Sentidrive SENTINELLE Manuale utente
Quick Start Guide
by
FR
UK
IT
DE
ES
2
Welcome
to the Sentidrive community!
Register your Sentinelle
Essential recording before the device is lit. Without active registration, the service is not available.
1
2
4
3
To enable the Sentidrive service :
In order to benet from the Sentidrive service, it is necessary to subscribe to a subscription, more information about
www.sentidrive.com
Note the S/N number on the back of the Quick Start Guide and the KEY ID.
Visit our website: www.sentidrive.com or on the Sentidrive App, and create a user account
or log in if you already have one.
Enter your S/N number and KEY ID in the «Register a device» section
Finally, choose the subscription formula that suits your needs.
www.sentidrive.com
UK
Box contents
Main unit Front camera Rear camera
Microphone Power box Antenna
User guideAccessoires
3
Mounting support
Description of the Sentinelle
Unconnected power
Sleep mode (every 30 seconds)
Normal operation
Sleep mode
GPS signal search (blinking)
Connected GPS
Sleep mode
4G network search (blinking)
Connected 4G
4G GPS Power
Micro USB 2.0Number S/N
Number IMEI
Statusof the Sentinelle :
4www.sentidrive.com
* Before any adjustment manipulation, remove the faste-
ning screw using the key provided.
Fixing screws *
Rotating setting
Maxi 90°
(180° available through the app)
Height setting
The live streaming feature is available through the
app to make it easier to adjust cameras.
UK
5
Installation on the vehicle
Make sure that the positioning of the elements does not interfere with the proper operation of the two-wheeler.
Make sure that the positioning of the different cables does not pass over protruding parts of the two-wheeler and that
the cables are secured by clamping collar.
We recommend that you install this material by a professional.
6www.sentidrive.com
The Main unit can be installed under the saddle or in the trunk of the two-wheeler
and must be securely secured. Fixing can be done using three methods (see next
page).
The front camera can be installed:
- on the handlebars
- on the top of the front fairing
- on the bottom of the front fairing between the latter and the fender
Watch out for fork travel!
The rear camera can be installed:
- on the mud guard
- on the holder of the license plate
- under the wheel passage
The antenna must be deported to the exterior fairing of the vehicle. Make sure to
put the inscription «This side faces the sky» facing the sky.
The microphone should be placed in the wind-free position, ideally within the
cockpit
The power box must be placed towards the vehicle’s battery to make the connec-
tion between the battery and the central unit. Its connection is explained in the
paragraph «power supply.»
UK
7
8www.sentidrive.com
Installation by double-
sided duct tape*.
Microphone sheltered from
the wind.
Installation by double-
sided duct tape.*.
The inscription «This side
faces the sky» in front of
the obligatory sky.
Use only the double-sided adhesive
tape provided in the package!
* Recommendation of the installation of
double-sided duct tape:
- Prepare the surface with a grease
remover and make sure there is no dust
and other dirt that could interfere with
the grip.
- Place the tape on the sticky item (e.g.
cameras)
- Glue the element on the two-wheeler
with moderate pressure for 10 seconds.
Applying on a surface of less than
10°C is not recommended.
Installation by double-
sided duct tape*.
Installation by double-
sided duct tape*. Lens
facing the area to be
saved.
Lens
recording
Installation by double-
sided duct tape*.
Mechanical installa-
tion. Used only the
supports and screws
provided in the
package.
Installation by mounting
collar**. Ensure compati-
bility with the operating
temperatures produced.
** Unsuperated mounting
collar
Electrical connection
The realization of the electrical connection by a professional is advised.
Solution 2 : Auto start-up detection
Solution 1 : Use 12 V after contact
- Connect the black cable (negative) to the battery negative
(-)
- Connect the red cable (positive) to the battery positive
The equipment will automatically start when the two-wheeler starts
(detection of voltage increase).
If this solution is used, check that the equipment automatically shuts
down after a few seconds at the stop of the two-wheeler. (If not, this
solution may drain your battery)
- Connect the black cable (negative) to the battery
negative (-)
- Connect the red cable (positive) to the battery
positive
- Connect the Yellow Cable on a 12 Volt after contact
(example: by-caring)
This solution is to be preferred.
The watch for your Sentinel needs a permanent power supply (tracker function).
In order to avoid untimely disconnections, we recommend a welding installation if possible.
UK
9
Fuse 2A Power box
How the Sentinelle works
Before the rst start, the registration of your Sentinel must be made. To do this, follow
the procedure described on page 12.
1
2
4
3
Download the Sentidrive app for iOS (Apple store) or Android (Google Play):
Launch the app and log in using your user account (account used when registering your Senti-
nelle on the site: www.sentidrive.com)
Connect your Sentinelle to your smartphone via Wi-Fi via the settings:
Wi-Fi Name = IMEI // Password by default = 8 digits of the IMEI number
Let yourself be guided in taking control of your Sentinelle.
10 www.sentidrive.com
Apple, the Apple logo are trademarks of Apple inc., registered in the US and other countires. Android and Google
Play are registered trademarks of Google
