Shark S3973D Manuale utente

A S S E M B LY

(Click)

Filling the Water Tank

Turn the water tank cap counterclockwise to

remove. Use the ﬁlling ﬂask to pour water into

the tank. Do not overﬁll. Replace the cap on

the water tank. We recommend

using distilled water to

prolong the life of

your Shark Pro

Steam Mop.

TO REMOVE the Intelli-Mop™

Head, press the release button

on front of the unit.

NOTE: Sweep or

vacuum your ﬂoors

prior to cleaning with

your Steam Mop.

For questions or to register your product, contact us at:

1-800-798-7398 or visit us online at sharkclean.com

@sharkcleaning

S3973D_160614

Please be sure to read the enclosed Owner’s Guide prior to using your unit.

QUICK

START

GUIDE

PRO STEAM MOP

With Lift-Away®

Use this Quick Start Guide

to learn about your

new Pro Steam Mop’s

great features.

WHAT’S INSIDE:

For additional parts and accessories, visit sharkclean.com

of SharkNinja Operating LLC. Intelli-Mop, Dirt Grip, and Steam Blaster are trademarks of SharkNinja Operating LLC.

A Steam Mop Handle

B Steam Mop Body

C Steam Mop Lift-Away®

D Intelli-Mop™ Head

E Dirt Grip™ Pad (x1)

F Filling Flask

G Concentrator Nozzle

H Garment Steamer

I Triangle Head with Steam Blaster™

J Triangle Pad with Scrubber

I J

CLEANING

USING YOUR PRO STEAM MOP

With the Intelli-Mop™ Head, you can quickly and easily attach and release the Dirt Grip™

Pads without touching them. No more wrestling with dirty, wet pads. The Dirt Grip Pads

are double-sided, washable and reusable. For pad attachment and removal instructions

see the following page.

Your Pro Steam Mop is ideal for deep cleaning and cutting through dirt

and grime in high-trafﬁc areas, as well as for sanitizing* ﬂoors.

*Sanitization studies were conducted under controlled test conditions.

Household conditions and results may vary. With the Intelli-mop head only

in SCRUB mode. Not in above ﬂoor mode or when using Steam Blaster. See

Owner’s Guide for instructions.

Plug the power cord into an outlet.

The STEAM CONTROL button will ﬂash blue.

Press the STEAM CONTROL button to

select your steam setting: Once for DUST,

twice for MOP, and three times for SCRUB.

Pressing a fourth time will place the unit in

STANDBY MODE.

SETTING

IDEAL FOR

THESE SEALED

SURFACES

RECOMMENDED

USAGE

DUST Laminate

Hardwood

Marble

Light cleaning and dusting

Loosening and lifting light dirt

Cleaning delicate surfaces

MOP Hardwood

Marble

Tile

Stone

Cleaning most surfaces and large areas

Basic, everyday cleaning

Removing spots and smaller messes

Cleaning moderate and heavy-trafﬁc areas

SCRUB Hardwood

Marble

Tile

Stone

Deep cleaning and cleaning hard-to-clean surfaces

Tough cleaning and removing stuck-on messes and stains

Deep cleaning heavy-trafﬁc areas

Cutting through heavy dirt and grime

Sanitizing* ﬂoors

ABOVE-FLOOR CLEANING

Slide nozzle onto the Handheld Steamer.

DIRECT STEAM NOZZLE

For spot cleaning and direct steaming

CUSTOM CLEANING ACCESSORIES HOW TO ATTACH

Remove the Handheld Steamer by pressing the release button and pulling it away from

the cradle.

Note: In Handheld Mode, the STEAM CONTROL is preset to SCRUB to optimize above-ﬂoor

cleaning and garment steaming.

Snap the desired accessory into the main nozzle of the Handheld Steamer. Then squeeze the

steam trigger to activate steam.

Using 3-to-5-second bursts of the trigger will allow you to steam longer and with more control.

Once done with handheld steaming, press the STEAM CONTROL button until the light ﬂashes

blue to put the unit in STANDBY MODE. Let cool for 2 to 3 minutes before removing mop

head, pads, or handheld accessories and storing.

Slide the Garment or Upholstery Bonnet onto

the Garment Steamer. Elastic will hold the

bonnet in place.

Snap the bristle over the Garment Steamer

and bonnet then click the Garment Steamer

onto the Handheld Steamer.

GARMENT STEAMER

Freshen clothing, fabrics and

upholstery

CAUTION: Make sure the Steam Mop is unplugged or in Standby Mode while attaching or

removing the accessories. Avoid touching the accessories, as they will be very hot after steaming.

It is recommended that you allow the pads to cool off before removing them from the accessories

to avoid possible scalding injury.

INTELLI-MOP™ HEAD TECHNOLOGY

TOUCH-FREE PAD ATTACHMENT

3 4

1. Lift the mop straight up by the handle

until the Intelli-Mop Head is hanging

straight down. Center the mop head

above the pad. Press down the release

buttons on the sides of the head post, and

both sides of the mop head will drop open.

2. Slip the Intelli-Mop Head’s 4 corner

tabs into the 4 corner pockets of the

Dirt Grip™ Pad.

3. Gently press the Intelli-Mop Head to the

ﬂoor on one side of the pad, and that side

will click into place.

4. Flip the other side of the Intelli-Mop Head

over onto the ﬂoor to click into place.

1. Lift the mop straight up by the handle

until the Intelli-Mop Head is hanging

straight down. Press down the release

buttons on the sides of the head post, and

both sides of the mop head will drop open.

TOUCH-FREE PAD REMOVAL

DIRT GRIP™ PADS

DOUBLE-SIDED, WASHABLE, REUSABLE

Our washable Dirt Grip Pads are made with ﬁbers specially designed to absorb and trap dirt.

This gives your ﬂoors an amazing clean, with minimal streaking and short dry times.

For best cleaning results, we recommend replacing your

Dirt Grip Pads following 20 normal uses.

PAD CARE

Machine wash the Dirt Grip Pads separately with warm

water using liquid detergent.

NEVER USE BLEACH, POWDERED DETERGENT,

OR FABRIC SOFTENERS as they may damage

the Dirt Grip Pads.

You can purchase replacement Dirt Grip Pads

and other accessories by visiting sharkclean.com

or calling 1-800-798-7398.

STEAM BLASTER™ TECHNOLOGY

When you need an extra burst of steam to

clean tough, dried messes and stuck-on stains,

use the Steam Blaster.

1. Flip back the Intelli-Mop™ Head so that it is

behind the mop body.

2. Tilt the mop handle back. This will cause the

Steam Blaster to emit a concentrated blast

of steam onto the ﬂoor.

3. To stop the Steam Blaster spray, simply tilt

the mop handle forward.

4. Flip the Intelli-Mop Head back into its

original position and continue cleaning.
