The MU 6040C/D is a fully digital DSP-

microprocessor based microphone unit

designed for use together with custom

made front plates and external micro-

phone and loudspeaker.

The MU 6040 is designed for installa-

tion inside the conference furniture,

below tables or inside floor boxes.

The MU 6040 is automatically recog-

nised and receives a unique address in

the system. The MU 6040 is delivered

in a shielded metal mounting box.

The MU 6040 is connected to the

unique DIS digital communication bus

- the DCS-LAN as any other DCS

6000 unit.

The MU 6040 features:

Two versions - a delegate

(MU 6040D) and a chairman (MU

6040C) version

Connection for DIS high quality

electret condenser microphones

semi gooseneck type DIS GM 44xx

or hand held type HM 4042/4047.

All with lamp indication

DCS 6000 Digital

Conference System

Conference Units

Microphone Unit

Chairman and

Delegate

MU 6040D

Data sheet no. 6.25b

Connection for DIS loudspeaker.

Signal mutes when the microphone

is activated

Digital audio and control transmis-

sion on STP/FTP Cat 5 cable using

DIS proprietary protocol gives

unique performance and high reli-

ability

Connection for front plates with ope-

rating buttons, LED indicators, loud-

speaker and microphone.

Multiple Operating modes deter-

mined by the DCS 6000 set-up.

Additional Chairman functions

via front plate:

"Delegate Off" button.

Extra button and LED for turning on

the microphone unit first in the queue

or other customized functions

How to order Conference Units:

MU 6040D

MU 6040C

Order no.:

15 31 58340

15 31 58344

Connection Cable for DCS

6000 components:

EC 6000-0,5 EC 6000-10

EC 6000-01 EC 6000-20

EC 6000-05 EC 6000 -50

0,5 m - 50 m. cables

MU 6040C

DIS, Danish Interpretation Systems A/S, Vestre Teglgade 12, DK-2450 Copenhagen SV, Denmark, Tel.: +45 33 85 40 40, Fax: +45 33 85 40 41, e-mail: info@dis.cc

Microphone connection:

Mic. type: DIS Electret Cardioid

HD15-Sub female socket

Switch Inputs: Microphone or

Request on/off

LED Outputs: Speak

Request

Microphone Lamp

Loudspeaker Output: 8 Ohm -

1W max.

Connections:

I/O for daisy chain connection with

digital STP/FTP Cat5 screened for pre-

vious and next DCS 6000 series con-

ference units or CU 6010 Central Unit.

Connector type: RJ-45, screened

with auto-termination

Audio section:

Freq. Response (mic. in to line out):

100 Hz - 15 kHz

THD: < 0,1%

S/N: > 90 dBA

Specifications

DCS 6000 Digital

Conference System

Conference Units

MU 6040D

Data sheet no. 6.25b

Dimension (WxHxD):

Overall dimension:

W/o connectors: 115 x 26 x 122 mm

Temperature Range:

5 º - 40 º C

Weight: 0,4 kg.

Power Requirements:

Supplied from CU 6010

Power Consumption:

2.5 W (typical) - inclusive

microphone and loudspeaker

Please refer to the CU 6010 User

Manual for specification of numbers

of units per chain.

Please refer to Data Sheet for CU 6010

for specifications of the DCS 6000

system.

The MU 6040 and the DCS 6000

system conform to all relevant stand-

ards - e.g. IEC 914, ISO 4043, ISO

2603

Data subject to change without notice in interest of

product improvements

Dimensions

MU 6040C
