Sennheiser SZI 1015-T Manuale utente

Features—Benefits

• 2-Watt infra-red emitter with integrated modulator for the carrier

frequency 2.3 MHz

• RF output (BNC socket and barrier strip) for connecting additional emitters

• Automatic on/off function

• 5/8"and 3/8" threads for mounting

• Avoid interference from fluorescent lighting

• Easy installation

• Controlled from a single location

• Versatile installations

• Available in black or white

Technical Data

Carrier frequency range 2.3 MHz

Number of diodes 72

Maximum coverage area 4,000 sq. ft. (mono)

Average radiating power 2 watts

Audio input connector XLR balanced line-level

Modified (mic-level) upon request

Carrier frequency range 30 Hz–18 kHz

Current consumption 0.8 A

Power requirements 25–30 V DC

Dimensions in inches 10 x 3.25 x 5

Weight (approx.) 3 lbs.

Product Variants

SZI 1015T with NT 1015-120 power supply SZI 1015T/NT

SZI 1015T in white (no power supply) SZI 1015T-W

SZI 1015T in white with

NT 1015-120 power supply SZI 1015T-W/NT

SZI 1015-T IR Hi-Band Modulator/Emitter

SZI 1015-T

The SZI 1015-T is a medium single-channel area modulator/emitter combination

unit utilizing the high sub-carrier frequency of 2.3 MHz. It is ideal for rooms where

fluorescent lighting is present. This system incorporates a built-in emitter and can

cover up to 4,000 sq. ft. It can be daisy-chained with SZI 1015 slave emitters for

additional coverage. External power supply (NT 1015-120) must be ordered

separately or use equivalent DC power supply, minimum 25V at .8 Amp per emitter.

SZI 1015-T

CBinder - Information Systems.indd 37 11/11/08 11:50:08 AM

Product Compatibility

SZI 1015

SZI 1029

SZI 1029-24

SZI 1029-10

Optional Accessories

0003SMESdnatsroolF

021-5101TNylppusrewoP

Charging unit and power supply for 10 batteries L 151-10/NT

Recommended Receivers

Single channel, stethophone receiver with BA

151 rechargeable battery RI 250

Same as RI 250 but with 1/8" jack

for connecting with hearing aid accessories RI 250-J

Single-channel, body pack receiver with

1/8" mono jack for connecting with hearing

S-052IRseirosseccadia

Recommended Accessories

Swivel joint and mounting plate GZG 1029 & GZP 10

9201GZGtniojleviwS

9101SZMrabgnitnuoM

Anti-vibration table stand MZT 100

Wall/ceiling mount (formerly AX 5-IR)WM 1

RI-W5XAetihwnigniliec/llaW

021-5101TNylppusrewoP

WM1

GZP10

GZG 1029 MZT 100

AX5W-IR

SZI 1015-T

CBinder - Information Systems.indd 38 11/11/08 11:50:09 AM
