Shop-Vac AM425-HV Manuale utente

User Manual

Please review before operating unit.

Air Mover

MODEL AM425-HV

Household and Workshop Use.

ATTENTION!

WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:

Read all safety rules carefully before attempting to operate.

Retain for future reference.

DANGER!

Never operate this unit when flammable materials or vapors

are present because electrical devices produce arcs or

sparks that can cause a fire or explosion. NEVER OPERATE

UNATTENDED.

If your Shop-Vac Air Mover ever needs repair or maintenance during

the warranty period or any time thereafter, there are Authorized Shop-

Vac Service Centres located across the country (please see the enclosed

separate pamphlet).

Do not attempt to service your Shop-Vac Air Mover beyond that

described in the User Manual. For all other servicing, please refer to a

qualified Shop-Vac Service Centre.

When using an electrical appliance, basic precautions should always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.

AUTHORIZED SHOP-VAC SERVICE CENTRES

IMPORTANT SAFETY INSTRUCTIONS

SHOP-VAC AUSTRALIA PTY LTD

Patents Issued and Pending.

1. Do not leave appliance when

plugged in. Unplug from outlet

when not in use and before

servicing.

2. Do not expose to water or rain –

store indoors.

3. Do not allow to be used as a toy.

Close attention is necessary when

used by or near children.

4. Use only as described in this

manual. Use only manufacturer’s

recommended attachments.

5. Do not operate Air Mover with

damaged cord or plug.

6. Do Not: pull or carry by cord, use

cord as a handle, close door on

cord or pull cord around sharp

edges or corners. Do not run

appliance over cord. Keep cord

away from heated surfaces.

7. Do not unplug by pulling on cord. To

unplug, grasp the plug; not the

cord.

8. Do not handle plug or appliance

with wet hands.

9. Do not put any object into openings.

Do not use with any opening

blocked; keep free of dust, lint, hair

and anything that may reduce air

flow.

10. Keep hair, loose clothing, fingers

and all parts of body away from

openings and moving parts.

11. Turn off all controls before

unplugging.

12. WARNING! To avoid injury or

property damage: do not use

around explosive liquids or vapors,

as electrical devices produce arcs

or sparks, which can cause a fire or

explosion.

13. Do not store or use near flammable

or combustible liquids such as

gasoline, toxic, carcinogenic,

combustible or hazardous materials

such as asbestos, arsenic, barium,

beryllium, lead, pesticides or other

health endangering materials.

LIMITED TWO-YEAR WARRANTY

Shop-Vac warrants the air mover for two years from the date of purchase to correct by repair or parts replacement without charge, any

product defect due to faulty material or workmanship provided that the air mover is not used for rental service. This warranty does not

cover accessories. Simply return the complete unit, (transportation prepaid), to the Authorized Shop-Vac Service Centre nearest you (a complete

list of Authorized Shop-Vac Service Centres is included with each air mover). Shop-Vac assumes no responsibility for damage or faulty

performance caused by misuse or careless handling, or where repairs have been made or attempted by others. Proof of purchase date is

required. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.Our goods come with

guarantees that cannot be excluded under the Australian Consumer Law.You are entitled to a replacement or refund for a major failure and for

compensation for any other reasonably foreseeable loss or damage.You are also entitled to have the goods repaired or replaced if the goods fail

to be of acceptable quality and the failure does not amount to a major failure.

WARNING - DO NOT LEAVE AIR MOVER UNATTENDED WHEN IT IS PLUGGED IN AND/OR

OPERATING. UNPLUG UNIT WHEN NOT IN USE.

READ AND SAVE THESE INSTRUCTIONS

14. Do not run cord under carpeting. Do

not cover cord with throw rugs,

runners, or similar coverings.

Arrange cord away from traffic area

and where it will not be tripped

over.

15. Operation of this unit can result in

foreign objects being blown into

eyes, which can result in eye

damage. Always wear safety

goggles when operating Air Mover.

16. STAY ALERT, Watch what you are

doing and use common sense.

17. Do not use an extension cord with

this Air Mover.

18. This appliance can be used by

children aged from 8 years and

above and persons with reduced

physical, sensory or mental

capabilities or lack of experience

and knowledge if they have been

given supervision or instruction

concerning use of the appliance in

a safe way and understand the

hazards involved. Children shall not

play with the appliance.

19. Cleaning and user maintenance

shall not be made by children

without supervision.

20. If the supply cord is damaged, it

must be replaced by the

manufacturer, its service agent or

similarly qualified person in order to

avoid a hazard.

21. The plug must be removed from the

socket-outlet before cleaning or

maintaining the appliance.

DOUBLE INSULATION

Do not operate if cord, plug or appliance is damaged. In your double insulated appliance, two systems of insulation are provided instead of

grounding. No grounding means is provided nor should a means for grounding be added to the appliance.

NOTE: If power cord needs to be replaced, use only a Shop-Vac Service Agent.

OPERATION

Follow these instructions to operate your air mover:

1. Unpack air mover from carton.

2. To use your unit, place the unit in the area most suitable for your application. Several factors need to be considered; the unit must be placed

close enough to an AC outlet to be plugged in, there must be a minimum clearance of two feet from either side of the unit to allow for proper

air flow, and the unit should not be placed where it can become a tripping or safety hazard.

3. Place unit in the proper operating position for your application. Refer to the Operating Positions section in this manual.

4. Plug unit into the wall.

5. Turn unit on and select air speed by turning the switch, located near the top handle, clockwise.

6. When your drying job is completed, turn the unit off and follow the directions for Storage in this manual.

WARNING -

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THIS AIR MOVER

WITH ANY SOLID-STATE SPEED CONTROL DEVICE.

OPERATING POSITIONS

The air mover may be set in one of three operating positions. Pick the position best suited for your application.

1. Use the down position (Figure 1) for applications such as; drying wet floors, shampooed carpets, etc. To use this position simply place unit

on its base.

2. Use the angle position (Figure 2) for applications such as, drying plaster on walls or drying wet furniture. To use this position, tilt unit

backwards so it rests on the support.

3. Use the up position for applications such as; drying paint on the ceiling. To use this position, lay the unit on the back side with the front grill

pointing towards the ceiling (Figure 3).

CLEANING

USER SERVICING INSTRUCTIONS

LUBRICATION

WARNING -

TO REDUCE THE RISK OF INJURY FROM THE AIR MOVER ACCIDENTALLY STARTING,

UNPLUG POWER CORD BEFORE CLEANING.

The outside of the unit may be cleaned with a damp cloth to remove any dust or residue.

WARNING -

BE SURE TO DISCONNECT POWER SUPPLY BEFORE ATTEMPTING TO SERVICE OR

REMOVE ANY COMPONENTS.

Do not attempt to service your air mover beyond that described in the user manual.

No lubrication is necessary as the motor is equipped with lifetime lubricated bearings.

123

1. Before storing your air mover it should be cleaned. For cleaning instructions, refer to the Cleaning section in this manual.

2. Wrap the power cord around the carry handle on the top of the unit to keep it untangled (Figure 4).

3. If you have more then one unit to store they may be stored by stacking them. Stack the units by placing them on their sides making sure the

indented side is facing down (Figure 5). Do not stack the units more then 4 high. Never operate the unit while it is on its side or stacked. THE

AIR MOVER SHOULD BE STORED INDOORS.

STORAGE

87548-36
