Sharkoon MS120 Manuale utente
Manual
MS120
MS120
Content
1. Features 3
2. Package content 4
3.The case at a glance 5
4. Installation notes 7
5. Removing the left HDD mounting plate 8
6. Installation of a mainboard 9
7. Installation of a PSU 11
8. Installation of a HDD 12
8.1 Into the lateral HDD mountings 12
8.2 Into the bottom panel 13
9. Installation of an optical device 14
10. Installation of a 3.5" device 16
11. Installation of an add-on card 17
12. Installation of additional fans / optimized airflow 18
Dear customer!
Congratulations for purchasing this premium quality SHARKOON product.
For a long life time and to take full advantage of this product we recommend you to read this manual completely.
Enjoy our product!
SHARKOONTechnologies
2
MS120
1. Features
• MicroATXcase
• 1x5.25"drivebay(external)
• 1x3.5"mountingbay(external)
• Internalmountingareafor4x3.5"or6x2.5"HDDs
• 4slotsforadd-oncards
• FrontI/Owith1xUSB3.0,3xUSB2.0and2xaudio
• 2x120mmLEDfanspre-installed
• SupportsVGAcardsupto36cmlength
• Dimensions:420x175x375mm(LxWxH)
• Weight:~4kg
• Fanconguration:
Casefront 2x120mmLEDfans
Rearpanel 1x80mmor1x92mmfan(optional)
Casebottom 1x120mmfan(optional)
3
MS120
2. Package contents
• ATXcase"MS120"
• Screwkit:
Screwsformainboardand
drivemounting
(3.5"and5.25")
Mountingscrewsfor2.5"
HDDs/SSDs
ScrewsforPSU
mounting
ScrewsforHDDmounting
• Accessorykit:
Stand-offsformainboard Washers Cabletie(A)andspeaker(B)
Note:
If you are missing any of the items listed above, please contact our customer service immediately:
[email protected] (international).
4
A
B
MS120
3.The case at a glance
Frontpanel
A – FrontI/O:
a – 1xUSB3.0
b – 3xUSB2.0and
c – 2xaudio
B – 5.25"drivebay
C – PowerLED
D – On/offbutton
E – 3.5"mountingbay
F – LEDforHDDactivity
G– Resetbutton
H – behindthemeshpanel:2x120mmLEDfans
Sidepanel(closed/left)
A – Airinlet
5
ab b
c
A
A
A
B
B
C
DE
E
F
G
H
MS120
Sidepanel(opened/left)
A – 5.25"drivebay
B – 3.5"mountingbay
C – Attachmentsfor4x3.5"or
6x2.5"-HDDs/SSDs
D – Mainboardmountingpanel
Rearpanel
A – PSUbracket
B – OpeningforI/Oshield
C – Fanbracket(80or92mm)
D – Slotbezels
E – Thumbscrews
F – ConnectioncableforthefrontUSB3.0plug
6
A
A
B
B
C
D
C
D
E
E
E
E
F
MS120
Bottompanel
A – Casefeet
B – Attachmentfor3.5"HDD
C – AttachmentscrewsforHDDmountingpanel
D – Bracketfor120mmfan
4. Installation notes
1.ForfurtherinformationonhowtoinstallthePCcomponents,alsorefertotheirrespectiveinstructions.
2.InordertoinstalllongVGAcards,itmightbenecessarytoremovetheleftHDDmountingpanel(see5.).
Tohavetheoptiontoinstallatleasttwo3.5"HDDs,thereisanadditionalHDDattachmentinthebottom
panelofthecase.
7
A A
AA
B B
BB
C C
D
MS120
Fig.1
1.Unscrewthethumbscrewsonthebacksideofthecaseandremovebothsidepanels.
2.UnscrewthethreeattachmentscrewsoftheHDDmountingpanelandremovethepanelfromthecase
(g.2a-c).
Fig.2a-c
5. Removing the HDD mounting plate
InordertoinstalllongVGAcards,andtoutilizethebottomHDDattachment,theleftHDDmountingpanel
(g.1)mustberemovedasfollows:
8
MS120
6. Installation of a mainboard
1.Unscrewthethumbscrewsonthebacksideofthecaseandremovetheleftsidepanel.Laydownthe
casesidewiseonanevensurface.
2.Themountingpanelofthemainboardinsidethecaseprovidesvariousmountingholestoxthe
standoffs(g.3).
Fig.3
Themainboardcontainsspecialscrewmounts(g.4).
Fig.4
Placethemainboardtothemountingpanel.Astandoffmustbescrewedintoeveryholeonthe
mountingpanelvisiblethroughthemainboard’sscrewopenings.
9
MS120
3.Removethemainboardandscrewthestandoffsintotherespectiveholesofthemountingpanel(g.5).
(Standoffs)
Fig.5
4.InserttheI/Oshield(deliveredwiththemainboard)intotheI/Oshieldopeningintherearpanelofthecase.
5.Placethemainboardbackontothestandoffsandscrewthemainboardtothem(g.6).
(Screwsformainboardmounting)
Fig.6
10
