' 90 MHz yes Ethernet XLR and AES-EBU
EM 2000 / EM 2050 single / dual receiver 19'' up to 75 MHz yes Ethernet XLR and 6,3 mm-Klinke
EM 500 gsingle receiver ½ 19'' 42 MHz yes Ethernet XLR and 6,3 mm-Klinke
EM 300 gsingle receiver ½ 19'' 42 MHz yes Ethernet XLR and 6,3 mm-Klinke
SR 2000 / SR 2050 single / dual
transmitter 19'' up to 75 MHz yes Ethernet XLR and 6,3 mm-Klinke
SR 300 IEM gsingle transmitter ½ 19'' 42 MHz yes Ethernet XLR and 6,3 mm-Klinke
Net 1 Interface device 19'' -/- yes Ethernet -/-
EM 3532 dual receiver 19'' 36 MHz via Net 1 via Net 1 XLR
EM 550 gdual receiver 19'' 36 MHz via Net 1 via Net 1 XLR
EM 500 gsingle receiver ½ 19'' 36 MHz via Net 1 via Net 1 XLR and 6,3 mm-Klinke
EM 300 gsingle receiver ½ 19'' 36 MHz via Net 1 via Net 1 XLR and 6,3 mm-Klinke
SR 350 gdual transmitter 19'' 36 MHz via Net 1 via Net 1 XLR
SR 300 IEM gsingle transmitter ½ 19'' 36 MHz via Net 1 via Net 1 XLR
System
components
Hardware
BRS_WSM_D+GB.indd 7BRS_WSM_D+GB.indd 7 08.09.2009 9:17:31 Uhr08.09.2009 9:17:31 Uhr
Sennheiser electronic GmbH & Co. KG
Am Labor 1, 30900 Wedemark, Germany
www.sennheiser.com/WSM
Printed in Germany 538312 09/09 Sennheiser is a registered trademark of Sennheiser electronic GmbH & Co. KG. www.sennheiser.com
