SENSORO SILVER BULLET RX7600 Manuale utente
SILVER BULLET RX7600
Ultra compact wireless
radar/laser detector
with compass
QUICK GUIDE
1. Choose where to install the Silver Bullet radar detector
• Windshield installation to use with batteries (wirelessly) or with power cord.
• Dashboard and Visor installations work exclusively with the power cord.
2. Install radar detector
QUICK GUIDE
1. Install 2 AA alkaline batteries in the bracket
battery box.
2. Bend the bracket bars as needed to ensure
the radar detector will be easily visible and
level with the road.
3. Press securely against the windshield.
4. Attach the radar detector to the bracket
– you will hear a “click” when properly
connected.
Windshield – with Power Cord (use Bracket B) 1. Bend the bracket bars as needed to ensure
the radar detector will be easily visible and
level with the road.
2. Press securely against the windshield.
3. Attach the radar detector to the bracket
– you will hear a “click” when properly
connected.
4. Plug the power cord into the radar detector
and power socket of your vehicle.
Windshield – with Battery (use Bracket A)
BRACKET A
SUCTION CUP
PULL TAB
BRACKET B
SUCTION CUP
PULL TAB
1
HOOK & LOOP
FASTENER
Dashboard – with Power Cord
(use Hook & Loop Fastener)
VISOR BRACKET
QUICK GUIDE
1. Mount the radar detector directly onto the
dashboard using the hook & loop fastener
(with sticky sides attached to the dashboard
and bottom of radar detector).
2. Plug the power cord into the radar detector
and power socket of your vehicle.
Visor – with Power Cord (use Visor Bracket) 1. Clip visor bracket to the back, pivoting edge
of your visor.
2. Turn the radar detector upside-down and
attach to the visor clip – you will hear a
“click” when properly connected.
3. Attach the power cord to the radar detector.
4. Turn on the unit.
5. Press and hold the MUTE and ALERT FILTER
buttons simultaneously for 3 seconds to
reverse the text display (so messages will
be seen right-side-up).
6. Use the retaining clips to neatly tuck away
the power cord.
When you use bracket A or bracket B, make sure the suction cups pull-tabs are not
positioned underneath the bracket, so they can be easily accessed for removal.
2
QUICK GUIDE
3. Turn on the radar detector
1. Move the POWER switch to ON.
2. The screen will display ”SENSORO RADAR DETECTOR * * * FILTER-NORMAL” indicating a
normal lter mode.
3. The screen will then display a random compass direction if the compass has not been
set-up since purchase.
If you selected an alternate alert lter mode during previous use, it will
display either “FILTER-HIGH” or “FILTER-OFF” instead of “FILTER-NORMAL” per
your selection.
4. Setting up the compass
1. To set the compass readings you will need to drive your vehicle slowly in a full circle.
Be sure you are in an area where you can safely perform this maneuver.
2. Install the radar detector in your vehicle at your preferred location - windshield,
dashboard, or visor.
3. Press and hold the BACKLIGHT and MUTE buttons simultaneously for 3 seconds.
4. The screen will display “DRIVE IN A FULL CIRCLE... PRESS ANY BUTTON WHEN DONE.”
5. Drive your vehicle in a full circle. The direction and size of circle do not matter. You
have one minute to complete the maneuver.
6. Press any button to complete the compass set-up.
3
QUICK GUIDE
5. Receiving alert messages
• When a radar signal is detected, the screen displays the name of the band – “X”, “K”,
or “KA” – and a number indicating the strength of the signal (1 to 8).
• The higher the number, the stronger the signal.
• Stronger signals usually imply that you’re closer to a police radar/laser device.
• When a laser signal is detected, the screen displays “LASER”.
6. Adjusting the Alert Filter
If you receive too many false alert signals, or are driving in specic environments, press the
ALERT FILTER button to switch between lter modes:
• FILTER-NORMAL – Optimized ltering for typical city or highway driving
• FILTER-HIGH – Increased ltering to reduce most false alerts, good for high-density
commercial areas
• FILTER-OFF – No ltering of alert signals, ideal for open space areas
4
12180 R01 1003074 R01
For more information on how to get the most from
your radar detector, see the Operation Manual.
PNI Corporation
5464 Skylane Boulevard, Suite A • Santa Rosa, CA 95403 - USA
1-888-422-6672 • fax: 1-707-566-2261
www.pnicorp.com
