Thank you for choosing SETMSPACE products!
Please read this user manual carefully before using. Also
available from www.setMspace.com download the
detailed e-brochure and keep it for later use.
Package Contents
Product Specifications
1× USB3.0 HUB
1× User Manual
EN
Output
Input
USB-A 3.0×4
USB-A USB-C
Transmission
Rate 5Gbps
Material Aluminum Alloy + ABS
Continuous
cable length 0.15m / 0.5m / 1m / 1.8m
Dimensions 93×30.6×18mm
Name
Model RW4U-U3 RW4U-C3
4-Port USB3.0 HUB
- 3 -
Output
Input
USB-A 3.0×2, USB-C 3.0×1
USB-A USB-C
Transmission
Rate 5Gbps
Material Aluminum Alloy + ABS
Continuous
cable length 0.15m / 0.5m / 1m / 1.8m
Dimensions 93×30.6×18mm
Name
Model RWC2U-U3 RWC2U-C3
3-Port USB3.0 HUB
Output
Input
USB-A 3.0×3, RJ45×1
USB-A USB-C
Transmission
Rate 5Gbps
Material Aluminum Alloy + ABS
Continuous
cable length 0.15m / 0.5m / 1m / 1.8m
Dimensions 93×30.6×18mm
Name
Model RW3UR-U3 RW3UR-C3
4-Port USB3.0 HUB
with gigabit ethernet port
- 4 -
Output
Input
USB-A 3.0×1, USB-C 3.0×1, RJ45×1
USB-A USB-C
Transmission
Rate 5Gbps
Material Aluminum Alloy + ABS
Continuous
cable length 0.15m / 0.5m / 1m / 1.8m
Dimensions 93×30.6×18mm
Name
Model RWCUR-U3 RWCUR-C3
3-Port USB3.0 HUB
with gigabit ethernet port
Output
Input
USB-A 3.0×3, RJ45 2.5G×1
USB-A USB-C
Transmission
Rate 5Gbps
Material Aluminum Alloy + ABS
Continuous
cable length 0.15m / 0.5m / 1m / 1.8m
Dimensions 93×30.6×18mm
Name
Model RW3UR25-U3 RW3UR25-C3
4-Port USB3.0 HUB
with 2.5-Gig ethernet port
- 5 -
Output
Input
USB-A 3.0×1, USB-C 3.0×1, RJ45 2.5G×1
USB-A USB-C
Transmission
Rate 5Gbps
Material Aluminum Alloy + ABS
Continuous
cable length 0.15m / 0.5m / 1m / 1.8m
Dimensions 93×30.6×18mm
Name
Model RWCUR25-U3 RWCUR25-C3
3-Port USB3.0 HUB
with 2.5-Gig ethernet port
Product Illustration
RW4U-U3
USB-A 3.0USB-A
RW4U-C3
USB-A 3.0USB-C
- 6 -
RWC2U-U3
USB-A 3.0USB-C 3.0USB-A
USB-A 3.0
USB-C 3.0
RWC2U-C3
USB-C
RW3UR-U3
USB-A 3.0 RJ45USB-A
USB-A 3.0 RJ45
RW3UR-C3
USB-C
- 7 -
USB-A 3.0USB-C 3.0 RJ45
RWCUR-C3
USB-C
RWCUR-U3
USB-A 3.0 RJ45USB-C 3.0USB-A
RW3UR25-U3
USB-A 3.0 RJ45 2.5GUSB-A
USB-A 3.0 RJ45 2.5G
RW3UR25-C3
USB-C
- 8 -
Note: Please follow the instruction of user manual and do
not force remove devices while application. Force remove
may cause error or damage to the files or devices.
1. Remove under microsoft windows:
Stop the using the devices and click "Safely Remove
Hardware and Eject Media" icon on taskbar, select "Eject
the USB device" to remove the devices safely when the
system suggests "Safe To Remove hardware".
2. Remove from Mac OS:
Stop the reading/writing to the devices and drag it in to
trash.
Vorsichtsmaßnahmen
RJ45 2.5GUSB-A 3.0USB-C 3.0
RWCUR25-C3
USB-C
RJ45 2.5G
RWCUR25-U3
USB-A 3.0USB-C 3.0USB-A
- 9 -
1. This product is compatible with mobile HDD, USB flash
disk, cell phone, tablet, card reader, MP3/4 player,
mouse, keyboard, camera, printer, scanner and any
other USB devices.
2. This product is compatible with Windows, Mac OS and
Linux laptop or desktop computer, plug and play, no
additional driver needed.
3. Some wireless network adapter, receiver and bluetooth
adapter can work with usb3.0 or USB2.0 host of
motherboard only and may be not compatible with the
product. Please contact SETMSPACE customer service
team for support if you have any issues about
compatibility.
4. If compatibility issues occur while using under MAC OS,
please try to update your MAC OS to the latest.
Compatibility
1. Please do not hit, throw, or puncture the product, and
avoid dropping, squeezing, or bending.
2. Please do not use or store this product in a humid
environment and avoid being wetted or rinsed with
liquids.
3. Please do not use the product in a hot, high-dust environ-
ment and keep it away from fire.
4. Please do not expose this product to the sun.
5. Please do not place this product in corrosive environ-
ment and do not use other chemical solutions to clean
the product.
6. Avoid placing the product or accessories in devices with
strong electromagnetic fields and keep the product away
from magnetic equipment.
7. Keep the product and accessories away from children.
Do not allow children to use the product without super-
vision.
8. Do not disassemble or repair the product and accesso-
ries by yourself. Please contact authorized support
center for help.
9. If the product needs to be equipped with power adapter,
please use the power adapter specified by our company.
10. If you have any questions during the use of this product,
please feel free to contact your dealer or SETMSPACE
Customer Service Center.
